Associated Numbers
12293 220831 25-4214 254468 254468D 30180R 428000-1931 428000-1932 428000-4890 428000-4891 428000-4892 4R83-11001-AC 4R83-11001-AD 6040385 840.506.092 88214452 8X23-11001-AA 8X23-11001-AB 8X23-11001-AC 8X23-11001-AD AEY2542 C2C15283 C2C32959 C2D27865 C2D51168 C2Z6560 CST40385 CST40385AS CST40385ES CST40385GS CST40385OS CST40385RS DENDSN1300 DRS0738 DSN1300 LRS02542 STN5283 UD13775S
snj298
WAI New 30180N
Alltech 126-30180
American Power Systems APS30180
Armature G Roy 30180
Atelier Dynamo S190-652
Auto Electric Suppliers 20.130.026
Autoelectro AEY2542
CASCO CST40385GS
Denso 428000-1930, 428000-1931, 428000-1932
Denso Europe DSN1300
DRI A/S Denmark 314048092
EGI S-30180
ERA 220831
Jaguar 4R83-11001-AC, 4R83-11001-AD, C2C15283, C2C32959
Lester 30180
Lucas Electrical Europe LRS02542
Mondial 70-956-20
Our Part Number 30180N
Part # 30180
Power Select 30180N
Powerite Automotive 30180
Quality Rebuilders 130180
Raw Power 30180N
Road Warrior 30180N
Sovereign SS750
Wood Auto Supplies DENDSN1300, STR70318
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 240 mm |
| Mount Hole Center - Center (O.1) | 130 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 25 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JAGUAR | S-Type 2.7 D V6 | [AJD] | 06.2004-10.2007 |
| JAGUAR | XF 2.7 D V6 | [AJD] | 03.2008-04.2015 |
| JAGUAR | XF 2.7 TD V6 | [AJD] | 01.2008- |
| JAGUAR | XF 3.0 D V6 | [306DT] | 03.2009-04.2015 |
| JAGUAR | XF 3.0 D V6 | [AJV6D] | 03.2009-04.2015 |
| JAGUAR | XF 3.0 TD V6 | [AJV6D] | 01.2009- |
| JAGUAR | XF Sportbrake 3.0 D V6 | [306DT] | 09.2012-04.2014 |
| JAGUAR | XF Sportbrake 3.0 D V6 | [AJV6D] | 09.2012-04.2014 |
| JAGUAR | XJ 2.7 D V6 | [AJD] | 10.2005-03.2009 |
| JAGUAR | XJ 3.0 D V6 | [AJV6D] | 10.2009-12.2015 |
| JAGUAR | XJ6 2.7 TD V6 | [AJD] | 01.2005-12.2009 |
| JAGUAR | XJ6 3.0 TD V6 | [AJV6D] | 01.2009- |
Reference Information
12293 254468D 840.506.092 C2Z6560 STN5283 AEY2542 STX210344 DRS0738 CST40385 220831 DENDSN1300 4R83-11001-AD 254468 25-4214 4R83-11001-AC C2D51168 CST40385OS 8X23-11001-AB 8X23-11001-AA 8X23-11001-AD 6040385 8X23-11001-AC C2D27865 CST40385GS 428000-1932 CST40385ES 428000-1931 88214452 30180N CST40385AS 30180R STX210344R C2C32959 DSN1300 STR6438 428000-4891 336588 CST40385RS 428000-4890 LRS02542 C2C15283 428000-4892 UD13775S LRS2542Video/Publications
