Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 322.05 including GST
NZ$ 280.04 excluding GST
or four payments of $80.51
with
Learn More
each
S3070
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
TS18E33Associated Numbers
0986022730 114029 12140 130.547.102 20479122BN 20479122OE 22.1511 22.1511M 25-4020 254307V 33345N 55221292 55564491 60105011 6015221 6202105 8214249 93191079 AEY2348 CS1511 CST15221AS CST15221GS DRS0123 EAA-121519 LRS02348 RNLTS18E33 S3070 SS740 STR54088 TS18E33 TS18E331Specifications
| Kilowatt | 1.8 kW |
| Length (L.1) | 219 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Diameter (C.1) | 9.5 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 24 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Aveo 1.3 D | [LDV] | 07.2011-12.2015 |
| CHEVROLET | Aveo 1.3 D | [LSF] | 07.2011-12.2015 |
| OPEL | Agila 1.3 CDTi | [Z13DT] | 08.2003-12.2007 |
| OPEL | Astra 1.3 CDTi | [A13DTE] | 05.2013-10.2015 |
| OPEL | Astra 1.3 CDTi | [A13DTE] | 06.2012-10.2015 |
| OPEL | Astra 1.3 CDTi | [A13DTE] | 10.2012-10.2015 |
| OPEL | Astra 1.3 CDTi | [A13DTE] | 12.2009-10.2015 |
| OPEL | Astra 1.3 CDTi | [Z13DTH] | 02.2007-10.2010 |
| OPEL | Astra 1.3 CDTi | [Z13DTH] | 08.2005-10.2010 |
| OPEL | Astra 1.3 CDTi Sports Tourer | [A13DTE] | 10.2010-10.2014 |
| OPEL | Astra GTC 1.3 CDTi | [Z13DTH] | 04.2005-10.2010 |
| OPEL | Astra H 1.3 CDTi | [Z13DTH] | 08.2005-09.2010 |
| OPEL | Astra H 1.3 CDTi GTC | [Z13DTH] | 08.2005- |
| OPEL | Astra J 1.3 CDTi | [A13DTE] | 01.2010- |
| OPEL | Astra J 1.3 CDTi | [A13DTF] | 01.2010- |
| OPEL | Combo 1.3 CDTi 16V | [Z13DT] | 08.2005- |
| OPEL | Combo 1.3 CDTi 16V | [Z13DTJ] | 10.2005-12.2012 |
| OPEL | Combo Tour 1.3 CDTi 16V | [Y13DT] | 06.2004-01.2011 |
| OPEL | Combo Tour 1.3 CDTi 16V | [Z13DT] | 06.2004-01.2011 |
| OPEL | Combo Tour 1.3 CDTi 16V | [Z13DTJ] | 10.2005-12.2011 |
| OPEL | Corsa 1.3 CDTi | [A13DTC] | 07.2006-08.2014 |
| OPEL | Corsa 1.3 CDTi | [A13DTE] | 06.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [A13DTE] | 11.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [A13DTR] | 06.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [A13DTR] | 11.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [Y13DT] | 06.2003-12.2009 |
| OPEL | Corsa 1.3 CDTi | [Z13DT] | 06.2003-12.2009 |
| OPEL | Corsa 1.3 CDTi | [Z13DTE] | 06.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [Z13DTE] | 11.2009-08.2014 |
| OPEL | Corsa 1.3 CDTi | [Z13DTH] | 07.2006-06.2010 |
| OPEL | Corsa 1.3 CDTi | [Z13DTH] | 07.2006-06.2011 |
| OPEL | Corsa 1.3 CDTi | [Z13DTJ] | 07.2006-08.2014 |
| OPEL | Corsa 1.3 CDTi 16V | [Z13DT] | 07.2005-06.2006 |
| OPEL | Corsa D 1.3 CDTi | [A13DTC] | 07.2006- |
| OPEL | Corsa D 1.3 CDTi | [A13DTR] | 06.2010- |
| OPEL | Corsa D 1.3 CDTi | [Z13DTH] | 07.2006- |
| OPEL | Corsa D 1.3 CDTi | [Z13DTJ] | 07.2006- |
| OPEL | Meriva 1.3 CDTi | [A13DTC] | 06.2010-10.2013 |
| OPEL | Meriva 1.3 CDTi | [A13DTE] | 06.2010-11.2014 |
| OPEL | Meriva 1.3 CDTi | [Y13DT] | 04.2005-05.2010 |
| OPEL | Meriva 1.3 CDTi | [Z13DT] | 04.2005-05.2010 |
| OPEL | Meriva 1.3 CDTi | [Z13DTJ] | 09.2003-05.2010 |
Reference Information
8214249 TS18E331 196039 6202071 458351 RNLTS18E33 1638119980 WG2196670 S12VA0084A 10439606 063721511010 SS740 2131377 A22730 CST15221GS H5015081 6202083 STR0096 55217672 438212 PRSL154 S-54088 944280802340 TS18E33 10015221AV CS1511 2176 3142 20479122BN TT15192 130.547.102.006 6202099 6202095 ASM1088 8080234 93169309 3110764 3110765 S3070 LRS2348 12140 OP9041 SX 22.1511M 328065102 201102 11022730 STX200253 SG0560 130.547.102.000 S12VA0084 STM1186 0986022730 CST15221AS S12VA0084A2 130.547.102.505 QRS2075 EZ0092 220432 AEY2348 114029 93169458 130.547.102.500 SVA221 DSN3047 55564491 5015081 10015221OV 1265030 93190320 ST01548 55221292 8550504857 460477 254307V 93186246 ANM12343X 93189232 DRS0123 WG2012983 WG2012982 STR54088 LRS02348 SVA221A 011-001-000622R AC-CBS1511 R1530109 20479122OE R1530103 4736003 TT15192PRO 60105011 R1540025 6015221.1 140ST21 6015221.0 33345N 22.1511 93191079 254307 8EA011612-601 106473 NPANSM1088 6202105 1202209 V40-12-50001 ANM12343 130.547.102.280 STRL154 BST2354 220432A 88214249 STX200253R 25-4020Video/Publications
