Associated Numbers
2020235 28-7531 4310 554439RIH A-80696 CAL20235 CAL20235AS CAL20235ES CAL20235GS CAL20235OS CAL20235RS DRA1278 FG20S019 HITLR1180-858 LR1180-851 LRA03921
a3471s a3471
06E903018G VW
06E903018M VW
06E903018N VW
06E903018S VW
12090779 EuroTec
205557180 PSH
287531 Elstock
439867 Valeo
440605 Valeo
618088 Valeo
DRA1278 Remy
FG20S019 Valeo
FG20S019OR +line
FGN20S019 Valeo show
LR1180851 Hitachi
LRA03921 Lucas
UD17227A AS-PL
UD17232A AS-PL
CAL20235GS CASCO
4310 CEVAM
DRA1278 DELCO
57645 EAI
28-7531 ELSTOCK
LR1180851 HITACHIList
LR1180858 HITACHI
LR1180858S HITACHI
ALH8501 KRAUF
554439RIH KUHNER
LRA03921 LUCAS
205.557.180 PSH
20145532OE REAL
2020235.1 SANDO
439867 VALEO
440605 VALEO
FG20S012 VALEOList
FG20S019 VALEOList
FGN20S019 VALEO
06E903018G VW
06E903018M VW
06E903018MX VW
06E903018S VWList
06E903018SX VW
6E903018S VW
6E903018SX VW
ALT32238 WOODAUTO
CAL20235 CASCO
CAL20235AS CASCO
CAL20235ES CASCO
CAL20235GS CASCO
CAL20235OS CASCO
CAL20235RS CASCO
4310 CEVAM
DRA1278 DELCO
A-80696 DIXIE
28-7531 ELSTOCK
LR1180-851 HITACHIList
554439RIH KUHNER
LRA03921 LUCAS
2020235 SANDO
FG20S019 VALEOList
HITLR1180-858 WOODAUTO
06E903018G VW
06E903018M VW
06E903018N VW
06E903018S VW
12090779 EuroTec
205557180 PSH
287531 Elstock
439867 Valeo
440605 Valeo
618088 Valeo
DRA1278 Remy
FG20S019 Valeo
FG20S019OR +line
FGN20S019 Valeo show
LR1180851 Hitachi
LRA03921 Lucas
UD17227A AS-PL
UD17232A AS-PL
CAL20235GS CASCO
4310 CEVAM
DRA1278 DELCO
57645 EAI
28-7531 ELSTOCK
LR1180851 HITACHIList
LR1180858 HITACHI
LR1180858S HITACHI
ALH8501 KRAUF
554439RIH KUHNER
LRA03921 LUCAS
205.557.180 PSH
20145532OE REAL
2020235.1 SANDO
439867 VALEO
440605 VALEO
FG20S012 VALEOList
FG20S019 VALEOList
FGN20S019 VALEO
06E903018G VW
06E903018M VW
06E903018MX VW
06E903018S VWList
06E903018SX VW
6E903018S VW
6E903018SX VW
ALT32238 WOODAUTO
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 8.5 mm |
| Diameter (D.4) | 8.5 mm |
| Length (L.1) | 193 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 64.5 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.8 FSi | [CHVA] | 01.2010- |
| AUDI | A6 2.8 FSi Quattro | [CHVA] | 01.2010- |
| AUDI | A6 3.0 TFSi Quattro | [CGWB] | 01.2010- |
| AUDI | A6 3.0 TFSi Quattro | [CGWD] | 01.2010- |
| AUDI | A6 3.0 TFSi Quattro | [CGXB] | 01.2010- |
| AUDI | A6 3.0 TFSi Quattro | [CTUA] | 01.2010- |
| AUDI | A7 2.8 FSi | [CHVA] | 01.2010- |
| AUDI | A7 2.8 FSi Quattro | [CHVA] | 01.2010- |
| AUDI | A7 2.8 FSi Quattro | [CNYA] | 01.2010- |
| AUDI | A7 3.0 TFSi Quattro | [CGWD] | 01.2010- |
| AUDI | A7 3.0 TFSi Quattro | [CGXB] | 01.2010- |
| AUDI | A7 3.0 TFSi Quattro | [CTTA] | 01.2010- |
| AUDI | A7 3.0 TFSi Quattro | [CTUA] | 01.2010- |
Alternatives >>>
AGV-C6153 - OEM VALEO Alternator - Will replace HITACHI Version
AAM-C6153 - +Plus Line Pro Alternator ( Valeo style, OEM Regulator and INA Pulley) Will replace HITACHI
A3471S - ASPL Standard line - Valeo Style Aftermarket Regulator and Pulley
A2073PR - Remanufactured HITACHI Alternator
AGH-C6153 - OEM HITACHI Alternator - Coming Soon
Reference Information
2020235 28-7531 4310 554439RIH A-80696 CAL20235 CAL20235AS CAL20235ES CAL20235GS CAL20235OS CAL20235RS DRA1278 FG20S019 HITLR1180-858 LR1180-851 LRA03921 FG20S019 FG20S019 FGN20S019 LR1180851 06E903018G VW 06E903018M 06E903018N 06E903018S
