Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 692.76 including GST
NZ$ 602.40 excluding GST
or four payments of $173.19
with
Learn More
each
S5174
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M9T83071Associated Numbers
103-5119 20437736OE 254705 254705M 51.26201-7206 51.26201-9231 51.26201.7231 51262017231 551.535.123 6035637 CS1551 CST35637 CST35637AS CST35637ES CST35637GS CST35637OS CST35637RS DRS0543 DRS0543N M009T82771 M009T83071 M009T83071AM M9T82771 M9T83071 M9T83071AM MITM9T83071 S5174 UD90045SSpecifications
| Kilowatt | 7 kW |
| Length (L.1) | 349 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 14 mm |
| Mount Hole Diameter (C.3) | 14 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAN | 18.440 12.4 | [D2676LF..] | 01.2007- |
| MAN | 18.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 18.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 18.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 18.540 12.4 | [D2676LF13] | 01.2006- |
| MAN | 19.440 12.4 | [D2676LF..] | 01.2006- |
| MAN | 19.440 12.4 | [D2676LF..] | 01.2011- |
| MAN | 19.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 19.480 12.4 | [D2676LF..] | 01.2011- |
| MAN | 24.440 12.4 | [D2676LF..] | 01.2007- |
| MAN | 24.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 24.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 24.540 12.4 | [D2676LF..] | 01.2006- |
| MAN | 26.440 12.4 | [D2676LF..] | 01.2008- |
| MAN | 26.440 12.4 | [D2676LF04] | 01.2006- |
| MAN | 26.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 26.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 26.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 26.540 12.4 | [D2676LF13] | 01.2006- |
| MAN | 27.440 12.4 | [D2676LF04] | 01.2008- |
| MAN | 28.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 28.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 28.480 12.4 | [D2676LF..] | 01.2008- |
| MAN | 28.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 28.540 12.4 | [D2676LF13] | 01.2006- |
| MAN | 32.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 32.480 12.4 | [D2676LF..] | 01.2008- |
| MAN | 33.440 12.4 | [D2676LF04] | 01.2007- |
| MAN | 33.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 33.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 33.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 33.540 12.4 | [D2676LF..] | 01.2009- |
| MAN | 35.360 10.5 | [D2066LF..] | 01.2006- |
| MAN | 35.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 35.480 12.4 | [D2676LF..] | 01.2008- |
| MAN | 35.480 12.4 | [D2676LF05] | 01.2006- |
| MAN | 35.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 35.540 12.4 | [D2676LF..] | 01.2008- |
| MAN | 37.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 37.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 37.540 12.4 | [D2676LF..] | 01.2007- |
| MAN | 39.480 12.4 | [D2676LF05] | 01.2006- |
| MAN | 40.440 12.4 | [D2676LF..] | 01.2011- |
| MAN | 41.440 12.4 | [D2676LF04] | 01.2007- |
| MAN | 41.480 12.4 | [D2676LF..] | 01.2006- |
| MAN | 41.480 12.4 | [D2676LF..] | 01.2007- |
| MAN | 41.540 12.4 | [D2676LF..] | 01.2007- |
Reference Information
M9T88571 51.26101-7206 51.26201-7206 M988571AM STR5215 M9T83071AM MITM9T88571 20437736BN 115440 F042S01213 M009T88571AM 20437736OE 0986025250 336471 11.139.614 551.535.123.138 103-5119 551.535.123.130 551.535.123.370 M009T88571 CST35637GS MITM9T83071 ANM12763 LRS4069 51.26201-9231 UD90045S M009T83071AM 6035637.1 6035637.0 DRS0543N M009T83071 CS1551 M9T82771 45-5232 M9T88571AM 72444501 33248N 551.535.123.310 STR71250 STRL763 254705 M009T82771 M9T83071 S5174 MS781 F042001213 CST35637AS M988571 DRS0543 254705V LRS04069 220571 130-90158 AZG4864 IS9466 254705M 51.26201-7231Video/Publications
