Associated Numbers
0-23000-1750 0-23000-1752 600-813-3320 600-813-4400 600-813-4421 600-813-4422 600-813-6210 8512 JS750 S9034 STK0750 STK8750
NXS9706 DXS523 SNJ138 SNJ138GQ 70-8565 70-8817-1 70-8817G
0-23000-2565
Wilson 91-28-4013
References:
Komatsu 600-813-3320, 600-813-4420, 600-813-4421, 600-813-4422, 600-813-4423, 600-813-4424, 600-813-4425, 600-813-4450
Lester 18104
Nikko 0-23000-1290, 0-23000-1291, 0-23000-1292, 0-23000-1750, 0-23000-1751, 0-23000-1752, 0-23000-2560, 0-23000-2561, 0-23000-2564, 0-23000-2565, 02-23-2000
PIC Picture ID 185-204, 185-204A, 185-209
Wilson 91-28-4012, 91-28-4013, 91-28-4020
J&N 410-50003
Nikko 0-23000-2565
References:
J&N 410-50003
Komatsu 600-813-4420, 600-813-4421, 600-813-4422, 600-813-4423
Lester 18104
Nikko 0-23000-1750, 0-23000-1751, 0-23000-1752, 0-23000-2560, 0-23000-2561, 02-23-2000
PIC Picture ID 185-204
0-23000-1750, 0-23000-1752, 0-23000-2560, 0-23000-2561, 0-23000-2564, 02-23-2000
Substitutes:
J&N 410-50003
References:
J&N 410-50003
Komatsu 600-813-4425
Nikko 0-23000-2561
Wilson 91-28-4013
Specifications
| Kilowatt | 5.5 kW |
| Length (L.1) | 368 mm |
| Mount Hole Center - Center (O.1) | 150 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 13 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | NIKKO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KOMATSU | D31 | [4D105] | |
| KOMATSU | D31 | [6D95L] | |
| KOMATSU | D31A | [4D105] | |
| KOMATSU | D31A | [6D95L] | |
| KOMATSU | D31P | [4D105] | |
| KOMATSU | D31P | [6D95L] | |
| KOMATSU | D31S | [4D105] | |
| KOMATSU | D31S | ||
| KOMATSU | GD305 | ||
| KOMATSU | GD305-1 | ||
| KOMATSU | GD305A-1 | ||
| KOMATSU | GD313A-1 | ||
| KOMATSU | GD355A-1 | ||
| KOMATSU | GD405 | ||
| KOMATSU | GD405-2 | ||
| KOMATSU | GD405A-2 | ||
| KOMATSU | GD461 | ||
| KOMATSU | GD461A-1 | ||
| KOMATSU | GD510R-1 | ||
| KOMATSU | GD511-1 | ||
| KOMATSU | GD511A-1 | ||
| KOMATSU | PC100 | ||
| KOMATSU | PC120 | [4D95] | |
| KOMATSU | PC120 | [6D95L] | |
| KOMATSU | PC120-3 | [4D95] | |
| KOMATSU | PC120-3 | [6D95L] | |
| KOMATSU | PC150 | [4D95] | |
| KOMATSU | PC150 | [6D95L] | |
| KOMATSU | PC150-3 | [4D95] | |
| KOMATSU | PC150-3 | [6D95L] | |
| KOMATSU | PC180-3 | [4D95] | |
| KOMATSU | PC180-3 | [6D95L] | |
| KOMATSU | PC200 | [4D95] | |
| KOMATSU | PC200 | [6D95L] | |
| KOMATSU | PC210-5 | [4D95] | |
| KOMATSU | PC210-5 | [6D95L] | |
| KOMATSU | PC210-5 | [SA6D95L] | |
| KOMATSU | PF3W-1 | [4D95] | |
| KOMATSU | PF3W-1 | [6D95L] | |
| KOMATSU | PW100-3 | [4D95] | |
| KOMATSU | PW100-3 | [6D95L] |
Reference Information
8512 0-23000-1752 0-23000-1750 S9034 JS750 600-813-6210 STK8750 CGB-91750 STR8851 600-813-4400 600-813-4422 600-813-4421 600-813-3320 STRS758 STK0750Video/Publications
