Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
LUCAS
Price:
NZ$ 486.35 including GST
NZ$ 422.91 excluding GST
or four payments of $121.59
with
Learn More
each
S4019
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
LRS969Associated Numbers
0986022680 10994L 10994P 111346 17072N 17652N 20405221OE 20405231OE 20500969 22.0994 25-1030 25-2402 26414 27541 27565 27568 27590 27598 27599 27602 27608 27626 27627 27627B 28.0994 28.0994M 2873A029 2873A031 2873B072 33473 35260950 3763362M94 6025122 6025132 63227597 650.008.103 8212947 8735 8735R 8EA737243-001 AES9169 CS994 CST25122GS CST25132GS DRS3287 EAA-111029 EAA-121167 LRS00969 M100R2015SE STR25000Specifications
| Kilowatt | 2.8 kW |
| Length (L.1) | 316 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 30 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | LUCAS |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MASSEY FERGUSON | MF 285 | 01.1979-12.1988 | |
| MASSEY FERGUSON | MF 365 | 01.1986-12.1990 | |
| MASSEY FERGUSON | MF 375 | 01.1986-12.1997 | |
| MASSEY FERGUSON | MF 390 | 01.1986-12.1997 | |
| MASSEY FERGUSON | MF 390 T | 01.1991-12.1997 | |
| MASSEY FERGUSON | MF 398 | 01.1983-12.1984 | |
| MASSEY FERGUSON | MF 399 | 01.1986-12.1990 | |
| MASSEY FERGUSON | MF 4255 | 01.1997-12.2000 |
Reference Information
650.008.103.461 650.008.103.460 27608 10994P 27568 714-40005 27602 10994L CST25132GS 1873A055 1873A054 27565 DRS3287 1447731R1 27627B 2378A029 111346 54265233 2873A029 28.0994 MAV271220 3763362M94 63227597 M100R2015SE 714/29500-R 2873B073 20500969 2873B072 STX200678 22.0994 LRS00969 8735 17652N STR4090 714/40005 71429500R 6025122 3181A032 26414 27627 27626 STR25000 2873A031 STX200560 0986022680 8EA737243-001 28.0994M 20405231OE AES9169 LRS969 33473 27541 650.008.103 714-14300 13028AA200 714/40159 S4019 6025132 35260950 27519 3116683R91 27599 CST25122GS 714-29500 STRL030 2873006 17072N 20405221OE CS994 25-2402 13028AA071 27598 13028AA072 STR4111 8212947 27539A 26414R STX210091 27590 71440005 25-1030 8735RVideo/Publications
S4019View your shopping basket or Browse other items in Starter Motors.
