Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
LUCAS
Price:
NZ$ 509.19 including GST
NZ$ 442.77 excluding GST
or four payments of $127.30
with
Learn More
each
S4010
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
LRS147Associated Numbers
0001359047 0001359124 0001367032 0001367067 02914502 0986013690 0986013691 10604 10604R 10944 11.130.179 11.130.376 11.130.414 11.130.692 11.131.249 110545 114254 123708003 20405901BN 20405901OE 20408601OE 20500147 25-0315 25-0430 26242 26284 26284A 26284B 26284E 26342 26342A 26342D 26342K 26432 27512 27512A 27512B 27512D 27512F 27587 33521 33783 35259360 3539390M91 443115142722 443115144142 443115144420 443115144520 443115144620 443115144722 443115144729 6025109 6048106 63227512 69185771 800.001.113 800.502.113 820.301.114 8212915 835331592 8710 8710R 8813690 8EA730174-001 8EA737089-001 9142722 9142741 9144722 91455722 933253 976111 976116 976117 AES1147 AZJ3119 AZJ3234 AZJ3405 AZJ3525 AZJ3599 CS604 CS944 CST25109AS CST25109GS CST48106GS DRS3690 EAA-111099 EAA-121509 IS0897 LES0006 LRS00147 LRS00926 LRS01088 NSB523 R11 R11.01 R11.06 R11.10 R11A R11F R11N S4010 STR31000 STR60413 UD16660SSpecifications
| Kilowatt | 2.8 kW |
| Length (L.1) | 341 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 10. 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 46 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | LUCAS |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VALMET | 305 | 01.1985-12.1989 | |
| VALMET | 405 | 01.1985- | |
| VALMET | 505 3.3 | 01.1985- | |
| VALMET | 6000 | 01.1990- | |
| VALMET | 605 3.3 | 01.1985- | |
| VALMET | 6400 | 01.1991- | |
| VALMET | 6600 | 01.1991- | |
| VALMET | 705 4.4 | 01.1985- | |
| VALMET | 805 4.4 | 01.1985- | |
| VALMET | 8100 | 09.1990- | |
| VALMET | 8400 | [620DS] | 01.1993-12.1995 |
| VALMET | 905 | 01.1985- |
Reference Information
110545 DRS3690 6048106 0001359124 AES1147 220238 6025109 11.130.692 11.130.179 26432 91 820.301.114 836640940 LRS00926 35259360 10604R R11.10 8EA730174-001 836662073 STRS526 33521 10944 26284 443115144722 NSB523 11.131.249 443115144729 R11.06 63227512 CGB-23147 0986013691 8710 0986013690 25-0315 S12308622 20405901OE 9142741 20500147 UD16660S 25-0430 27587 STR4189 4412894 976116 976117 976111 STR60413 800.502.113 IS0897 27512 443115142722 8EA737089-001 933253 443115144620 MAV3650 AZJ3599 AZJ3234 0001367067 LRS1088 AZJ3119 1208086 123708003 0001359047 3539390M91 91455722 11.130.376 11.130.414 CST25109AS 8710R CS604 LRS147 MS 69185771 R11A R11F MAV501060 26242 9142722 R11N 443115144520 LES0006 27512D STR31000 27512A 27512B STX200715 27512F S4010 9144722 LRS926 R11.01 800.001.113 20405901BN 26342D 114254 26342A LRS01088 8212915 835331592 CST48106GS 26342K 8813690 CS944 0001367032 02914502 CST25109GS AZJ3405 19677130A AZJ3525 184 10604 LRS00147 R11 26342 33783 26284A STX200691 443115144420 26284E 26284B 20408601OE 443115144142Video/Publications
