Associated Numbers
115982 12186 220828 25-4006 254331 254331D 254331R 3135 33334R 428000-4610 428000-4611 428000-4612 428000-9510 450.519.112 6040266 7H42-11001-AB 7H42-11001-AC 88214518 AEY2334 CPLA-11001-AC CST40266 CST40266AS CST40266ES CST40266GS CST40266OS CST40266RS DENDSN1207 DRS0485 DSN1207 EAA-122872 LR010512 LR021461 LR029152 LR032541 LRS02334 LRS2334 NAD500280 RAS31596 S6264S STN4611 STR70217 UD13192S
16-556
16-556
S6264S ASPLList
UD13192S ASPL
AEY2334 AUTOELECTRO
115982 CARGO
CST40266 CASCO
CST40266AS CASCO
CST40266ES CASCO
CST40266GS CASCO
CST40266OS CASCO
CST40266RS CASCO
3135 CEVAM
DRS0485 DELCO
RAS31596 DELCO
4280004610 DENSO
4280004611 DENSO
4280004612 DENSO
4280009510 DENSO
DSN1207 DENSO
EAA122872 EAA
12186 EAI
254006 ELSTOCK
220828 ERA
7H4211001AB FORD
7H4211001AC FORD
STN4611 KRAUF
254331 KUHNER
254331D KUHNER
254331R KUHNER
LRS02334 LUCAS
LRS2334 LUCAS
88214518 POWERMAX
450.519.112 PSH
CPLA11001AC ROVER
LR010512 ROVER
LR021461 ROVER
LR029152 ROVER
LR032541 ROVER
NAD500280 ROVER
6040266 SANDO
33334R WAI / TRANSPO
DENDSN1207 WOODAUTO
STR70217 WOODAUTO
11040782 EuroTec
12186 EAI
254006 Elstock
33334N WAI
33334R WAI
4280004610 Denso
4280004611 Denso
4280004612 Denso
450519112 PSH
7H4211001AB Ford
7H4211001AC Ford
8080256F Friesen
910485 EDR
A78440 ATL
DRS0485 Remy
DSN1207 Denso
LR032541 Rover Group
LRS02334 Lucas
NAD500280 Rover Group
STR6171sa Electrolog
TNS013 TWA
16-556
S6264S ASPLList
UD13192S ASPL
AEY2334 AUTOELECTRO
115982 CARGO
CST40266 CASCO
CST40266AS CASCO
CST40266ES CASCO
CST40266GS CASCO
CST40266OS CASCO
CST40266RS CASCO
3135 CEVAM
DRS0485 DELCO
RAS31596 DELCO
4280004610 DENSO
4280004611 DENSO
4280004612 DENSO
4280009510 DENSO
DSN1207 DENSO
EAA122872 EAA
12186 EAI
254006 ELSTOCK
220828 ERA
7H4211001AB FORD
7H4211001AC FORD
STN4611 KRAUF
254331 KUHNER
254331D KUHNER
254331R KUHNER
LRS02334 LUCAS
LRS2334 LUCAS
88214518 POWERMAX
450.519.112 PSH
CPLA11001AC ROVER
LR010512 ROVER
LR021461 ROVER
LR029152 ROVER
LR032541 ROVER
NAD500280 ROVER
6040266 SANDO
33334R WAI / TRANSPO
DENDSN1207 WOODAUTO
STR70217 WOODAUTO
11040782 EuroTec
12186 EAI
254006 Elstock
33334N WAI
33334R WAI
4280004610 Denso
4280004611 Denso
4280004612 Denso
450519112 PSH
7H4211001AB Ford
7H4211001AC Ford
8080256F Friesen
910485 EDR
A78440 ATL
DRS0485 Remy
DSN1207 Denso
LR032541 Rover Group
LRS02334 Lucas
NAD500280 Rover Group
STR6171sa Electrolog
TNS013 TWA
Specifications
| Kilowatt | 2.7 kW |
| Length (L.1) | 278 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 17.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 80 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Range Rover 3.6 D 4x4 | [368DT] | 04.2006-08.2012 |
| LAND ROVER | Range Rover 4.4 D 4x4 | [448DT] | 07.2010-08.2012 |
| LAND ROVER | Range Rover Sport 3.6 D 4x4 | [368DT] | 04.2006-03.2013 |
Reference Information
7H42-11001-AC 7H42-11001-AB CPLA-11001-AC STN1512 6040266 6040266.1 S6264S UD13192S CST40266AS 88214518 STRL668 LRS2334 NAD500280 AEY2334 220828 LR010512 PRSL668 DSN1207 EAA-122872 CST40266GS 254331R 33334R 254331 25-4006 33334N 450.519.112.260 428000-4612 254331D 428000-4611 DRS0485 428000-4610 DENDSN1207 STX210288R STX210288 LRS02334 115982 3135 336097 LR029152 20432662BN 12186 450.519.112.050 RAS31596 LR032541 STR70217 428080-4612 LR021461 STR6171 20432662OEVideo/Publications
S6264SView your shopping basket or Browse other items in Starter Motors.
