Associated Numbers
11130707 16028248 AZJ3245 D26747769 IS0707 UD90002ASpecifications
| Kilowatt | 3.6 kW |
| Length (L.1) | 305 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 22 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DEUTZ-FAHR | 5670 H | ||
| DEUTZ-FAHR | 5670 HTS | ||
| DEUTZ-FAHR | 5680H | ||
| DEUTZ-FAHR | 5680 HTS | ||
| DEUTZ-FAHR | 5690 HTS | ||
| DEUTZ-FAHR | 6095 HTS |
Reference Information
D26747769 AZJ3245 IS0707 6021119.1 MS 16028248 20419911OE CST21119GS 331976 MAV231190 STR7846 338 11130707 UD90002AVideo/Publications
S9159(LETRIKA)View your shopping basket or Browse other items in Starter Motors.
