Associated Numbers
015957W 112036 128000-0970 128000-4110 128000-4111 128000-4113 17290N 17311N 20432721BN 254056 28300-23040 28300-23040-71 28300-23041 28300-23041-71 6040127 8076 8213373 CST40127 CST40127AS CST40127ES CST40127GS CST40127OS CST40127RS S-8512 STR6073 UD02113S UD12959S
28100-40291
DXS521 SNJ034 70-8568 16-014
ARROWHEAD ND280-7005, SND0138, SND0418
DENS O128000-0970, 128000-0971, 128000-0972, 128000-0973, 128000-0974, 128000-4110, 128000-4111, 128000-4112, 128000-4113, 228000-3710, 228000-3711, 280-7005, AS128000-4113
HYSTER 3049479
J&N ELECTRICAL PRODUCTS 410-52008
JANNCO 410-52008R
LESTER 17290, 17311
LUCAS ELECTRIC LRS01447
OTHER OEMS STR6053
015957W Andre Niermann
104401 FARC
11040824 EuroTec
112036 Cargo
113238 Cargo
1280000970 Denso
1280000971 Denso show
1280000972 Denso show
1280000973 Denso show
1280000974 Denso
1280004110 Denso show
1280004111 Denso show
1280004112 Denso show
1280004113 Denso
1280006910 Denso show
1280006911 Denso
1280006912 Denso
1280804113 Denso
17311 Lester
190534112 PSH
2280003710 Denso show
2280003711 Denso
2280803711 Denso
252373 Elstock
2810023600 Toyota
2810023660 Toyota
281002366071 Toyota
2810023671 Toyota
2810040290 Toyota
281004029071 Toyota
2810040291 Toyota
281004029171 Toyota
2830023040 Toyota
283002304071 Toyota
2830023041 Toyota
283002304171 Toyota
3049479 Hyster
635004112 DRI
8076 CEVAM
91295231 Wilson
91295234 Wilson
91295234N Wilson
91295320 Wilson
A78130 ATL
ATS208 ATK
ATS240 ATK
DEMR211 ADI
DRS0812 Remy
DSN2111 Denso
DSN2112 Denso
F042000072 Bosch
F042S00072 Bosch
LRS01447 Lucas
LRS1447 Lucas
MS910 Mahle
STR6035sa Electrolog
STR6073 Unipoint
TRS078 TWA
TOYOTA 8100-23660-71, 28100-40290, 28100-40290-71, 28100-40291, 28100-40291-71, 28300-23040, 28300-23041, 28300-23041-71
Specifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 297 mm |
| Mount Hole Center - Center (O.1) | 114 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 14 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 16 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 90 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
| Wet Clutch | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 7FD20 | 01.1998- | |
| TOYOTA | 7FD23 | 01.1998- |
Reference Information
CST40127GS 28100-40291-71 CST40127ES CST40127 28300-23040 3049479 CST40127AS 8213373 STR6802 8076 28300-23041 CGB-8512 2810023660 CST40127RS MAV421270 UD02113S 28300-23041-71 S6117 2.81002E+11 UD12959S 128000-4111 128000-0970 128000-4110 112036 128000-4113 6040127 S-8512 2810040291 2810040290 STR6035 254056 20432721BN 17290N CST40127OS 2.81004E+11 28300-23040-71 17311N 015957W STR6073Video/Publications
