Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
PRESTOLITE
Price:
NZ$ 590.61 including GST
NZ$ 513.57 excluding GST
or four payments of $147.65
with
Learn More
each
S9249
No stock in NZ
No stock in NZ
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M93R3026SEAssociated Numbers
4992135 701.513.103 M93R3026SE PREM93R3026SE S9249 UD90317SSpecifications
| Kilowatt | 6 kW |
| Length (L.1) | 314 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | PRESTOLITE |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Engine |
Reference Information
STR97002 701.513.103 4992135 UD90317S S9249 M93R3026SE PREM93R3026SEVideo/Publications
