S4027 - Brand new AS-PL Starter motor

Name: Brand new AS-PL Starter motor
Brand: AS-PL
SKU: S4027
Price: 282.97 NZD
Availability: BackOrder

Brand new AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

MAGNETI MARELLI

Price:

NZ$ 282.97 including GST

NZ$ 246.06 excluding GST

UOM:

each

Product Code:

S4027

Quantity In Stock Nationally:

No stock in NZ

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

0986022111 101191 101345 101345V 11947 20404321 220693 25-2337 3004 32579R 42022111 458163 46451529 46531437 500.538.113 6030123 63111008 63111010 63111016 63111018 63111019 63111036 63111037 63223536 70789523 88212300 8EA012527-391 8EA737820-001 AEU1191 CS1191 CST30123 CST30123AS CST30123ES CST30123GS CST30123OS CST30123RS DRS3583 DRS3587 DS4693 DS4697 EAA-121400 LRS01431 S4027 SG0779 STE1191

Kilowatt	1.4 kW
Length (L.1)	212 mm
Mount Hole Center - Center (O.1)	106 mm
Mount Hole Center - Center (O.2)	72 mm
Mount Hole Center - Center (O.3)	73 mm
Mount Hole Diameter (C.1)	M8x1.25 mm
Mount Hole Diameter (C.2)	M8x1.25 mm
Mount Hole Diameter (C.3)	M8x1.25 mm
No./Mount holes	3 qty
No./Mount holes with thread	3 qty
No./Teeth	9 qty
No./Teeth (Replaces)	9. 11 qty
OEM Product	No
Pinion at Rest (B)	12 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	64 mm
Unit Type	MAGNETI MARELLI
Voltage	12 V

Make	Model	Type	Year
FIAT	Brava 1.6 16V	[182A4.000]	02.1996-10.2001
FIAT	Brava 1.6 16V	[182A6.000]	10.1995-10.2001
FIAT	Bravo 1.6 16V	[182A4.000]	03.1996-10.2001
FIAT	Bravo 1.6 16V	[182A6.000]	10.1995-10.2001
FIAT	Marea 1.6 100 16V	[182A4.000]	09.1996-05.2002
FIAT	Marea 1.6 16V	[185A3.000]	04.1997-02.1999
FIAT	Multipla 1.6 100 16V	[182A4.000]	04.1999-06.2010
FIAT	Multipla 1.6 16V Bipower	[186A4.000]	04.1999-06.2010
FIAT	Multipla 1.6 16V Blupower	[186A3.000]	04.1999-06.2010
FIAT	Palio 1.6 16V	[178C7.098]	07.1997-10.2003
FIAT	Palio 1.6 16V	[178D2.011]	07.1997-10.2003
LANCIA	Dedra 1.6 16V	[182A4.000]	01.1996-07.1999
LANCIA	Dedra SW 1.6 16V	[182A4.000]	01.1996-07.1999
LANCIA	Lybra 1.6 16V	[182A4.000]	07.1999-10.2005

46748349 CST30123 220437 7773763 CST30123RS 63223536 101191 101345V AEU1191 71723357 STRL067 11947 STR9015 51776205 CST30123AS DS4693 63111033 51832956 101345 63111036 DS4697 LRS1431 71782310 46748356 63111037 46748355 CST30123GS 20404321 51868757 46748350 CST30123OS 71782394 3004 458163 46835094 S12MA0821A2 STX200196 0986022111 71782309 8EA737820-001 S4027 71782308 ANM15803X 63111008 70789523 46531437 500.538.113 MAV2380 STA0174R 220693 46808152 46231536 46800152 55193407 71794531 25-2337 71721272 CS1191 8EA012527-391 DRS3587 32579R DRS3583 SG0779 71721236 STX200212R 63111010 63111019 STE1191 CST30123ES 71789523 46451529 63111016 6030123 63111018 EAA-121400 42022111 46524472 46821681 46816971 71721266 LRS01431 STX200196R MAV6360 STX200338 88212300 STX200212

S4027
