Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 264.89 including GST
NZ$ 230.34 excluding GST
or four payments of $66.22
with
Learn More
each
S5288S
2
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M0T38071Associated Numbers
116270 25-4233 31100-51K10 31100-61MA0 31100-73K10 88214378 9766 AEY2561 DRS0644 J5218033 J5218034 LRS02561 M000T38071 M000T38071ZE M000TF0071 M000TF0072 M000TF0073 M0T38071 M0T38071ZE M0TF0071 M0TF0072 M0TF0073 MITM0T38071 UD14919SSpecifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Splash 1.2 VVT | [K12B] | 01.2011- |
| SUZUKI | Swift 1.2 | [K12B] | 01.2010- |
| SUZUKI | Swift 1.2 4x4 | [K12B] | 01.2012- |
| SUZUKI | SX4 S-Cross 1.6 | [M16A] | 01.2013- |
| SUZUKI | SX4 S-Cross 1.6 AllGrip | [M16A] | 01.2013- |
| SUZUKI | Vitara 1.4 T | [K14C] | 01.2015- |
| SUZUKI | Vitara 1.6 | [M16A] | 01.2015- |
Reference Information
CST35356AS AEY2561 MAV373560A 9766 UD14919S M0TD0871 M000TF0073 M000TF0072 S5288S STR5457 M000TD0871ZE M0TD0871ZE 31100-61P00 95507894 31100-73K10 M0T38071 25-4233 M000TF0071 4711566 116270 M000TD871 J5218033 M0TF0071 J5218034 STRF701 88214378 20437653OE 6035356.0 6035356.1 M0T38071ZE M000T38071ZE 1202505 31100-60P00 31100-61MA0 20437653BN 31100-51K10 95520338 DRS0644 LRS02561 MITM0T38071 LRS2561 M000T38071 CST35356GS M0TF0073 M0TF0072Video/Publications
