Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 308.94 including GST
NZ$ 268.64 excluding GST
or four payments of $77.24
with
Learn More
each
S6002
2
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
1280000040Associated Numbers
03101-3050 03101-3051 0986014101 0986014971 0K71118400 0K71118400A 0K71118400C 0K71F18400B 0R20118400 0R20118400B 110389 11462 11561 128000-0040 140.506.093 140.510.093 140.527.103 16857R 1EM0049 20365 20428701OE 20432501BN 20500625 20513031 22.5365 22.5365M 228000-3840 228000-3841 228000-3842 25-0446 25-0497 31100-77E90 31354N 31354R 455592 455605 6040105 6041107 8052316 8212936 88212936 8EA011610-821 8EA726456-001 943241015010 944280523160 9672 AES6125 AES6126 AET0365 CST40105 CST40105AS CST40105ES CST40105GS CST40105OS CST40105RS CST41107 CST41107AS CST41107ES CST41107GS CST41107OS CST41107RS DRS4971 EAA-121102 GS000040-A J5213016 JS365 K711-18-400C LRS00625 LRS00626 LRS01113 M002T32071 M002T92071 M002T92071A M2T32071 M2T92071 M2T92071A M32909 MG122404 OK711-18-400 OK71118400 OK71118400A OK71118400C OK71F18400B OR20118400 OR20118400B R201-18-400 R201-18-400A R201-18-400B R201-18-400C R201-18-400D R201-18-400EX R201-18-400R R201-18-400Z RF01-18-400 RF01-18-400A RF01-18-400B RF01-18-400C RF01-18-400E RFL1-18-400 RFL1-18-400A S6002 SG0275 SS073 SS558 SS804 STR5005 STR70077 STR71008 TM000A06701 TM000A06901 dxs440 mxs221 16-162 16162 snj005 708562Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 231 mm |
| Mount Hole Center - Center (O.1) | 130 mm |
| Mount Hole Center - Center (O.2) | 83 mm |
| Mount Hole Center - Center (O.3) | 89 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | M12x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9. 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 6 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 88 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ASIA MOTORS | Rocsta 2.2 D 4x4 | [R2] | 06.1993- |
| FORD | Econovan 2.0 D | [RF] | 01.1986-12.1999 |
| FORD | Econovan 2.0 Diesel | [RF] | 09.1985-03.1992 |
| KIA | Besta 2.2 D | [R2] | 02.1996- |
| KIA | Besta 2.2 Diesel | [R2] | 02.1996- |
| KIA | Retona 2.0 TD | [RF] | 06.1999- |
| KIA | Sportage 2.0 TD | [RF] | 01.1996-12.2002 |
| KIA | Sportage 2.0 TD 4WD | [RF] | 10.1997-08.2004 |
| KIA | Sportage 2.2 D 4WD | 08.1994-04.1999 | |
| MAZDA | 323 2.0 D | [RF] | 01.1996-12.1998 |
| MAZDA | 323 2.0 DiTD | [RF] | 01.1998- |
| MAZDA | 323 2.0 DiTD | [RF] | 01.2000- |
| MAZDA | 323 2.0 TD | [RF] | 09.1998-01.2001 |
| MAZDA | 626 2.0 | 01.1983-01.1983 | |
| MAZDA | 626 2.0 | 01.1984-01.1985 | |
| MAZDA | 626 2.0 | 01.1986-01.1987 | |
| MAZDA | 626 2.0 D | [RF46] | 01.1982-12.1987 |
| MAZDA | 626 2.0 D | [RF46] | 03.1984-06.1987 |
| MAZDA | 626 2.0 D | [RF-N] | 09.1988-07.1991 |
| MAZDA | 626 2.0 D Comprex | [RF] | 01.1992-12.1997 |
| MAZDA | 626 2.0 D GLX Comprex | [RFOHC] | 01.1993-04.1997 |
| MAZDA | 626 2.0 D GLX Comprex | [RFOHC] | 10.1992-04.1997 |
| MAZDA | 626 2.0 Diesel | [RF46] | 01.1983-06.1987 |
| MAZDA | 626 2.0 Diesel | [RF-N] | 09.1988-02.1998 |
| MAZDA | 626 2.0 Diesel Comprex | [RF-CX] | 05.1993-10.1997 |
| MAZDA | 626 2.0 DiTD | [RF3F] | 01.1998-12.2002 |
| MAZDA | 626 2.0 TDDi | [RF3F] | 04.1998-10.2002 |
| MAZDA | 626 2.0 Turbo | 01.1986-01.1987 | |
| MAZDA | B2200 2.2 D | [R290] | 01.1985-12.1996 |
| MAZDA | B 2200 2.2 Diesel | [R290] | 12.1989-03.1996 |
| MAZDA | E2000 2.2 D | [FE..] | 01.1984-12.1988 |
| MAZDA | E 2200 2.2 D | [R203] | 03.1991- |
| MAZDA | E 2200 2.2 D | [R207] | 01.1984-02.1988 |
| MAZDA | E 2200 2.2 D | [R207] | 03.1991- |
| MAZDA | E2200 2.2 D | [R21N] | 01.1999-12.2004 |
| MAZDA | E 2200 2.2 D 4WD | [R207] | 03.1991- |
| MAZDA | E 2200 2.2 Diesel | [R203] | 01.1984- |
| MAZDA | E 2200 2.2 Diesel | [R207] | 01.1984- |
| MAZDA | E 2200 2.2 Diesel 4WD | [R203] | 03.1991- |
| MAZDA | E 2200 2.2 Diesel 4WD | [R207] | 03.1991- |
| SUZUKI | Grand Vitara 2.0 TD Intercooler | [RF] | 03.1998- |
| SUZUKI | Vitara 2.0 D 4WD | [RF] | 12.1994-03.1998 |
| SUZUKI | Vitara 2.0 TD Intercooler 4WD | [RF] | 12.1995-03.1998 |
Reference Information
M2T92071 110389 455592 CST40105ES M2T92071A K711-18-400C 3M200 31354N CST41107RS 3110077E90000 31354R 335215 140.510.093 88212936 SS073 SG0275 220084 LRS625 LRS626 11462 0R20118400B CST41107AS 22.5365 RFL1-18-400A M002T32071 OK71F18400B 220342 25-0446 CST41107 M002T92071 J5213016 STR71008 MTM931 CST40105OS R201-18-400EX 0K71118400 STX200247R 3110077E90 RFL1-18-400 3110077E91 MTM200 3110077E96 CST40105 003-M931 20432501BN CST41107GS 11561 3110077E97 AET0365 M32909 STX200247 OK05818400 SS804 TM000A06901 STR6019 03101-3051 OK711-18-400 03101-3050 CST41107OS 3M931 JS365 8EA726456-001 943241015010 R201-18-400 1516962R STRS027 CGB-24971 LRS00626 LRS00625 R201184009R 8EA011610-821 SS558 MAV6000 944280523160 CST40105AS GS000040-A MG122404 6041107 CST41107ES M002M92071 RF0118400EX 25-0497 22.5365M CST40105RS 003-M200 8212936 OR20118400 DRS4971 RF0118400A9R 0986014971 LRS1113 STA0393R 9672 RF01-18-400 ANM17191X 31100-77E91-000 8052316 S6002 140.527.103 OR20118400B AA30118400 23300-HC300 AES6126 STR70077 AES6125 M2M92071 23300HC300 0R20118400 1EM0049 OK71118400 0986014101 228000-3842 128000-0040 CST40105GS 31100-77E90 31100-77E91 R201-18-400-9R RF01-18-400E RF01-18-400B 140.506.093 RF01-18-400C RF01-18-400A AA301-18400 228000-3841 31100-77E96 228000-3840 31100-77E97 31100-77E90-000 M2T32071 0K71F18400B RF01-18-400A-9R 455605 R201-18-400Z 20428701OE 0K71118400C 0K71118400B 0K71118400A R201-18-400R 20365 STR5005 TM000A06701 140.527.103.415 6040105 16857R 3110077E91000 OK71118400A 336435 LRS01113 OK71118400C R201-18-400B R201-18-400C R201-18-400D 20500625 M002T92071A R201-18-400AVideo/Publications
