Associated Numbers
28100-23060 428000-2140 S6170 UD12045S
2810023061, 28100-23061, 28100 23061
4280002140 4280002141 4280002142
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 202 mm |
| Mount Hole Center - Center (O.1) | 129 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 11.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Yaris 1.3 | 01.2006-12.2011 |
Reference Information
428000-2140 UD12045S 28100-23060 S6170Video/Publications
