Associated Numbers
A0599 UD15021A AS-PL AEK3658 AUTOELECTRO F000BL0803 BOSCHList F000BL0829 F000BL08P1 F000BL08P2 CAL10469 CASCO CAL10469AS CAL10469ES CAL10469GS CAL10469OS CAL10469RS CAL15552 CAL15552AS CAL15552ES CAL15552GS CAL15552OS CAL15552RS 9481 CEVAM DA2331 DELCO DRA1221 57424 EAI 28-6798 ELSTOCK ALB3903 KRAUF 553753RIV KUHNER 554038RIB 554268RIV LRA03658 LUCAS 89215744 POWERMAX 205.556.140 PSH 305.905.140 20101964 REAL 2010469 SANDO 2015552 439814 VALEO 440468 FG18T084 VALEOList TG14C041 TG14C096 TG14C104 06J903023A VW 06J903023AX 06J903023G VWList 06J903023GX 06J903023H 06J903023HX ALT10726 WOODAUTO ALT14576 VAL439814 VALTG14C041 ASPL 286798 12090486 EuroTec 205556140 Elstock 9090805F Friesen 931221 EDR Remy Bosch F000BL0803OR +line F000BLO803 06J903023B 20354 Lester 20354N WAI 2715993A Valeo 305905140 611730 715993 9090805 ALT0406sa Electrolog ALT1185sa Lucas TG14C041OR 06J903023D 06K903024A 113502 FARC 209493 Messmer LRA3658 show TG14C041SEL Volkswagen 12201356 AES Sando Wood Auto EVEAVE1225 Dapex F000BL08K1 F000BL08K2 F000BL08S9 F000BL08X5 RNLBL0803OER RNL RNLF000BL0803 WOOALT14576 F-000-BL0-803 F-000-BL0-829 F-00E-100-658 Reman AL0194X IAT A24226 Industry 24226 PIC 220-5837 11216 SEG Automotive F000.BL0.829 Group 06K903015AX Voltux V2-24226Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 140 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 8.5 mm |
| Diameter (D.4) | 9.5 mm |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 28 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A1 1.8 TFSi | [DAJB] | 01.2015- |
| AUDI | A3 1.8 TFSi | [CJSA] | 01.2013- |
| AUDI | A3 1.8 TFSi | [CJSB] | 01.2013- |
| AUDI | A3 1.8 TFSi Quattro | [CJSA] | 01.2013- |
| AUDI | A3 1.8 TFSi Quattro | [CJSB] | 01.2013- |
| AUDI | A3 2.0 S3 Quattro | [CJXB] | 01.2012- |
| AUDI | A3 2.0 S3 Quattro | [CJXC] | 01.2012- |
| AUDI | Q3 2.0 TFSi | [CULB] | 01.2015- |
| AUDI | Q3 2.0 TFSi Quattro | [CULB] | 01.2014- |
| AUDI | S1 2.0 Quattro | [CWZA] | 01.2014- |
| AUDI | S3 2.0 Quattro | [CJXB] | 01.2012- |
| AUDI | S3 2.0 Quattro | [CJXC] | 01.2012- |
| AUDI | S3 2.0 Quattro | [CJXF] | 01.2012- |
| AUDI | TT 1.8 TFSi | [CJSA] | 01.2015- |
| AUDI | TT 2.0 TFSi | [CHHC] | 01.2014- |
| AUDI | TT 2.0 TFSi | [CJYF] | 01.2014- |
| AUDI | TT 2.0 TFSi | [CJYG] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CHHC] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CJYF] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CJYG] | 01.2014- |
| SEAT | Alhambra 2.0 TSi | [DEDA] | 01.2015- |
| SEAT | Leon 2.0 Cupra | [CJXA] | 01.2013- |
| SEAT | Leon 2.0 Cupra | [CJXE] | 01.2013- |
| SKODA | Octavia 1.8 TSi | [CJSA] | 01.2012- |
| SKODA | Octavia 1.8 TSi | [CJSC] | 01.2012- |
| SKODA | Octavia 1.8 TSi 4x4 | [CJSA] | 01.2012- |
| SKODA | Octavia 1.8 TSi 4x4 | [CJSC] | 01.2012- |
| SKODA | Octavia 2.0 TSi RS | [CHHB] | 01.2013- |
| SKODA | Superb 1.8 TSi | [CJSA] | 01.2015- |
| SKODA | Superb 1.8 TSi | [CJSC] | 01.2015- |
| SKODA | Superb 2.0 TSi | [CHHB] | 01.2015- |
| SKODA | Superb 2.0 TSi 4x4 | [CJXA] | 01.2015- |
| VW | Golf VI 2.0 TSi | [CULC] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CHHA] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CHHB] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CXDA] | 01.2013- |
| VW | Golf VII 2.0 R 4-Motion | [CJXB] | 01.2013- |
| VW | Golf VII 2.0 R 4-Motion | [CJXC] | 01.2013- |
| VW | Multivan 2.0 TDi | [CJKA] | 01.2015- |
| VW | Multivan 2.0 TDi | [CJKB] | 01.2015- |
| VW | New Beetle 2.0 TSi | [CULA] | 01.2014- |
| VW | New Beetle 2.0 TSi | [CULC] | 01.2014- |
| VW | Passat 1.8 TSi | [CJSA] | 01.2015- |
| VW | Passat 1.8 TSi | [CJSC] | 01.2015- |
| VW | Passat 2.0 TSi | [CHHB] | 01.2015- |
| VW | Passat 2.0 TSi | [CJXA] | 01.2015- |
| VW | Passat 2.0 TSi | [CXDA] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CHHB] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CJXA] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CXDA] | 01.2015- |
| VW | Polo 1.8 GTi | [DAJA] | 01.2014-12.2016 |
| VW | Polo 1.8 GTi | [DAJB] | 01.2014-12.2016 |
| VW | Scirocco 2.0 TSi | [CULA] | 01.2013- |
| VW | Scirocco 2.0 TSi | [CULC] | 01.2013- |
| VW | Sharan 2.0 TSi | [DEDA] | 01.2015- |
| VW | Tiguan 2.0 TFSi 4-Motion | [CHHB] | 01.2016- |
| VW | Tiguan 2.0 TFSi 4-Motion | [CZPA] | 01.2016- |
| VW | Touran 1.8 TSi | [CJSA] | 01.2015-12.2017 |
| VW | Transporter 2.0 TSi | [CJKA] | 01.2015- |
| VW | Transporter 2.0 TSi | [CJKB] | 01.2015- |
| VW | Transporter 2.0 TSi 4-Motion | [CJKA] | 01.2015- |
