Associated Numbers
115769 12282 25-4332 254754 254754V 30368N 30644957 30659478 31296302 31376637 3157 36001519 6015266 810.535.113 8214451 88214451 9M5N-11000-AA 9M5T-11000-AA AEY2660 CST15266 CST15266AS CST15266ES CST15266GS CST15266OS CST15266RS DRS0664 EAA-123381 LRS02660 LRS2660 S3165S STR54179 STV6441 STV9441 TS22E36 TS22E37 UD13987S VAL438230
11090227 EuroTec
11090318 EuroTec
115769 Cargo
12282 EAI
1687623 Ford
199750 Valeo
221011A Messmer
254332 Elstock
30644957 Volvo
30659478 Volvo
31296302 Volvo
31376637 Volvo
3157 CEVAM
36000947 Volvo
36001519 Volvo
438230 Valeo
458398 Valeo
458713 Valeo
6906194 Volvo
6906214 Volvo
810535113 PSH
8EA011611811 Hella
910664 EDR
9M5N11000AA Ford
9M5t11000aa Ford
AV6N11000GA Ford
AV6N11000GD Ford
DRS0664 Remy
LRS02660 Lucas
LRS2660 Lucas
STR00064sa Electrolog
TS22E36 Valeo show
TS22E36SEL +line
ts22e37 Valeo
Specifications
| Kilowatt | 2.3 kW |
| Length (L.1) | 218 mm |
| Mount Hole Center - Center (O.1) | 116 mm |
| Mount Hole Center - Center (O.2) | 74 mm |
| Mount Hole Center - Center (O.3) | 83 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 13 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | C-Max 1.5 TdCi | [AEDA] | 01.2015- |
| FORD | C-Max 1.5 TdCi | [XWDA] | 01.2015- |
| FORD | C-Max 1.5 TdCi | [XWDB] | 01.2015- |
| FORD | C-Max 1.5 TdCi | [XXDA] | 01.2015- |
| FORD | C-Max 1.5 TdCi | [XXDC] | 01.2015- |
| FORD | Focus 1.6 TdCi | [G8..] | 01.2009- |
| FORD | Focus 1.6 TdCi | [GP..] | 01.2009- |
| FORD | Focus 1.6 TdCi | [HH..] | 01.2009- |
| FORD | Grand C-Max 1.5 TdCi | [XWDA] | 01.2015- |
| FORD | Grand C-Max 1.5 TdCi | [XWDB] | 01.2015- |
| FORD | Grand C-Max 1.5 TdCi | [XXDA] | 01.2015- |
| FORD | Grand C-Max 1.5 TdCi | [XXDC] | 01.2015- |
| VOLVO | C30 1.6 D2 | [D4162T] | 01.2011-12.2013 |
| VOLVO | C30 2.0 D | [D4204T] | 01.2006-12.2012 |
| VOLVO | S40 1.6 D2 | [D4162T] | 01.2011-12.2012 |
| VOLVO | S40 2.0 D | [D4204T] | 01.2004-12.2010 |
| VOLVO | S40 2.0 D | [D4204T2] | 01.2004-12.2010 |
| VOLVO | S60 1.6 D2 | [D4162T] | 01.2011- |
| VOLVO | S80 1.6 D2 | [D4162T] | 01.2011- |
| VOLVO | S80 1.6D DRIVe | [D4164T] | 01.2010- |
| VOLVO | V40 1.6 D2 | [D4162T] | 01.2012- |
| VOLVO | V50 1.6 D2 | [D4162T] | 01.2011-12.2012 |
| VOLVO | V50 2.0 CDi | [D4204T2] | 01.2003-12.2006 |
| VOLVO | V50 2.0 D | [D4204T] | 01.2004-12.2010 |
| VOLVO | V50 2.0 D | [D4204T2] | 01.2004-12.2010 |
| VOLVO | V60 1.6 D2 | [D4162T] | 01.2011- |
| VOLVO | V70 1.6 D | [D4164T] | 01.2010-12.2011 |
| VOLVO | V70 1.6 D2 | [D4162T] | 01.2011- |
| VOLVO | XC40 1.6 D | [D4162T] | 01.2015- |
Reference Information
STV6441 AEY2660 CST15266RS TS22E37 254754V TS22E36 6015266 25-4332 3157 STR54179 STM1312 12282 STM1326 331923 30659478 S12VA0124A2 STX200871 LRS02660 810.535.113.000 CST15266AS UD13987S 6906214 CST15266ES STV9441 VAL438230 5015307 RNLTS22E36 STR00064 60001519 30368N 31296302 CST15266 30644957 STRF603 EAA-123381 88214451 CST15266OS 8214451 S3165S 115769 254754 CST15266GS STX200871R 6906194 810.535.113.500 31376637 DRS0664 9M5T-11000-AA 1687623 9M5N-11000-AA 810.535.113.461 810.535.113.462 LRS2660 36001519 36000947Video/Publications
