Associated Numbers
0350-602-0410 0350-602-0411 0350-602-0412 0350-602-0450 0350-602-0451 20444206OE 23300-Z6001 23300-Z6002 23300-Z6005 23300-Z6008 6037602 CST37602 CST37602AS CST37602ES CST37602GS CST37602OS CST37602RS UD11117S
03506020610 Sawafuji
161524113 PSH
23300Z6007 Nissan
STR9883sa Electrolog
UD11117S ASPL
CST37602 CASCO
CST37602GS CASCO
23300Z6001 NISSAN
23300Z6002 NISSAN
23300Z6005 NISSAN
23300Z6008 NISSAN
20444206OE REAL
6037602 SANDO
03506020410 SAWAFUJIList
03506020411 SAWAFUJI
03506020412 SAWAFUJIList
03506020450 SAWAFUJI
03506020451 SAWAFUJI
23300Z6001 23300Z6002 23300Z6005 23300Z6008
SAWAFUJI: 03506020410 03506020411 03506020412 03506020450 03506020451
Specifications
| Kilowatt | 6 kW |
| Length (L.1) | 378 mm |
| Mount Hole Center - Center (O.1) | 111 mm |
| Mount Hole Center - Center (O.2) | 130 mm |
| Mount Hole Center - Center (O.3) | 122 mm |
| Mount Hole Diameter (C.1) | 14.5 mm |
| Mount Hole Diameter (C.2) | 14.5 mm |
| Mount Hole Diameter (C.3) | 14.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 32 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Voltage | 24 V |
Vehicle Applications
250032, NISSAN, Engine, [MD92], ,View your shopping basket or Browse other items in Starter Motors.
