Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 250.84 including GST
NZ$ 218.12 excluding GST
or four payments of $62.71
with
Learn More
each
S3015
1
Associated Numbers
0000434120 0001208515 0001208517 0001208526 0001208528 0001208717 0986010310 0986010311 0986015010 0986015011 10310 11.130.208 11.130.346 11.130.582 11.130.790 11.130.956 110585 11348 11359 16797R 20401711BN 20513048 22.0310 3010 30177N 3412455 3430012 3503 35258720 42013200 42015010 42016401 432566 432614 432621 433249 433309 436058 436059 436084 534029 534031 534042 534043 534057 6010117 63291405 66925129 7700272482 7700703490 7700758217 7700854954 7701349264 7701351027 7701499247 7701499482 7709758174 8010310 8212447 88212447 8EA726063-001 9000333117 9031302 AES5103 AES5105 AZE1203 AZF3512 AZF3531 AZF3558 CS310 CST10117AS D9E137 D9E138 D9E237 D9E238 D9E276 D9E39 D9E71 D9E76 D9E761 D9E77 D9E771 D9E772 D9E773 D9E774 D9E776 D9R237 DRS0310 DRS3116 DRS5010 EAA-121517 GS432566-A IS0790 LRS00503 LRS00505 M3T32985 M3T32986 M3T32988 M3T32989 ND058 ND114 ND145 RNL1031 S3015 SS154 SS340 STR54000 VS103 VS320Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 212.5 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Center - Center (O.2) | 93 mm |
| Mount Hole Center - Center (O.3) | 23 mm |
| Mount Hole Center - Center (O.4) | 64 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| Mount Hole Diameter (C.4) | M10x1.5 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 4 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9. 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | -2 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| RENAULT | 19 1.7 Chamade | 09.1988-08.1995 | |
| RENAULT | 19 1.7 Chamade | 09.1988-12.1992 | |
| RENAULT | Clio 1.1 | [C1E700] | 06.1990-03.1996 |
| RENAULT | Clio 1.2 | [C3G720] | 09.1995-03.1996 |
| RENAULT | Clio 1.2 | [E5F710] | 05.1990-03.1996 |
| RENAULT | Clio 1.2 i | [C3G720] | 09.1995-03.1996 |
| RENAULT | Clio 1.7 | [F2N770] | 06.1990-03.1996 |
| RENAULT | Clio 1.8 | [F3P710] | 06.1990-07.1994 |
| RENAULT | Clio 1.8 | [F3P714] | 06.1990-07.1994 |
| RENAULT | Clio 1.8 16V | [F7P722] | 03.1991-03.1996 |
| RENAULT | Clio 1.8 i | [F3P712] | 07.1992-03.1996 |
| RENAULT | R11 1.1 | [C1E715] | 03.1983-03.1991 |
| RENAULT | R11 1.1 | [C1E720] | 03.1983-03.1991 |
| RENAULT | R11 1.2 | [C1G700] | 10.1984-12.1986 |
| RENAULT | R11 1.2 | [C1G710] | 06.1986-03.1991 |
| RENAULT | R11 1.4 | [C1J715] | 03.1983-12.1985 |
| RENAULT | R11 1.4 | [C2J717] | 05.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J718] | 03.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J720] | 03.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J730] | 03.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J755] | 05.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J757] | 03.1983-12.1984 |
| RENAULT | R11 1.4 | [C2J766] | 03.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J767] | 03.1983-03.1991 |
| RENAULT | R11 1.4 | [C2J768] | 06.1985-03.1991 |
| RENAULT | R11 1.4 Turbo | [C1J760] | 09.1983-12.1986 |
| RENAULT | R11 1.4 Turbo | [C1J764] | 09.1983-03.1991 |
| RENAULT | R11 1.4 Turbo | [C1J770] | 06.1985-03.1991 |
| RENAULT | R11 1.4 Turbo | [C1J782] | 06.1985-03.1991 |
| RENAULT | R11 1.7 | [F2N700] | 10.1983-12.1987 |
| RENAULT | R11 1.7 | [F2N704] | 10.1983-06.1987 |
| RENAULT | R11 1.7 | [F2N708] | 10.1986-03.1991 |
| RENAULT | R11 1.7 | [F2N710] | 10.1986-03.1991 |
| RENAULT | R11 1.7 | [F2N730] | 10.1986-03.1991 |
| RENAULT | R11 1.7 | [F2N732] | 06.1987-03.1991 |
| RENAULT | R11 1.7 | [F2N742] | 06.1987-03.1991 |
| RENAULT | R11 1.7 | [F2N798] | 10.1986-03.1991 |
| RENAULT | R11 1.7 | [F3N708] | 06.1987-12.1988 |
| RENAULT | R11 1.7 | [F3N718] | 10.1984-03.1991 |
| RENAULT | R19 1.2 | [C1G730] | 01.1988-12.1995 |
| RENAULT | R19 1.4 | [C2J772] | 01.1989-04.1992 |
| RENAULT | R19 1.4 | [C3J710] | 01.1989-10.1995 |
| RENAULT | R19 1.4 | [E6J700] | 01.1988-12.1995 |
| RENAULT | R19 1.4 | [E6J701] | 09.1988-12.2001 |
| RENAULT | R19 1.4 | [E7J706] | 01.1992-12.1995 |
| RENAULT | R19 1.4 | [E7J742] | 01.1988-12.2001 |
| RENAULT | R19 1.8 16V | [F7P704] | 10.1989-06.1996 |
| RENAULT | R21 1.4 | [C2J770] | 09.1989-03.1993 |
| RENAULT | R21 1.7 | [F2N710] | 03.1986-12.1995 |
| RENAULT | R21 1.7 | [F2N712] | 03.1986-03.1993 |
| RENAULT | R21 1.7 | [F2N750] | 03.1986-11.1989 |
| RENAULT | R21 1.7 | [F2N752] | 06.1987-04.1989 |
| RENAULT | R21 1.7 | [F3N722] | 03.1986-11.1989 |
| RENAULT | R21 1.7 | [F3N723] | 03.1986-11.1989 |
| RENAULT | R21 1.7 | [F3N726] | 03.1986-11.1989 |
| RENAULT | R5 1.0 | [C1C700] | 10.1984-12.1996 |
| RENAULT | R5 1.1 | [C1E750] | 10.1984-12.1996 |
| RENAULT | R5 1.1 | [C1E752] | 10.1984-06.1989 |
| RENAULT | R5 1.1 | [C1E754] | 10.1984-06.1989 |
| RENAULT | R5 1.1 | [C1E756] | 06.1987-08.1990 |
| RENAULT | R5 1.1 | [C1E760] | 01.1986-03.1995 |
| RENAULT | R5 1.4 | [C1J768] | 10.1984-12.1996 |
| RENAULT | R5 1.4 | [C1J780] | 10.1984-06.1989 |
| RENAULT | R5 1.4 | [C2J700] | 06.1987-12.1996 |
| RENAULT | R5 1.4 | [C2J780] | 10.1984-06.1987 |
| RENAULT | R5 1.4 | [C2J781] | 10.1984-12.1996 |
| RENAULT | R5 1.4 | [C2J782] | 06.1987-12.1996 |
| RENAULT | R5 1.4 | [C2J784] | 06.1987-12.1996 |
| RENAULT | R5 1.4 | [C2J788] | 10.1984-12.1996 |
| RENAULT | R5 1.4 | [C2J789] | 10.1984-12.1996 |
| RENAULT | R5 1.4 | [C2J798] | 10.1984-07.1989 |
| RENAULT | R5 1.4 | [C3J700] | 10.1984-10.1987 |
| RENAULT | R5 1.4 | [C3J702] | 10.1985-02.1988 |
| RENAULT | R5 1.4 | [C3J760] | 10.1985-12.1996 |
| RENAULT | R5 1.4 Turbo GT | [C1J782] | 04.1984-08.1990 |
| RENAULT | R5 1.4 Turbo GT | [C1J784] | 10.1984-12.1996 |
| RENAULT | R5 1.4 Turbo GT | [C1J788] | 06.1987-12.1996 |
| RENAULT | R9 1.1 | [C1E715] | 09.1981-10.1987 |
| RENAULT | R9 1.1 | [C1E720] | 09.1981-10.1987 |
| RENAULT | R9 1.2 | [C1G700] | 09.1985-12.1986 |
| RENAULT | R9 1.2 | [C1G710] | 09.1986-03.1991 |
| RENAULT | R9 1.4 | [C1J715] | 12.1981-03.1991 |
| RENAULT | R9 1.4 | [C1J792] | 12.1981-03.1991 |
| RENAULT | R9 1.4 | [C1J796] | 12.1981-03.1991 |
| RENAULT | R9 1.4 | [C2J717] | 09.1981-03.1991 |
| RENAULT | R9 1.4 | [C2J718] | 09.1981-03.1991 |
| RENAULT | R9 1.4 | [C2J720] | 10.1986-06.1987 |
| RENAULT | R9 1.4 | [C2J730] | 10.1986-03.1991 |
| RENAULT | R9 1.4 | [C2J755] | 09.1981-03.1991 |
| RENAULT | R9 1.4 | [C2J757] | 09.1981-10.1984 |
| RENAULT | R9 1.4 | [C2J766] | 10.1984-03.1991 |
| RENAULT | R9 1.4 | [C2J767] | 10.1984-03.1991 |
| RENAULT | R9 1.4 | [C2J768] | 09.1985-03.1991 |
| RENAULT | R9 1.4 Turbo | [C1J760] | 10.1984-03.1991 |
| RENAULT | R9 1.4 Turbo | [C1J764] | 10.1984-03.1991 |
| RENAULT | R9 1.7 | [F2N708] | 10.1986-03.1991 |
| RENAULT | R9 1.7 | [F2N710] | 10.1986-03.1991 |
| RENAULT | R9 1.7 | [F2N730] | 10.1986-03.1991 |
| RENAULT | R9 1.7 | [F2N798] | 10.1986-12.1988 |
| RENAULT | R9 1.7 | [F3N708] | 06.1987-12.1988 |
| RENAULT | R9 1.7 | [F3N718] | 10.1986-03.1991 |
| RENAULT | R9 1.7 TXE | [F2N700] | 09.1984-06.1987 |
| RENAULT | R9 1.7 TXE | [F2N704] | 09.1984-06.1987 |
| RENAULT | Rapid 1.0 | [C1C706] | 02.1986-05.1992 |
| RENAULT | Rapid 1.1 | [C1E750] | 03.1986-04.1995 |
| RENAULT | Rapid 1.1 | [C1E752] | 03.1986-06.1989 |
| RENAULT | Rapid 1.1 | [C1E754] | 03.1986-08.1991 |
| RENAULT | Rapid 1.1 | [C1E756] | 06.1987-08.1991 |
| RENAULT | Rapid 1.1 | [C1E760] | 08.1990-08.1991 |
| RENAULT | Rapid 1.1 | [C1E762] | 09.1991-09.1996 |
| RENAULT | Rapid 1.1 | [C1E792] | 03.1986-08.1991 |
| RENAULT | Rapid 1.2 | [C3G710] | 09.1991-10.1997 |
| RENAULT | Rapid 1.2 | [C3G712] | 09.1991-10.1997 |
| RENAULT | Rapid 1.4 | [C1J768] | 07.1985-08.1991 |
| RENAULT | Rapid 1.4 | [C1J780] | 07.1985-08.1991 |
| RENAULT | Rapid 1.4 | [C2J784] | 06.1987-09.1997 |
| RENAULT | Rapid 1.4 | [C3J700] | 03.1986-05.1987 |
| RENAULT | Rapid 1.4 | [C3J702] | 06.1987-08.1991 |
| RENAULT | Rapid 1.4 | [C3J760] | 06.1987-08.1991 |
| RENAULT | Rapid 1.4 | [C3J762] | 09.1991-03.1997 |
| RENAULT | Super 5 1.0 | [C1C700] | 10.1984-12.1996 |
| RENAULT | Super 5 1.1 | [C1E750] | 10.1984-12.1996 |
| RENAULT | Super 5 1.1 | [C1E752] | 10.1984-06.1989 |
| RENAULT | Super 5 1.1 | [C1E754] | 10.1984-06.1989 |
| RENAULT | Super 5 1.2 | [C1G702] | 10.1984-12.1996 |
| RENAULT | Super 5 1.2 | [C1G720] | 10.1986-12.1996 |
| RENAULT | Super 5 1.2 | [C1G722] | 03.1990-12.1996 |
| RENAULT | Trafic 1.6 | [A1M707] | 05.1987-02.1989 |
| RENAULT | Trafic 1.6 | [A1M708] | 05.1987-02.1989 |
| RENAULT | Trafic 1.7 | [F1N722] | 06.1986-04.1989 |
| RENAULT | Trafic 1.7 | [F1N724] | 06.1986-04.1989 |
| VOLVO | 340 1.7 | [B172K] | 08.1985-07.1991 |
| VOLVO | 440 1.6 | [B16F] | 09.1988-07.1997 |
| VOLVO | 440 1.7 | [B18EP] | 09.1988-08.1994 |
| VOLVO | 440 1.7 | [B18F] | 08.1988-08.1991 |
| VOLVO | 440 1.7 | [B18FP] | 08.1989-07.1992 |
| VOLVO | 440 1.7 | [B18KP] | 09.1988-08.1993 |
| VOLVO | 440 1.7 Turbo | [B18FT] | 01.1991-12.1996 |
| VOLVO | 440 1.8 | [B18U] | 09.1995-12.1996 |
| VOLVO | 460 1.6 | [B16F] | 07.1992-07.1997 |
| VOLVO | 460 1.7 | [B18EP] | 08.1989-07.1992 |
| VOLVO | 460 1.7 | [B18FP] | 03.1990-07.1993 |
| VOLVO | 460 1.7 Turbo | [B18FT] | 01.1991-07.1996 |
| VOLVO | 460 1.8 | [B18U] | 08.1991-07.1996 |
| VOLVO | 480 1.7 | [B18E] | 04.1986-07.1989 |
| VOLVO | 480 1.7 | [B18EP] | 08.1989-07.1990 |
| VOLVO | 480 1.7 | [B18F] | 08.1987-07.1989 |
| VOLVO | 480 1.7 Turbo | [B18FT] | 08.1987-07.1996 |
| VOLVO | 480 2.0 | [B20F] | 08.1992-09.1995 |
Reference Information
M3T42581 7700703490 N3T42581 7702180318 7701352049 STR7831 7701352048 AES5105 D9E39 0001208717 42015010 66925129 AES5103 ANM12530X 8010310 AZF3531 580276 M2T48361 GS432566-A 580273 11348 STX200302 432621 570.003.094.395 STX200705 3010 D9R237 7700272482 534031 7700854954 3412455 M002T48361 STX200155 534029 VS320 ESA150 SS340 ND058 11.130.208 7701499247 11359 7701499487 DRS5010 7701499200 9031082 8212447 570.003.094.500 AZF3512 7709758174 570.003.094.505 STR00214 M3T32991 468532 RNL1031 STRL002 M2T48381 7701349265 7701349264 11.130.956 6010117 MAV4510 SX CST10117AS 2100 1516729R 3430012 D9E276 M003T42581 STX200302R 7700352050 0001208526 0001208528 STR0031 42013200 STX200079R 436059 8EA726063-001 436058 433249 570.003.094.000 110585 SS154 D9E77 0986015010 0986015011 D9E761 M003T32989 M003T32988 D9E71 0001208515 M003T32986 0001208517 M003T32985 436084 D9E76 ND145 20513048 20401711BN D9E774 D9E137 D9E138 D9E776 310492 7708758174 220389 D9E771 D9E772 D9E773 9031302 16797R STX200079 220150 DRS3116 310404 M3T32989 30177N M3T32988 STX200636 M3T32985 S3015 STR54000 M3T32986 STR79066 432614 63291405 7701499482 22.031 AZF3558 433309 220456 330462 534043 534042 7700854349 7701352350 EAA-121517 42016401 434120 DRS0310 10310 7700758217 432566 PRSL002 570.003.094.375 7701351027 D9E237 534057 D9E238 0986010311 0986010310 M002T48381 11.130.582 CS310 ND114 VS103 STR00366 11.130.346 9000333117 M003T32991 431120 7701499467 35258720 7700715116Video/Publications
