Associated Numbers
10465536 18342N 18342R 228000-5000 228000-5001 228000-5002 228000-5003 228000-5050 228000-5051 246-30207 254348 254348C 3282626 3675249RX 3957596 45-5042 600-863-5110 600-863-5111 6040610 91-29-5425 91-29-5425N CST40610 CST40610AS CST40610ES CST40610GS CST40610OS CST40610RS DRS0258 LRS03879 STR70072 STR70098 UD13182S
16-646
Specifications
| Kilowatt | 5.5 kW |
| Length (L.1) | 316 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 12.5 mm |
| Mount Hole Diameter (C.2) | 12.5 mm |
| Mount Hole Diameter (C.3) | 12.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Various Models 5.9 | [B6T-590] | |
| KOMATSU | D39EX-21 | [SAA4D102E] | 01.2001-12.2011 |
| KOMATSU | D39PX-21 | [SAA4D102E] | 01.2001-12.2011 |
| KOMATSU | Engine | [6B] | 01.1995-12.1995 |
| KOMATSU | Engine 6.5 | [6D105] | |
| KOMATSU | PC220LC | [6D105] | 01.1996-12.2006 |
| KOMATSU | PC220LC 6.5 | [6D105] | 01.1996-12.2006 |
| KOMATSU | WA380-6 | [SAA6D107E-1] | 01.2006-12.2015 |
Reference Information
S24DE0129 187566C1 228000-5002 228000-5003 228000-5000 1987566C1 228000-5001 254348 114693 UD13182S DRS0258 600-863-5111 600-863-5110 S24DE0129A2 3282626 CST40610OS CST40610AS 254348C 6738-82-6810 45-5042 18342R CST40610ES LRS3879 91-29-5425 CST40610GS CST40610 3957596 18342N CST40610RS 228000-5050 STR70098 6040610 10465536 228000-5051 91-29-5425N STR70072 3924466 246-30207 D129494 MAV426170 LRS03879 D129474 S6205 3675249RX STR6270Video/Publications
