Associated Numbers
104-10260 19451N 20445432OE 240-14118 255312 6020234 980.529.092 CST20234 CST20234AS CST20234ES CST20234GS CST20234OS CST20234RS HITS114-940 S114-940 STH4940 STR72221 UD12069S
104440 PIC
107372 Farcom
11912577010 Yanmar
11912577011 Yanmar
11912577012 Yanmar
41044128 JN
6020234 Sando
7018593 Bobcat
712519451 Wilson
980529092 PSH
AYS131 ATK
DEM608940 ADI
S114940 Hitachi
16-244
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 195 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 12.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 80 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BOBCAT | 3400 0.5 | ||
| BOBCAT | 3400 XL 0.5 | ||
| BOBCAT | 3450 0.5 | ||
| BOBCAT | 3600 0.5 | ||
| FERIS | IS2500Z | [3TNM68] | |
| FERIS | IS2500Z | [3TNM72] | |
| FERRIS | IS2500Z | [3TNM68] | |
| FERRIS | IS2500Z | [3TNM72] | |
| YANMAR | Various Models |
Reference Information
S12HT0769A2 11912577010 20445432OE STH4940 980.529.092 HITS114-940 CST20234AS S114-940 6020234 240-14118 UD12069S CST20234OS CST20234 255312 CST20234RS CST20234GS CST20234ES 104-10260 STR72221 19451NVideo/Publications
