Brand new AS-PL Starter motor drive
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 43.47 including GST
NZ$ 37.80 excluding GST
or four payments of $10.87
with
Learn More
each
SD4006
No stock in NZ
No stock in NZ
Associated Numbers
063220536010 063220537010 063220538010 63220506 63220507 63220508 63220536 63220537 63220538 063220536010 063220537010 063220538010 63220506 63220507 63220508 63220536 63220537 63220538Specifications
| Inside Diameter (I.D.1) | 11.5 mm |
| Length (L.1) | 67.2 mm |
| Length (L.2) | 15.2 mm |
| No./Splines | 12 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Outside Diameter (O.D.1) | 45 mm |
| Outside Diameter (O.D.2) | 25.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Type | Drive |
| Unit Type | MAGNETI MARELLI |
Reference Information
85540601010 74889271010 AMB0115 3120 SDV3716 DRV4176 9941751 225164 CQ2010250 74889271 85540601 74886971 9936996Video/Publications
