S9175 - Brand new AS-PL Starter motor

Associated Numbers

11.131.116 11.131.426 11.131.728 11.131.746 11.131.970 11.132.101 11.132.169 20419341OE 6021143 83646400 AZE4166 AZE4168 AZE4209 AZE4230 AZE4251 AZE4540 AZE4597 CST21143GS IS1303 LETIS0179 LETIS1303 S9175 TS-6268 UD11323S VPF7264

Specifications

Kilowatt	3.2 kW
Length (L.1)	286 mm
Mount Hole Center - Center (O.1)	90 mm
Mount Hole Center - Center (O.2)	127 mm
Mount Hole Center - Center (O.3)	90 mm
Mount Hole Diameter (C.1)	11 mm
Mount Hole Diameter (C.2)	11 mm
Mount Hole Diameter (C.3)	11 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	11 qty
No./Teeth (Replaces)	10.11 qty
OEM Product	No
Pinion at Rest (B)	48 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	89 mm
Unit Type	ISKRA / LETRIKA
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
CASE	110 4.4		01.1997-12.2003
CASE	68 3.3		01.1998-12.2004
CASE	75 3.3		01.1998-12.2004
CASE	80 PRO		10.2007-
CASE	86		01.1999-01.2004
CRYSTAL TRACTOR	ORION 13
MASSEY FERGUSON	MF 5300
VALTRA	1180 S
VALTRA	A650 3.3		01.2010-
VALTRA	A650 3.3
VALTRA	A650 F 3.3		01.2010-
VALTRA	A72 3.3	[33DTA]
VALTRA	A750 3.3		06.2009-
VALTRA	A750 3.3
VALTRA	A750F 3.3		06.2009-
VALTRA	A75 4WD 3.3	[33DTA]
VALTRA	A75n/A75L 3.3	[33DT]
VALTRA	A83 3.3	[33CTA]
VALTRA	A850 3.3		05.2009-
VALTRA	A850 3.3
VALTRA	A850 F 3.3		06.2009-
VALTRA	A93 3.3	[33CTA]
VALTRA	A950 4.4		03.2009-
VALTRA	A950 4.4
VALTRA	A950 F 3.3
VALTRA	A95N 4.4	[33DTA]
ZETOR	3320 2.6	[Z5201]	01.1992-
ZETOR	3511 2.7	[Z5201]	01.1994-
ZETOR	3513	[Z3001]
ZETOR	3520. 3540	[7201]	01.1995-
ZETOR	4320 3.9	[Z6201]	01.1992-
ZETOR	4320 3.9	[Z6202]
ZETOR	4341 3.9	[6202]	01.1997-
ZETOR	4712 2.5	[Z4701]	01.1974-12.1977
ZETOR	4718 2.5	[Z4701]	01.1974-12.1977
ZETOR	4911 2.6	[Z4901]	01.1976-12.1980
ZETOR	5011 2.6	[Z5001]	01.1980-12.1984
ZETOR	5211 2.6	[Z5001]	01.1984-12.1990
ZETOR	5213
ZETOR	5243
ZETOR	5245
ZETOR	5320.534 3.5	[Z7201]	01.1992-
ZETOR	5321 3.5	[7202]	01.1997-
ZETOR	5511.5545	[Z5501]
ZETOR	5516	[Z5501]
ZETOR	5611.5645	[Z5501]
ZETOR	5647	[Z5501]
ZETOR	5711.5718 3.1	[Z5501]	01.1974-12.1977
ZETOR	5745.5748	[Z5501]
ZETOR	5911.5945 3.4	[Z5901]	01.1978-12.1980
ZETOR	6011.6045 3.4	[Z6001]	01.1980-12.1984
ZETOR	6211 3.4	[Z6201]	01.1984-12.1990
ZETOR	6212.6245 3.4	[Z6201]	01.2984-12.1990
ZETOR	6320.634 3.9	[Z7701]	01.1992-
ZETOR	6321.6341 3.9	[Z7701]	01.1977-
ZETOR	6511.6518
ZETOR	6522
ZETOR	6711.6718 3.4	[Z6701]	01.1974-12.1977
ZETOR	6745.6748 3.4	[Z6701]	01.1974-12.1977
ZETOR	6911 3.4	[Z6901/]	01.1978-12.1980
ZETOR	6918.6945 3.4	[Z6901/]	01.1978-12.1980
ZETOR	7011.7045 3.4	[Z7001/]	01.1980-12.1984
ZETOR	7211.7245 3.5	[Z7201]	01.1984-12.1990
ZETOR	7321.7341 3.9	[Z7302]	01.1997-
ZETOR	7340 3.9	[Z7301]	01.1992-
ZETOR	7520 4.1	[7801/]	01.1991-
ZETOR	7520.754
ZETOR	7711.7745 3.9	[Z7701]	01.1986-12.1990

Reference Information

STR79002 836873290 11.132.169 AZE4166 AZE4540 AZE4168 6021143 11.132.101 83646400 STR7858 LETIS1303 TS-6268 20419341OE 592 LETIS0179 235 30528N 836673289 11.131.116 634 OF 11.131.970 UD11323S 6021143.1 AZE4209 6021143.0 S9175 AZE4597 MS AZE4230 VPF7264 AZE4251 836667365 11.131.728 11.131.746 CST21143GS 836867365 CST21143AS 11.131.426 IS1303 STR7882 20419341BN STR79003
