Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 246.34 including GST
NZ$ 214.21 excluding GST
or four payments of $61.59
with
Learn More
each
S2017
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
S114535Associated Numbers
0986012290 0986017541 111312 11818 17295N 17688N 201301 20305 20445521BN 20513013 20759 22.0759 22.0759M 23300-1M215 23300-1M216 23300-70Y00 23300-70Y01 23300-70Y10 23300-73C00 23300-73C10 23300-74Y00 23300-74Y10 25-1335 25-2070 438159 458173 6020103 6020125 66925126 66925201 66925391 8052152 88212779 8EA012526-701 8EA731794-001 9007045016 9573 AES7193 CST20103 CST20103AS CST20103ES CST20103GS CST20103OS CST20103RS CST20125 CST20125AS CST20125ES CST20125GS CST20125OS CST20125RS DRS3357 EAA-121262 JS759 LRS00793 LRS01220 M0T80285 M0T80285A M1T77281 M2T49283 M3T37783 S114-535 S114-569 S114-630 S114-769 S114-769A S2017 SS754 STR72097 VS314 Bosch Starter Motor BXN121 STARTER MOTOR 1 UNIT JXS128 Hitachi S114-315 [23300-M80000] 12v 0.8kw S114-316 [23300-M8200] [23300-70Y00] [23300-85A01] Ingram 843213 Lucas LRS400 APPLICATION USED IN PARTSLOT QTY COMMENTS Mitsubishi M0T80281 [23300-1M210] 1.2kw M0T80281A [23300-1M211] M2T23181 [23300-M8010] ASPLList AUTOELECTRO BOSCH BOSCHList CARGO CASCO CEVAM DELCO EAA121262 EAA EAI 251335 ELSTOCK 252070 FRIESEN HC PARTS 8EA012526701 HELLA 8EA731794001 S114535 HITACHIList S114569 S114630 S114769 S114769A KUHNER LAUBER LUCAS MITSUBISHIList 233001M215 NISSANList 233001M216 NISSAN 2330070Y00 2330070Y01 2330070Y10 2330073C00 2330073C10 2330074Y00 2330074Y10 POWERMAX PRESTOLITE REAL SANDO SOVEREIGN VALEO WAI / TRANSPO WOODAUTO ruil 11040118 EuroTec 11040173 11040181 11040187 11296 113139 Cargo STEMOT 160566082 PSH 17295R 17688 Lester 17688R 233000M210 Nissan 233001M211 2330070y00 233008LA01B Elstock 4734SP Spidan Prestolite ADS216 ATK EL25115 EL25201 F042001090 F042S01090 H647997C Valeo HJS1301 J5211071 Nipparts JS1301 M000T80281 M0T80281B M0T80281ZC M2T37081 S114535A S27199 STM1043 Rolling Components STM713 STR3007sa Electrolog STR3501 Unipoint STR4023sa STR5130sa STR5278SA 11040164 11040165 160012082 17147N 17580 21864MI 2330085A01 23300M8000 4282SP 458537 8052152F Friesen A77690 ATL DRS2290 Remy HJS759 J5211042 JST1812 M002T49283 M003T37783 S114569A S114617 S114617A TRS109 TWA Delco Mando TM000A33801 M000T80281A M000T80285 M001T77281 M002T53883 M2T53883 mxs312 706015 snj118Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 8 qty |
| No./Teeth (Replaces) | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 43 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | 100 NX 1.6 | (B13)[GA16DE] | 10.1990-10.1994 |
| NISSAN | Almera 1.4 | (N15)[GA14DE] | 07.1995-03.2000 |
| NISSAN | Almera 1.6 | (N15)[GA16DE] | 07.1995-03.2000 |
| NISSAN | Almera 1.6 SLX | (N15)[GA16DE] | 07.1995-04.2000 |
| NISSAN | Sunny 1.4 16V | [GA14DE] | 10.1990-05.1995 |
| NISSAN | Sunny 1.4 i | (N14)[GA14DE] | 10.1992-05.1995 |
| NISSAN | Sunny 1.4 i | (N14)[GA14DS] | 10.1990-05.1995 |
| NISSAN | Sunny 1.4 i 16V | (N14)[GA14DE] | 10.1992-06.1995 |
| NISSAN | Sunny 1.6 16V | (Y10)[GA16DS] | 10.1990-05.1995 |
| NISSAN | Sunny 1.6 i | (N14)[GA16DE] | 10.1992-05.1995 |
| NISSAN | Sunny 1.6 i | (N14)[GA16DEL] | 10.1990-10.1992 |
| NISSAN | Sunny 1.6 i | (N14)[GA16DS] | 10.1990-05.1995 |
| NISSAN | Sunny 1.6 i | (Y10)[GA16DE] | 10.1992-03.2000 |
| NISSAN | Sunny 1.6 i 16V | (10)[GA16DE] | 10.1992-03.2000 |
| NISSAN | Sunny 1.6 i 16V | (N14)[GA16DE] | 10.1992-05.1995 |
| NISSAN | Sunny 1.6 i 16V | (Y10L)[GA16DE] | 10.1992-03.2000 |
Reference Information
CST20103OS 233001M210 233001M211 20445521BN S114769H CST20103GS JS759 SS754 S114-316 CST20125 S114-769H M001T77285 66925126 23300M8200L M001T77281 23300-73C01 23300-73C00 LRS01220 M3T37783 MTD176 8EA731794-001 S114-769A 2330070Y01R M002T49283ZC S114316 25-2070 M2T23181 S114315 23300-74Y00 88212779 MTD216 S2017 M2T27781 335609 M0T80281ZC 3D216 2330041B15 6020103 M002T37081 2330041B10 22.0759 23300M8000 CST20103ES 23300M8001 M1T77281 S114568 M1T77285 MAV221250 M003T37783 M2T43283 STR3258 23300-62C10 M0T80281 S114569A M0T80285 M003T27781 CST20103 3D176 M002T49282 S114-617 M002T49283 M000T80281B 23300M8211 23300M8210 S114617 458173 STR5278 23300M8212 VS314 S114-569A M002T49281 9007045016 23300B03G0 CGB-23357 S114-569B 003-D176 CST20125RS 003-D216 220088 M3T37781 0986017541 M000T80281A PRSS633 S114568A S114-569 23300-73C10 CST20125AS M002T23181 M002T27781 STA0347R 2330099B00 23300-74Y10 AES7193 23300-0M210 2330080200 2330099B06 M0T80285A 111312 MAV5030 S114-630 2330085A01 M2T37781 S114535A MTD136 MDR775 STX200182 M002T43283 66925201 23300-70Y01 S114769AR 8052152 23300-70Y00 S114-535A 23300-85A01 M3T37081 66925391 2330094850 ESA63 STX201029R CST20103RS 20305 3D136 CST20103AS M000T80281 M000T80285 23300M8200 23300M8202 25-1335 23300M8201 S114402 DRS3357 STR72097 22.0759M 23300M8200LB 23300M8200LA S114364 STX200752 LRS793 M003T37781 23300V8200 CST20125OS LRS1220 M0T80281B 8EA012526-701 M2T37081 M3T27781D S114-535 20759 CST20125GS 2330099B00EP LRS00793 23300-1M216 STRS633 23300M8011 23300M8010 M2T49283ZC 0986012290 ANM15577X STX200967 S114617A 9573 23300-84A11 23300-70Y10-EP M000T80281ZC M000T80285A 23300-1M210 23300-1M211 201301 6020125 S114-769 23300-1M215 003-D136 23300-1M212 STX200697R 16775R M3T27781 CST20125ES 11818 M003T37081 M2T49281 20513013 438159 M2T49282 M2T49283 M0T80281A S114-617A STX200697 23300-70Y10 STX201029Video/Publications
