S3029PR - Remanufactured AS-PL Starter motor

Name: Remanufactured AS-PL Starter motor
Brand: AS-PL
SKU: S3029PR
Price: 256.16 NZD
Availability: BackOrder

Remanufactured AS-PL Starter motor

PREMIUM LINE

Manufacturer:

AS-PL

Replacement For:

VALEO

Price:

NZ$ 256.16 including GST

NZ$ 222.75 excluding GST

UOM:

each

Product Code:

S3029PR

Quantity In Stock Nationally:

No stock in NZ

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

0986022790 101329M 101329V 113933 11997 12417803514 20479512 220.524.113 220429 25-3296 28100-YV020 3105 32737N 3647959 42455982 438166 458185 495107 5802AA 5802EG 5802Z8 5802Z9 5802ZB 6.0155.9 6015215 726065 88212646 8EA011610-981 8EA738198-001 944280801170 95526025 9645100680 9662854080 9663528880 9801667780 AEX1299 CS1329 CST15215 CST15215AS CST15215ES CST15215GS CST15215OS CST15215RS D7G3 DRS3976 DS5086 EAA-121078 G201329MI-R GS438166-A J5218023 LRS01737 M000T22471 M000T22472 M000T22473 M0T22471 M0T22472 M0T22473 MRS80117 RAS34087 SG0580 STM1329 STM965 STR54044 STV1329 STV9329 TS18E13 VAL438166

Kilowatt	1.5 kW
Length (L.1)	210 mm
Mount Hole Center - Center (O.1)	123.5 mm
Mount Hole Center - Center (O.2)	29.5 mm
Mount Hole Center - Center (O.3)	45.5 mm
Mount Hole Center - Center (O.4)	92 mm
Mount Hole Diameter (C.1)	9 mm
Mount Hole Diameter (C.2)	M8x1.25 mm
Mount Hole Diameter (C.3)	M8x1.25 mm
Mount Hole Diameter (C.4)	9.5 mm
No./Mount holes	4 qty
No./Mount holes with thread	2 qty
No./Teeth	11 qty
No./Teeth (Replaces)	11, 12 qty
OEM Product	No
Pinion at Rest (B)	14 mm
Product Line	Premium Line
Product Type	Remanufactured
Rotation	CW
Spigot Diameter (A)	65 mm
Unit Type	VALEO
Voltage	12 V

Make	Model	Type	Year
CITROEN	C1 1.4 HDi	[8HT(DV4TD)]	06.2005-09.2014
CITROEN	C2 1.4 HDi	[8HX(DV4TD)]	09.2003-12.2009
CITROEN	C2 1.4 HDi	[8HZ(DV4TD)]	09.2003-12.2009
CITROEN	C3 1.4 16V HDi	[8HY(DV4TED4)]	02.2002-
CITROEN	C3 1.4 HDi	[8HX(DV4TD)]	02.2002-
CITROEN	C3 1.4 HDi	[8HX(DV4TD)]	04.2004-
CITROEN	C3 1.4 HDi	[8HZ(DV4TD)]	02.2002-
CITROEN	C3 1.6 16V HDi	[9HX(DV6ATED4)]	10.2005-
CITROEN	C3 1.6 16V HDi	[9HZ(DV6TED4)]	09.2005-
CITROEN	C4 1.6 HDi	[9HX(DV6ATED4)]	11.2004-07.2011
CITROEN	C4 1.6 HDi	[9HY(DV6TED4)]	11.2004-07.2011
CITROEN	C4 1.6 HDi	[9HZ(DV6TED4)]	11.2004-07.2011
CITROEN	C4 Grand Picasso 1.6 HDi	[9HY(DV6TED4)]	10.2006-06.2011
CITROEN	C4 Grand Picasso 1.6 HDi	[9HZ(DV6TED4)]	10.2006-06.2011
CITROEN	C4 Picasso 1.6 HDi	[9HY(DV6TED4)]	02.2007-08.2013
CITROEN	C4 Picasso 1.6 HDi	[9HZ(DV6TED4)]	02.2007-08.2013
CITROEN	C5 1.6 HDi	[9HY(DV6TED4)]	09.2004-
CITROEN	C5 1.6 HDi	[9HZ(DV6TED4)]	09.2004-
CITROEN	C5 1.6 HDi 110	[9HZ(DV6TED4)]	02.2008-
CITROEN	C5 2.2 HDi	[4HT(DW12BTED4)]	04.2006-
CITROEN	Xsara Picasso 1.6 HDi	[9HY(DV6TED4)]	05.2004-12.2011
CITROEN	Xsara Picasso 1.6 HDi	[9HZ(DV6TED4)]	05.2004-12.2011
PEUGEOT	1007 1.4 HDi	[8HX(DV4TD)]	04.2005-
PEUGEOT	1007 1.4 HDi	[8HZ(DV4TD)]	04.2005-
PEUGEOT	1007 1.6 HDi	[9HZ(DV6TED4)]	06.2007-
PEUGEOT	107 1.4 HDi	[8HT(DV4TD)]	06.2005-05.2014
PEUGEOT	206 1.4 HDi eco 70	[8HX(DV4TD)]	09.2001-04.2009
PEUGEOT	206 1.4 HDi eco 70	[8HZ(DV4TD)]	09.2001-04.2009
PEUGEOT	206 SW 1.4 HDi	[8HX(DV4TD)]	07.2002-
PEUGEOT	207 1.4 HDi	[8HR(DV4C)]	02.2006-12.2015
PEUGEOT	207 1.4 HDi	[8HZ(DV4TD)]	02.2006-12.2015
PEUGEOT	207 1.6 HDi	[9HV(DV6TED4B)]	02.2006-10.2013
PEUGEOT	207 1.6 HDi	[9HV(DV6TED4BU)]	02.2006-10.2013
PEUGEOT	207 1.6 HDi	[9HX(DV6ATED4)]	02.2006-10.2013
PEUGEOT	207 1.6 HDi	[9HY(DV6TED4)]	02.2006-10.2013
PEUGEOT	207 1.6 HDi	[9HZ(DV6TED4)]	02.2006-10.2013
PEUGEOT	207 CC 1.6 HDi	[9HZ(DV6TED4)]	02.2007-01.2015
PEUGEOT	207 SW 1.6 HDi	[9HV(DV6TED4B)]	06.2007-12.2012
PEUGEOT	207 SW 1.6 HDi	[9HV(DV6TED4BU)]	06.2007-12.2012
PEUGEOT	207 SW 1.6 HDi	[9HZ(DV6TED4)]	06.2007-12.2012
PEUGEOT	208 1.4 HDi	[8HP(DV4C)]	03.2012-
PEUGEOT	208 1.4 HDi	[8HR(DV4C)]	03.2012-
PEUGEOT	307 1.6 HDi 110	[9HY(DV6TED4)]	02.2004-03.2009
PEUGEOT	307 1.6 HDi 110	[9HY(DV6TED4)]	02.2004-04.2008
PEUGEOT	307 1.6 HDi 110	[9HZ(DV6TED4)]	02.2004-03.2009
PEUGEOT	307 1.6 HDi 110	[9HZ(DV6TED4)]	02.2004-04.2008
PEUGEOT	307 SW 1.6 HDi 110	[9HY(DV6TED4)]	11.2003-12.2007
PEUGEOT	307 SW 1.6 HDi 110	[9HZ(DV6TED4)]	11.2003-12.2007
PEUGEOT	308 1.6 HDi	[9HZ(DV6TED4)]	09.2007-10.2014
PEUGEOT	308 SW 1.6 HDi	[9HZ(DV6TED4)]	09.2007-10.2014
PEUGEOT	407 1.6 HDi 110	[9HZ(DV6TED4)]	05.2004-12.2010
PEUGEOT	407 SW 1.6 HDi 110	[9HZ(DV6TED4)]	05.2004-12.2010
PEUGEOT	Partner 1.6 HDi Tepee	[9HZ(DV6TED4)]	04.2008-
TOYOTA	Aygo 1.4 HDi	[2WZ-TV]	07.2005-08.2010

M000T22472 M000T22473 8EA011610-981 J5218023 M000T22471 MT130028 M0T22473ZZ9 113933 193767 CST15215OS 9662854080 5645100680 CST15215GS 95526025 220429 220.524.113.505 CS1329 220.524.113.508 CST15215AS M0T22473AM M000T22472AM M0T22471AM 220.524.113.265 STR00195 M0T22471 CST15215RS M0T22472 8EA738198-001 M0T22473 9801667780 220.524.113.500 0986022790 SG0580 F042S0H117 003-130028 RAS34087 STR00145 6.0155.9 220.524.113.395 3130028 M000T22473ZZ9 STX200013R S12VA0014A2 9.66353E+11 STM965 EAA-121078 3647959 5802ZB 32737N MRS80117 5802Z9 CST15215ES 5802AA DS5086 5802EG 9663528880 5802Z8 28100-YV020 220.524.113.009 726065 D7G3 220.524.113.008 M000T22471AM M0T22472AM M000T22473AM 220.524.113.000 STX200099 9645100680 STX200013 DRS3976 220.524.113.372 CST15215 STX200099R 6015215 20479512 STRL117

S3029PR
