Associated Numbers
M0T32371 UD20420S 04608800AE 4608800AE S-80365 25-5178 STM3272 LRS04016 M000T32371 M000T32371ZC M0T32371ZC 150.914.103 19026N 19026R 91-27-3444 91-27-3444N STR71292
Arrowhead SMT0343
Chrysler 04608800AE, 4608800AE
Denso 2804274
Lester 19026
Mitsubishi M0T32371, M0T32371ZC
Remy Light Duty 16101
Wilson 91273444
J&N 41048151
Remy Light Duty 16101
References:
J&N 41048151
Chrysler 04608800AE
Lester 19026
Mitsubishi M000T32371, M000T32371ZC, M0T32371ZC
Remy Light Duty 16101
706217 04608800AE Chrysler
1035032C PIC
150914103 PSH
19026 Lester
19026N WAI
19026R WAI
23257MI WAI
255178 Elstock
4608800AE Chrysler
7B0911023A VW
LRS04016 Lucas
M000T32371 Mitsubishi
M0T32371 Mitsubishi
M0T32371ZC Mitsubishi
M900708 DuBois
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 207 mm |
| Mount Hole Center - Center (O.1) | 113 mm |
| Mount Hole Center - Center (O.2) | 71 mm |
| Mount Hole Center - Center (O.3) | 67 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 7 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Grand Voyager V 4.0 | [EMM] | 01.2007- |
| CHRYSLER | Sebring 2.4 VVT | [EER] | 01.2006- |
| CHRYSLER | Sebring 2.7 WT | [EER] | 01.2007-12.2010 |
| DODGE | Avenger 2.7 | [EER] | 01.2007- |
| DODGE | Journey 2.7 | [EER] | 01.2009- |
Reference Information
STR5419 M0T32371ZC M000T32371ZC MAV373940A 7B0911023A 19026R 6035394 LRS04016 UD20420S 19026N STM3272 150.914.103 91-27-3444 STR71292 20437493BN S-80365 4608800AE LRS4016 M0T32371 M000T32371 04608800AE S5404S CST35394AS 25-5178 STRF410 91-27-3444NVideo/Publications
