Associated Numbers
03111-4270 03111-4272 03111-4290 20493821OE 25-4222 250.510.123 36100-4X900 36100-4X901 36100-4X902 6032128 AEY2550 CST32128 CST32128AS CST32128ES CST32128GS CST32128OS CST32128RS LRS02550 S9246 STY4901 UD11997S
031114270 Hitachi
031114272 Hitachi
031114290 Hitachi
11040811 EuroTec
250510123 PSH
254222 Elstock
361004X900 Kia
361004X901 Kia
361004X902 Kia
46KJ005
910846 EDR
DRS0846 Remy
LRS02550 Lucas
STR6524sa Electrolog
TRS090 TWA
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 140.5 mm |
| Mount Hole Center - Center (O.2) | 75 mm |
| Mount Hole Center - Center (O.3) | 83 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | M12x1.25 mm |
| Mount Hole Diameter (C.3) | M12x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 4 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | HYUNDAI / KIA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KIA | Carnival 2.9 CRDi | [J3] | 01.2006- |
| KIA | Sedona 2.9 CRDi | [J3] | 01.2006-12.2010 |
Reference Information
CGB-24290 S9246 CST32128AS CST32128 CST32128GS CST32128ES 5040624 STR6524 CST32128RS 336510 03111-4270 03111-4290 LRS02550 03111-4272 S12DE0617A2 LRS2550 250.510.123 UD11997S 20493821OE 36100-4X902 6032128 AEY2550 STY4901 361004X902SJ STX210277R STX210277 36100-4X901 36100-4X900 25-4222 CST32128OSVideo/Publications
