Associated Numbers
36100-45500 600250 602037 PXPSA-807 S0001250238 STA3500 UD02623SSpecifications
| Kilowatt | 5 kW |
| Length (L.1) | 288 mm |
| Mount Hole Center - Center (O.1) | 57 mm |
| Mount Hole Center - Center (O.2) | 144 mm |
| Mount Hole Center - Center (O.3) | 102.5 mm |
| Mount Hole Center - Center (O.4) | 23 mm |
| Mount Hole Diameter (C.1) | M10x1.75 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| Mount Hole Diameter (C.4) | M10x1.75 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 17.5 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | VALEO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | County | [D4DD] | |
| HYUNDAI | HD 65 | [D4DD] | |
| HYUNDAI | HD 72 | [D4DD] | |
| HYUNDAI | HD 78 | [D4DD] |
Reference Information
PXPSA-807 UD02623S S0001250238 600250 STA3500 36100-45500 602037Video/Publications
S3108(VALEO)View your shopping basket or Browse other items in Starter Motors.
