Information
M2T88572Associated Numbers
05033125AA 05033125AB 114237 12015 22.1481 22.3237 25-3451 254031 32690N 3664 5033125AA 5033125AB 6035162 8080355 88214200 AEY2280 CS1481 CST35162 CST35162AS CST35162ES CST35162GS CST35162OS CST35162RS DRS0119 LRS02280 M002T88571 M002T88572 M2T88571 M2T88572 UD02149S
DXS504 BXS0115 70-6067
05033125AA Chrysler
05033125AB Chrysler
0986024380 Bosch ruil
103398a
11040773 EuroTec
11090188 EuroTec
114144 Cargo
114237 Cargo
12015 EAI
12138 EAI
253231 Elstock
253451 Elstock
32690 Lester
32691 Lester
3664 CEVAM
5033125AA Chrysler
5033125AB Chrysler
670010122 DRI
670013122 DRI
830572112 PSH
910081 EDR
A78540 ATL
CS1481 HC
DRS0081 Remy
drs0119 Remy
KRLX33125AB Chrysler
LRS01685 Lucas
LRS02280 Lucas
LRS1685 Lucas
M002T88571 Mitsubishi show
M002T88572 Mitsubishi show
M002T88572ZC Mitsubishi
M2T88571 Mitsubishi show
M2T88571SEL +line
M2T88572 Mitsubishi show
M2T88572ZC Mitsubishi
RLX33125AB Chrysler
STR5177sa Electrolog
STR5411SA Electrolog
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 228 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 25.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | PT Cruiser 2.2 CRD | [EDJ] | 08.2005- |
| CHRYSLER | PT Cruiser 2.2 Diesel | [EDJ] | 03.2002- |
| JEEP | Grand Cherokee 2.7 CRD 4x4 | [ENF] | 10.2001- |
Reference Information
220717 88214200 PRSS168 STR5411 LRS02280 220710 KRLX33125AB STM4144 22.3237 LES0398 05033125AB 05033125AA 106330 M002T88571 SKSTR-0330168 22.1481 M002T88572 S5155 AC-CBS1481 STX200492R M002T88572ZC CS1481 ANM12339X LRS2280 CST35162GS STRS168 RLX33125AB 803-10042 10439574 670013122 11040773 CMA-621211 SMI162A UD02149S S512180 254031 CST35162RS 6035162.0 8080355 220710A DRS0119 20437261OE 0986024380 6035162.1 6035162.2 A78545 10035162AV 12015 3126264 AEY2280 830.572.112.130 32690N M2T88572ZC 20437261BN 5033125AB 114237 5033125AA J5210800 015ST21 S12MH0308A2 STX200492 MAV371620 20437261RC M2T88571 3664 M2T88572 ST01482 CST35162AS 25-3451Video/Publications
