Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBA
Price:
NZ$ 332.44 including GST
NZ$ 289.08 excluding GST
or four payments of $83.11
with
Learn More
each
S9347S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
SM422-09Associated Numbers
128000-0280 128000-2190 128000-5080 17587N 20319 20645 20645K 228000-0210 228000-0211 242-101 25-1117 254883 31200-P2A-014 31200-P2C-004 31200-PCO-883 31200-PEO-461 31200-PEO-661 31200-PEO-662 31200-PEO-663 31200-PEO-664 31200-PEO-665 66925103 88212644 8EA726416-001 9605 J5214024 JS319 LRS00719 S-8701 SG0238 SM-302-05 SM-302-07 SM-302-25 SM-302-48 SM-422-09 SM-442-10 SM-44210 SM422-09 STU0319 UD20519SSpecifications
| Kilowatt | 1 kW |
| Length (L.1) | 206 mm |
| Mount Hole Center - Center (O.1) | 113 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 34 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Civic 1.2 | [AGAH] | 01.1985-12.1987 |
| HONDA | Civic 1.2 | [ECEDEE] | 01.1987-12.1991 |
| HONDA | Civic 1.3 | [AGAH] | 01.1983-12.1987 |
| HONDA | Civic 1.3 | [ECEDEE] | 01.1987-12.1991 |
| HONDA | Civic 1.3 | [EGEHEJ] | 01.1991-12.1995 |
| HONDA | Civic 1.4 | [ECEDEE] | 01.1987-12.1991 |
| HONDA | Civic 1.5 | [AGAH] | 01.1983-12.1987 |
| HONDA | Civic 1.5 | [AGAH] | 01.1985-12.1987 |
| HONDA | Civic 1.5 i | [D15Z6] | 11.1995-02.2001 |
| HONDA | Civic 1.5 i | [ECEDEE] | 01.1987-12.1991 |
| HONDA | Civic 1.5 i | [ECEDEE] | 01.1988-12.1990 |
| HONDA | Civic 1.5 i | [EGEHEJ] | 01.1992-12.1995 |
| HONDA | Civic 1.5 i | [EJEK] | 01.1995-12.2001 |
| HONDA | Civic 1.6 i | [D16Y7] | 03.1996-03.2000 |
| HONDA | Civic 1.6 i | [ECEDEE] | 01.1987-12.1991 |
| HONDA | Civic 1.6 i VTEC | [D16Y6] | 11.1995-02.2001 |
| HONDA | Civic 1.6 i VTEC | [D16Y8] | 03.1996-03.2000 |
| HONDA | Civic 1.6 i VTEC | [D16Y8] | 11.1995-02.2001 |
| HONDA | Civic 1.6 i VTEC | [EJEK] | 01.1995-12.2001 |
| HONDA | Civic 1.6 Si | [EGEHEJ] | 01.1991-12.1993 |
| HONDA | Civic 1.6 VTi | [B16A2] | 11.1995-02.2001 |
| HONDA | Concerto 1.4 | [HWHWW] | 01.1989-12.1991 |
| HONDA | Concerto 1.5 | [HWHWW] | 01.1989-12.1995 |
| HONDA | Concerto 1.6 i | [HWHWW] | 01.1989-12.1995 |
| HONDA | CR-X 1.5 | [AFAS] | 01.1983-12.1987 |
| HONDA | CR-X 1.6 i | [EDEE] | 01.1987-12.1992 |
| HONDA | Integra 1.5 | [DA] | 01.1985-12.1989 |
| HONDA | Integra 1.6 | [DA] | 01.1986-12.1989 |
| HONDA | Jazz 1.2 | [AA] | 01.1983-12.1986 |
| HONDA | Shuttle 1.5 | [RA] | 01.1988-12.1992 |
| HONDA | Shuttle 1.5 4x4 | [RA] | 01.1985-12.1987 |
| ROVER | 216 1.6 GSi | [XW] | 01.1991-12.1999 |
| ROVER | 416 1.6 GSi | [XW] | 01.1990-12.1996 |
| ROVER | 416 1.6 GTi | [XW] | 01.1990-12.1995 |
Reference Information
SM422-09 SM-302-48 JS319 31200-P2A-014 SM-302-05 254883 SM-302-07 UD20519S STX200986 SG0238 SM-44210 STX200709 20645K SM-422-09 LRS719 31200-P2A-004 31200-P2C-004 J5214024 88212644 MAV5930 STX200986R 17587N 128000-2190 STU0319 31200-PCO-883 STX200709R 8EA726416-001 LRS00719 20319 SM-302-25 S-8701 228000-0210 228000-0211 66925103 242-101 128000-0280 CGB-24061 CGB-24062 25-1117 20645 31200-PEO-661 128000-5080 31200-PEO-662 31200-PEO-663 31200-PEO-461 JS645 9605 31200-PEO-664 31200-PEO-665 SM-442-10Video/Publications
