Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 734.53 including GST
NZ$ 638.72 excluding GST
or four payments of $183.63
with
Learn More
each
S5149
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M9T82671Associated Numbers
0001330057 0986024990 101451P 114310 19831N 200-38212 20437236OE 20450305 20732404 28.3029 45-3468 6035632 811.510.123 8198 85000295 85000526 88212743 CS1451 CST35632 CST35632AS CST35632ES CST35632GS CST35632OS CST35632RS DRS0319 DRS0319X LRS02297 M009T82671 M009T82672 M105R3509SE M9T82671 M9T82672 UD01726SSpecifications
| Kilowatt | 7 kW |
| Length (L.1) | 379 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | FH 16/540 16.1 | [D16C550] | 08.2007- |
| VOLVO | FH 16/540 16.1 | [D16G540] | 01.2009- |
| VOLVO | FH 16/540 16.1 | [D16G540] | 05.2012- |
| VOLVO | FH 16/540 16.1 | [D16G540] | 08.2007- |
| VOLVO | FH 16/550 16.1 | [D16C550] | 01.2003- |
| VOLVO | FH 16/550 16.1 | [D16C550] | 08.2007- |
| VOLVO | FH 16/550 16.1 | [D16G540] | 08.2007- |
| VOLVO | FH 16/580 16.1 | [D16E580] | 01.2009- |
| VOLVO | FH 16/580 16.1 | [D16E580] | 09.2006- |
| VOLVO | FH 16/600 16.1 | [D16G600] | 01.2009- |
| VOLVO | FH 16/600 16.1 | [D16G600] | 05.2012- |
| VOLVO | FH 16/600 16.1 | [D16G600] | 09.2006- |
| VOLVO | FH 16/610 16.1 | [D16C610] | 01.2003- |
| VOLVO | FH 16/610 16.1 | [D16C610] | 08.2007- |
| VOLVO | FH 16/660 16.1 | [D16E660] | 09.2006- |
| VOLVO | FH 16/700 16.1 | [D16G700] | 01.2009- |
| VOLVO | FH 16/700 16.1 | [D16G700] | 05.2012- |
| VOLVO | FH 16/700 16.1 | [D16G700] | 09.2006- |
| VOLVO | FH 16/750 16.1 | [D16G750] | 05.2012- |
| VOLVO | FH 550 16.1 | [D16C550] | 09.2005- |
| VOLVO | FH 610 16.1 | [D16C610] | 09.2005- |
Reference Information
8198 M9T82671AM 11129448 DRS0319X 20732404 8EA012586-221 85000526 336527 M009T82671AM ANM12539X 811.510.123.370 DRS0319 811.510.123.010 PRSL313 M9T82672 M9T82671 811.510.123.130 85000586 0001330057 773 85000295 114310 M009T82071AM LRS02297 M9T82071AM F042S01211 LRS2297 STM1451 S5149 STM1249 20450305 M009T82672 M009T82671 MS UD01726S 45-3468 STR5203 0986024990 22809631 IS9469 220570 88212743 22809736 STRL313 19831N 130-90153Video/Publications
