Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 459.57 including GST
NZ$ 399.63 excluding GST
or four payments of $114.89
with
Learn More
each
S6026
S6139
2
Associated Numbers
0986023840 112366 191.505.122 201217 20432626BN 20432626OE 22.1217 22800 0-598 0 228000-5981 28100-17050 45-2482 6040626 8023840 8212722 8EA737843-001 AET1217 CST40626 CST40626AS CST40626ES CST40626GS CST40626OS CST40626RS DRS3858 DSN1228 EAA-152761 LRS01934 STR70383 UD30039S dxs482 SNJ019 708572 Bosch ruil 11040637 EuroTec 12060 EAI 191514122 PSH 2280005980 Denso 2280005981 452482 Valeo 4652SP Spidan 913858 EDR Remy HJS1217 HC JS1217 Lucas OSM11574 Optimum AS-PL AUTOELECTRO BOSCH CARGO CASCO DELCO DENSO EAA ELSTOCK FRIESEN HELLA KUHNER LAUBER LUCAS POWERMAX REAL SANDO 228000-5980 TOYOTA TOYOTAList WOODAUTO 16036 16-036 Cargo 20130048 AES show 2280805982 2810017050 Toyota 2810017051 Elstock DENDSN1228 Wood Auto LRS1934 RNL2280005980 RNL RNL2280005980T WOOSTR70383Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 295 mm |
| Mount Hole Center - Center (O.1) | 142 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 16 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 91 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Land Cruiser 4.2 TD | [1HD-FT] | 01.1996-12.1998 |
Reference Information
CST40626ES UD30039S CST40626 CST40626AS 8023840 8212722 112366 201217 228000-5981 228000-5980 28100-17050 CST40626GS 45-2482 CST40626RS STR6046 8EA737843-001 MAV426260 191.505.122 22.1217 STR70383 AET1217 ANM16078X 6040626 DSN1228 20432626OE DRS3858 CST40626OS LRS1934 LRS01934 20432626BN EAA-152761 2810017080 0986023840Video/Publications
