Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 497.24 including GST
NZ$ 432.38 excluding GST
or four payments of $124.31
with
Learn More
each
S9174
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
AZF4167Associated Numbers
0001230013 01181570 01182179 01182388 04300287 11.131.645 11.131.862 114320 18525 18525N 255052 255052M 260-23102 510.507.092 91-15-7140 AZF4167 AZF4229 BOS0001230013 DRS0363 IS1237 LETIS1237 LRS02559 S0300 STR50271 TS-6205 UD11160SSpecifications
| Kilowatt | 4 kW |
| Length (L.1) | 322 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 23 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AHLMANN | AL-100-100 | [BF4L2011] | |
| AHLMANN | AZ90T | [BF4L2011] | |
| ATLAS COPCO | XAS-66 | [Deutz] | 01.1997- |
| ATLAS COPCO | XAS-66DDG | [Deutz] | 01.1997- |
| BOMAG | BW-120AD | [Deutz] | 01.1997- |
| CASE | 360 | [Deutz] | 01.1988-01.1998 |
| CHAMPION | A421 Super Pac | [Deutz] | 01.1996- |
| DEUTZ | TCD2011 L4 3.6 | [4] | |
| DEUTZ | TD2011 L4W 3.6 | ||
| DYNAPAC | CG233HF 3.6 | [TCD2011] | |
| DYNAPAC | CG333HF 3.6 | [BF4M] | |
| DYNAPAC | CG333HF 3.6 | [TCD2011] | |
| EUROMACCHINE | MP 01 DC 3.1 | [BF4M2011] | |
| EUROMACCHINE | MP 02 DC 3.1 | [BF4M2011] | |
| EUROMACCHINE | MP 03 DC 4 | [BF4M2011] | |
| EUROMACCHINE | MP 04 DC 4 | [BF4M2011] | |
| GEHL | 5640 3.1 | [BF4M2011] | |
| GEHL | 5640 3.1 | [F4M2011] | |
| JCB | 409 3.6 | [Deutz] | |
| JLG | 600A | [F4M1011F] | |
| JLG | 600S | [F4M1011F] | 01.1996- |
| KRAMER | 1150 3.6 | [D2011] | |
| KRAMER | 380 3.6 | [D2011] | |
| KRAMER | 480 3.6 | [D2011] | |
| KRAMER | 580 3.6 | [TCD2011] | |
| KRAMER | 680T 3.6 | [TCD2011] | |
| KRAMER | 750 3.6 | [D2011] | |
| KRAMER | 780 3.6 | [D2011] | |
| KRAMER | 850 3.6 | [D2011] | |
| KRAMER | 950 3.6 | [TCD2011] | |
| KRAMER | KL27T 3.6 | [D2011] | |
| KRAMER | KL35 3.6 | [D2011] | |
| KRAMER | KL35T 3.6 | [D2011] | |
| KRAMER | KL37 3.6 | [D2011] | |
| KRAMER | KL43 3.6 | [D2011] | |
| WACKER NEUSON | 10001 3.6 | [D2011T] | |
| WACKER NEUSON | 14504 4 | [TCD2012-L04] | |
| WACKER NEUSON | 6001 3.6 | [D2011T] | |
| WACKER NEUSON | 9001 3.6 | [D2011T] | |
| WACKER NEUSON | 9503 4 | [TCD2012-L04] | |
| WACKER NEUSON | WL 37 3.6 | ||
| WACKER NEUSON | WL 48 3.6 | ||
| WEIDEMANN | 2070 CX80 3.6 | ||
| WEIDEMANN | 2070 CX80 LP 3.6 | ||
| WEIDEMANN | 2070 CX80 LP T 3.6 | ||
| WEIDEMANN | 2070 CX80 T 3.6 | ||
| WEIDEMANN | 3070 CX60 3.6 | ||
| WEIDEMANN | 3070 CX60 LP 3.6 | ||
| WEIDEMANN | 3070 CX60 LP T 3.6 | ||
| WEIDEMANN | 3070 CX60 T 3.6 | ||
| WEIDEMANN | 3070 CX80 3.6 | ||
| WEIDEMANN | 3070 CX80 LP 3.6 | ||
| WEIDEMANN | 3070 CX80 LP T 3.6 | ||
| WEIDEMANN | 3070 CX80 T 3.6 | ||
| WEIDEMANN | 4070 CX80 3.6 | ||
| WEIDEMANN | 4070 CX80 LP 3.6 | ||
| WEIDEMANN | 4070 CX80 T 3.6 |
Reference Information
STR7939 67 LRS2559 6021224.1 AZF4229 TS-6205 BOS0001230013 IS1237 S12BH0463 510.507.092.460 AZF4167 01182179 255052M 260-23102 STR50271 04300287 LRS02559 510.507.092 20419422OE 5010445 01181570KZ S9174 UD11160S CST21224GS MS LETIS1237 MAV232240 255052 S12BH0463A2 11.131.645 91-15-7140 114320 CGB-93013 1181570KZ 01181570 18525N DRS0363 STRL677 11.131.862 01182388 18525 0001230013Video/Publications
