Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
FORD
Price:
NZ$ 281.78 including GST
NZ$ 245.03 excluding GST
or four payments of $70.45
with
Learn More
each
S9063
2
Associated Numbers
101430V 12170 1379703 1525795 20450911OE 22.1430 22.1430M 25-4059 255842V 3129 36000039 36002496 6014119 6935N 6G9N11000JA 6G9N11000JB 8080253 8697650 88212794 AEU1430 CS1430 CST14119GS DRS0032 DRS0032N LRS02387 SS720 STR61820 0986025960 Bosch ruil 11090124 EuroTec 115641 Cargo 120359D PIC EAI Ford show 2010001039 Visteon 254059 Elstock 31268035 Volvo 360000390 360024960 36003222 42025960 Herth Buss 438424 Valeo 458840 4884SP Spidan 590543103 PSH 6935 Lester 8080253F Friesen 910032 EDR HC Remy HCS1430 Lucas RAS31143 RNL1430CS RNL RNL6G9NJB STR8018sa ElectrologSpecifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 206 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | -1 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Focus 2.5 | 01.2009- | |
| FORD | Kuga 2.5 | [HYDB] | 02.2008-11.2012 |
| FORD | Kuga 2.5 | [HYDC] | 02.2008-11.2012 |
| FORD | Kuga 2.5 4x4 | [HYDB] | 02.2008-11.2012 |
| FORD | Kuga 2.5 4x4 | [HYDC] | 02.2008-11.2012 |
| FORD | Kuga 2.5 4x4 | 03.2009- | |
| FORD | Mondeo 2.5 | [HUBA] | 03.2007-01.2015 |
| FORD | Mondeo 2.5 V5 | 03.2007- | |
| FORD | Mondeo Turnier 2.5 | [HUBA] | 03.2007-12.2012 |
| FORD | S-Max 2.5 ST | [HUWA] | 03.2006- |
| VOLVO | C30 2.4 | [B5244S4] | 10.2006-12.2012 |
| VOLVO | C30 2.4 i | [B5254T3] | 10.2006- |
| VOLVO | C30 2.5 T5 | [B5254T3] | 10.2006-12.2012 |
| VOLVO | C30 2.5 T5 | [B5254T7] | 03.2007-12.2012 |
| VOLVO | C30 2.5 Turbo T5 | [B5244T3] | 10.2006- |
| VOLVO | C30 2.5 Turbo T5 | [B5254T7] | 03.2007- |
| VOLVO | C70 2.4 | [B5244S4] | 03.2006-10.2009 |
| VOLVO | C70 2.4 | [B5244S5] | 03.2006-10.2009 |
| VOLVO | C70 2.4 | [B5244S5] | 07.2006- |
| VOLVO | C70 2.4 i | [B5244S4] | 03.2006- |
| VOLVO | C70 2.5 T5 | [B5254T3] | 03.2006-02.2007 |
| VOLVO | C70 2.5 T5 | [D5254T3] | 03.2006- |
| VOLVO | S40 2.5 T5 | [B5254T7] | 03.2007-12.2012 |
| VOLVO | S40 2.5 T5 AWD | [B5254T7] | 03.2007-12.2010 |
| VOLVO | S40 2.5 Turbo T5 | [B5254T7] | 01.2008- |
| VOLVO | S40 2.5 Turbo T5 AWD | [B5254T7] | 01.2008- |
| VOLVO | S60 2.0 T | [B5204T8] | 05.2012-12.2015 |
| VOLVO | S60 2.4 | [B5244T4] | 01.2005-10.2006 |
| VOLVO | S60 2.4 Bifuel | [B5244SG2] | 07.2001-04.2010 |
| VOLVO | S60 2.5 T | [B5254T2] | 01.2003-04.2010 |
| VOLVO | S60 2.5 T5 | [B5254T5] | 09.2011-12.2015 |
| VOLVO | S60 2.5 T AWD | [B5254T2] | 07.2002-04.2010 |
| VOLVO | S60 2.5 Turbo | [B5254T2] | 01.2007- |
| VOLVO | S60 2.5 Turbo AWD | [B5254T2] | 01.2007- |
| VOLVO | S60 Cross Country 2.5 T5 AWD | [B5254T12] | 03.2015-12.2018 |
| VOLVO | S80 2.5 T | [B5254T10] | 01.2010-12.2012 |
| VOLVO | S80 2.5 T | [B5254T12] | 01.2012-04.2016 |
| VOLVO | S80 2.5 T | [B5254T14] | 09.2012-12.2016 |
| VOLVO | S80 2.5 T | [B5254T6] | 03.2006-12.2011 |
| VOLVO | S80 2.5 T Flexfuel | [B5254T11] | 01.2010-12.2011 |
| VOLVO | S80 2.5 T Flexfuel | [B5254T8] | 05.2008-12.2011 |
| VOLVO | S80 2.5 Turbo | [B5254T6] | 08.2006- |
| VOLVO | S80 2.5 Turbo AWD | [B5254T6] | 10.2006- |
| VOLVO | S80 2.5 Turbo FlexFuel | [B5254T8] | 05.2008- |
| VOLVO | V40 2.0 T4 | [B5204T8] | 07.2013-12.2015 |
| VOLVO | V40 2.0 T5 | [B5204T9] | 03.2013-12.2015 |
| VOLVO | V40 2.5 T5 | [B5254T12] | 12.2012-12.2014 |
| VOLVO | V40 Cross Country 2.0 T4 | [B5204T8] | 10.2013-12.2015 |
| VOLVO | V40 Cross Country 2.0 T4 AWD | [B5204T8] | 07.2013-12.2015 |
| VOLVO | V40 Cross Country 2.0 T5 | [B5204T9] | 02.2013-12.2015 |
| VOLVO | V40 Cross Country 2.0 T5 AWD | [B5204T9] | 03.2013-12.2015 |
| VOLVO | V40 Cross Country 2.5 T5 AWD | [B5254T12] | 10.2012-12.2016 |
| VOLVO | V50 2.4 | [B5244S] | 01.2007- |
| VOLVO | V50 2.4 | [B5244S4] | 04.2004-12.2010 |
| VOLVO | V50 2.4 | [B5244S5] | 01.2007- |
| VOLVO | V50 2.4 | [B5244S5] | 04.2004-12.2010 |
| VOLVO | V50 2.5 T5 | [B5254T7] | 03.2007-12.2012 |
| VOLVO | V50 2.5 T5 AWD | [B5254T7] | 03.2007-12.2010 |
| VOLVO | V50 2.5 Turbo T5 | [B5254T7] | 03.2007- |
| VOLVO | V50 2.5 Turbo T5 AWD | [B5254T7] | 01.2008- |
| VOLVO | V60 2.0 T5 | [B5204T9] | 10.2013-05.2018 |
| VOLVO | V60 Cross Country 2.5 T5 AWD | [B5254T12] | 03.2015-05.2018 |
| VOLVO | V70 2.0 Bifuel | [B5204T9] | 03.2013-12.2015 |
| VOLVO | V70 2.0 GDi | [B5204T9] | 04.2012-12.2015 |
| VOLVO | V70 2.5 T | [B5254T10] | 04.2009-12.2012 |
| VOLVO | V70 2.5 T | [B5254T6] | 08.2007-12.2009 |
| VOLVO | V70 2.5 T Flexifuel | [B5254T11] | 04.2009-12.2011 |
| VOLVO | V70 2.5 T Flexifuel | [B5254T8] | 05.2008-12.2009 |
| VOLVO | V70 2.5 Turbo | [B5254T6] | 08.2007- |
| VOLVO | V70 2.5 Turbo FlexFuel | [B5254T8] | 05.2008- |
| VOLVO | XC60 2.5 T5 AWD | [B5254T12] | 04.2014-02.2017 |
| VOLVO | XC70 2.5 T5 AWD | [B5254T12] | 08.2015-12.2016 |
| VOLVO | XC70 2.5 T6 AWD | [B5254T14] | 03.2015-12.2016 |
Reference Information
331816 DRS0032N AEU1430 8697650 25-4059 36003221 8080253 36002496 101430V 5014271 STX200387 STX200387R 36003222 115641 1525795 36000039 6935N 590.543.103.020 36000639 STM575 CGB-54059 590.543.103.028 590.543.103.029 STF1430 30659557 2134489 STR8018 31268035 PRSE500 6G9N-11000-JA 3129 LRS02387 6G9N-11000-JB 6G9N-11000-JC 360003221 360003222 STRE500 590.543.103.230 12170 220418 MAV161140 20450911OE S9063 1379703 CS1430 DRS0032 MAV161190 S12VS0369 255842V STR61820 6014119.1 22.1430M 88212794 S12VS0369A2 31652012 22.143 SS720 31652010 ANM12252X CST14119GS LRS2387Video/Publications
