Associated Numbers
111485 11698 17425N 20437951BN 20510168 20939 23300-80G10 23300-86G10 23300-86G11 23300-86G12 25-2064 6035159 AES1268 CST35159AS DRS3558 EAA-121266 LRT00168 M001T60281 M001T60285 M001T60285A M1T60281 M1T60285 M1T60285A M1T60286 PBNS1168 STR71243
16-069
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 199 mm |
| Mount Hole Center - Center (O.1) | 109 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 8 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Maverick 2.4 i | [KA24-E] | 02.1993-08.1996 |
| NISSAN | D21 2.4 | [KA24E] | 01.1990-01.1993 |
| NISSAN | King Cab 2.4 i 12V | [KA24E] | 04.1992-02.1998 |
| NISSAN | King Cab 2.4 i 12V 4WD | [KA24E] | 04.1992-02.1998 |
| NISSAN | Pick Up 2.4 | [KA24E] | 01.1994-01.1994 |
| NISSAN | Pick Up 2.4 Short Bed E | [KA24E] | 01.1995-01.1995 |
| NISSAN | Pick Up 2.4 Short Bed XE | [KA24E] | 01.1995-01.1997 |
| NISSAN | Pick Up 2.4 XE | [KA24E] | 01.1994-01.1995 |
| NISSAN | TeRano 2.4 i 12V | [KA24E] | 02.1993-10.1999 |
Reference Information
233001S710 233001S711 20510168 STRL858 AES1268 233001S71A M001T60313 STX200460 STX200460R 20437951BN 6035159 STX200177R STX200909 23300-86G11 23300-86G12 23300-86G10 STR5269 23300-86G11-EP EAA-121266 DRS3558 20939 M001T60285 2330086G12RE S5118 25-2064 233001S772 M001T60281 233001S770 STR71243 JS939 LRT00168 CGB-23558 M0T60081 M1T60281 M0T60082 M1T60286 M001T60285A M1T60285 M0T60081A MAV371590 M1T60285A 17425N PBNS1168 CST35159AS 111485 M000T60082 M000T60081 2330086G11EP STX200177 STX200573 M1T60313 23300-80G10 11698Video/Publications
