Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
LUCAS
Price:
NZ$ 476.53 including GST
NZ$ 414.37 excluding GST
or four payments of $119.13
with
Learn More
each
S4053
No stock in NZ
No stock in NZ
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
LRS240Associated Numbers
0001354107 0001359035 0001359045 0001359059 0001359069 0001362310 0001367003 0001367036 0001367042 0986015040 10106 10461483 10503 10965R93 11.131.038 1107862 1107867 1113284 112660 189330A5 1990316 1990317 1990319 1993713 1993763 1993778 1998343 20401733BN 20500240 260-62158 26336 26336E 26336F 26336L 26336Q 26428 26428A 26433 26925262B 27508 27508A 27508B 27508D 27556 27575 27575B 27575E 27586 27586A 27604 27604A 27604B 27604D 529965EX 529965R92 529965R93 6010337 6060145 6092295 63227508 63227508010 63227586010 820DB11000EA 91-15-6995 91-15-6995N 91-15-7057 91-17-8887 AES2140 AZJ3364 CS106 CST10337 CST10337AS CST10337ES CST10337GS CST10337OS CST10337RS CST60145 CST60145AS CST60145ES CST60145GS CST60145OS CST60145RS DRS5040 EAA-112018 EAA-121304 IS1018 LRS00240 LRS240 MAHMS152 MS152 MSN206 S4053 SG0158 STR25014 TS-4030 UD12408SSpecifications
| Kilowatt | 2.8 kW |
| Length (L.1) | 340 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | LUCAS |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 3220 | [3-179] | 01.1994-12.1997 |
| CASE | 3230 | [4-206] | 01.1994-12.1997 |
| CASE | 380B | 01.1981-12.1987 | |
| CASE | 380CK | [D-179] | 01.1973-12.1980 |
| CASE | 385 | [3-155] | 01.1984-12.1990 |
| CASE | 395 | [3-155] | 01.1991-12.1993 |
| CASE | 4210 | [4-239] | 01.1994-12.1997 |
| CASE | 4210 | [D-239] | 01.1994-12.1996 |
| CASE | 4230 | [4-268] | 01.1994-12.1997 |
| CASE | 4230 | [D-268] | 01.1994-12.1996 |
| CASE | 4240 | [4-268] | 01.1994-12.1997 |
| CASE | 4240 | [DT-268] | 01.1994-12.1996 |
| CASE | 454 | [D-179] | 01.1971-12.1975 |
| CASE | 474 | [D-206] | 01.1973-12.1975 |
| CASE | 484 | [D-179] | 01.1977-12.1982 |
| CASE | 485 | [3-179] | 01.1985-12.1990 |
| CASE | 485 4 | 01.1988- | |
| CASE | 485XL | [D-179] | 01.1982-12.1991 |
| CASE | 495 | [3-179] | 01.1991-12.1994 |
| CASE | 495 | [D-179] | 01.1991-12.1994 |
| CASE | 574 | [D-239] | 01.1971-12.1976 |
| CASE | 584 | [D-206] | 01.1977-12.1982 |
| CASE | 585XL | [D-206] | 01.1982-12.1991 |
| CASE | 595 | [4-206] | 01.1991-12.1994 |
| CASE | 595 | [D-206] | 01.1991-12.1994 |
| CASE | 674 | [D-239] | 01.1973-12.1981 |
| CASE | 684 | [D-239] | 01.1977-12.1982 |
| CASE | 685XL | [D-239] | 01.1982-12.1991 |
| CASE | 695 | [4-239] | 01.1991-12.1994 |
| CASE | 695 | [D-239] | 01.1991-12.1994 |
| CASE | 784 | [D-246] | 01.1977-12.1974 |
| CASE | 784 | 01.1990-12.2008 | |
| CASE | 785 | [D-246] | 01.1981-12.1985 |
| CASE | 885 | [4-268] | 01.1985-12.1990 |
| CASE | 885XL | [D-268] | 01.1983-12.1990 |
| CASE | 895 | [4-268] | 01.1991-12.1994 |
| CASE | 995 | [4-268] | 01.1991-12.1994 |
| INTERNATIONAL | 240 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | 240 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | 250 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | 250 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | 260 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | 260 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | 270 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | 270 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | 3400 | 01.1975-12.2008 | |
| INTERNATIONAL | 3500 | 01.1975-12.2008 | |
| INTERNATIONAL | 474 | 01.1973-12.1976 | |
| INTERNATIONAL | 484 | [D-179] | 01.1978-12.1984 |
| INTERNATIONAL | 584 | [D-206] | 01.1978-12.1984 |
| INTERNATIONAL | 684 | [D-239] | 01.1978-12.1984 |
| INTERNATIONAL | 784 | [D-246] | 01.1978-12.1984 |
| INTERNATIONAL | 884 | [D-268] | 01.1979-12.1984 |
| INTERNATIONAL | I-4500 | 01.1975-12.1982 | |
| INTERNATIONAL | I-454 | 01.1972-12.1976 | |
| INTERNATIONAL | I-574 | [C-200] | 01.1972-12.1976 |
| INTERNATIONAL | I-674 | [C-200] | 01.1972-12.1976 |
| INTERNATIONAL | TD-240 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | TD-240 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | TD-250 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | TD-250 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | TD-260 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | TD-260 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | TD-270 | [D-179] | 01.1976-12.1981 |
| INTERNATIONAL | TD-270 | [D-239] | 01.1976-12.1981 |
| INTERNATIONAL | TD-3400 | 01.1975-12.2008 | |
| INTERNATIONAL | TD-3500 | 01.1975-12.2008 | |
| MASSEY FERGUSON | MF-50 | 01.1970-12.1971 |
Reference Information
1107862 27586A CGB-25040 MAHMS152 0001354107 26433 STR7957 CST10337AS 26336E 63227508010 MAV123370 26336F 26336L 91-17-8887 SG0158 STR0480 26336Q CST10337RS MAV3320 1107867 1993763 26428A 6092295 63227508 403300R92 LRS00240 0001367003 CST10337 27508 S4053 1993778 820DB11000EA MSN206 MS152 0001359069 CST60145ES CS106 27586 260-62158 63227586010 20401733BN 330258 91-15-6995 26428 S12BH0670A2 1990319 1990317 1990316 6060145 CST60145OS 112660 26925262B 20500240 1993713 10965R93 CST10337ES IS1018 0001359045 152 27604 CST60145GS 91-15-7057 189330A5 91-15-6995N 6010337 ANM17260X MS TS-4030 STR4136 0001359035 10461483 10503 10106 27575 529965EX 0001362310 0001367042 CST60145AS MAV621120 26336 CST10337GS 529965R93 529965R92 11.131.038 0986015040 1998343 27508B CST60145RS 27508A LRS240 27508D DRS5040 27575E UD12408S 27575B 27556 STR25014 CST60145 CST10337OS 537140R95 AES2140 537140R94 AZJ3364 27604D 27604A STR10041 27604BVideo/Publications
