Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MAGNETON
Price:
NZ$ 351.33 including GST
NZ$ 305.50 excluding GST
or four payments of $87.83
with
Learn More
each
S9044
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
9142802Associated Numbers
110536 116086 8447 1178686 G380900060010 X830100001 01161384 01163669 01164668 01164994 01164995 01170052 01173240 01174166 01175886 01178026 1161384 1163669 1164668 1164994 1170052 1173240 1174166 1175886 1178026 B15R12X3H762 STB0103 STG0103 STP0103 STV0103 255424 8212960 560.001.093 6000102270 6000102394 6005001146 6005003155 6005003156 6005016395 105-10101 MGN9142802 9142802Specifications
| Kilowatt | 2.7 kW |
| Length (L.1) | 233 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9. 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 29 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 88 mm |
| Unit Type | MAGNETON |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DEUTZ-FAHR | D 6807 3.8 Diesel | [F4L912] | 06.1986- |
| DEUTZ-FAHR | D 7007 3.8 Diesel | [F4L912] | 06.1986- |
| DEUTZ-FAHR | DX 3.10 2.8 Diesel | [F3L912] | 06.1986- |
| DEUTZ-FAHR | DX 3.30 2.8 Diesel | [F3L912] | 06.1986- |
| DEUTZ-FAHR | DX 3.50 3.1 Diesel | [F3L913] | 06.1986- |
| DEUTZ-FAHR | DX 3.60 3.8 Diesel | [F4L912] | 06.1986- |
| DEUTZ-FAHR | DX 3.70 3.8 Diesel | [F4L912] | 06.1986- |
| DEUTZ-FAHR | DX 3.80 4.1 Diesel | [F3L913] | 06.1986- |
| DEUTZ-FAHR | DX 3.90 4.1 Diesel | [F3L913] | 06.1986- |
| DEUTZ-FAHR | DX 4.10 3.8 Diesel | [F4L912] | 06.1986- |
| DEUTZ-FAHR | DX 4.30 4.1 Diesel | [F3L913] | 06.1986- |
| DEUTZ-FAHR | DX 4.31 4.1 Diesel | [F3L913] | 01.1991- |
| DEUTZ-FAHR | DX 4.50 4.1 Diesel | [BF6L913T] | 06.1986- |
| DEUTZ-FAHR | DX 4.51 4.1 Diesel | [BF6L913] | 01.1990- |
| DEUTZ-FAHR | DX 4.70 4.1 Diesel | [BF6L913T] | 01.1992- |
| DEUTZ-FAHR | DX 6.05 5.7 Diesel | [F6L912] | 06.1986- |
| DEUTZ-FAHR | DX 6.10A Diesel | [F6L912] | 06.1986- |
| DEUTZ-FAHR | DX 6.30 6.1 Diesel | [F6L913] | 06.1986- |
| DEUTZ-FAHR | DX 6.31 6.0 Diesel | [BF6L913T] | 01.1990- |
| DEUTZ-FAHR | DX 6.50 6.1 Diesel | [BF6L913] | 06.1986- |
| DEUTZ-FAHR | DX 6.60 6.0 Diesel | [BF6L913] | 10.1988- |
| DEUTZ-FAHR | DX 7.10 6.1 Diesel | [BF6L913] | 06.1986- |
| DEUTZ-FAHR | Intrac 2003 3.8 | [F4L912H] | 08.1978-05.1980 |
| DEUTZ-FAHR | Intrac 2004 3.8 | [F4L912] | 05.1978-08.1982 |
| DEUTZ-FAHR | Intrac 630 | [F6L913] | 01.1988-12.1988 |
| DEUTZ-FAHR | Intrac 630 Turbo | [BF6L913T] | 01.1989- |
| DEUTZ-FAHR | M 1080 4.7 Diesel | [F5L912] | 01.1981- |
| DEUTZ-FAHR | M 1202 5.7 Diesel | [F5L912] | 01.1980- |
| DEUTZ-FAHR | M 2385 5.7 Diesel | [F5L912] | 01.1982- |
| DEUTZ-FAHR | M 3330 2.8 | [F3L912] | 01.1992- |
| DEUTZ-FAHR | M 3360 3.8 | [F5L912] | 03.1987- |
| DEUTZ-FAHR | M 980 3.8 Diesel | [F5L912] | 01.1981- |
Reference Information
01170052 01173240 G380900060010 S9044 05710991 05710992 05710917 1161384 X830100001 B28R12X4H7622 B15R12X3H762 STV0103 1164668 MAV3320 6005003156 6005003155 STP0103 110536 05710923 116086 9142802 STG0103 255424 560.001.093 1175726 01163669 42498132 1164994 1175886 01164994 605720100027 B13R12X4H7622 01164995 8212960 1301833 1163669 1178686 MAV2140 B23R12X3H7622 STRX764 B15R12X3H7622 01175726 V941501EX 01175886 01164668 105-10101 1174166 10430 1516652R 6107108 01174166 8447 01301833 05710905 05710901 6005016395 STB0103 CS114 MGN9142802 560.001.093.460 01161384 1516667R 1170052 6005001146 PTC-4032 6000102394 CGB-21143 6000102270 42522733 1173240Video/Publications
S9044View your shopping basket or Browse other items in Starter Motors.
