Associated Numbers
47-578
Specifications
| Amp | 150 A |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 9.5 mm |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 69 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 41 mm |
| Pad mount thickness (E.2) | 41 mm |
| Plug Code | PL_2305 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 76 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Focus 2.0 Ti | [MGDA] | 01.2011-12.2015 |
| FORD | Focus 2.0 Ti | [XQDA] | 01.2011-12.2015 |
Reference Information
12090887 2015A11.0 ALT00726 BV6T-10300-EA BV6T-10300-EB 1743881 BV6T10300EA DA2812 90-22-5650 ALV6030 FGN15S091 DRA1702 28-7661 595.920.150 57627 11747N CAL15A11AS FG15S091 2410219 1777583 LRA4052 ALT2355CP ALTJ490 40416 209318 RMBV6T-10300-EB LRA04052 UD17163A 2415004 A-9559 BV6T10300EC 2017911ABN 554597RI BV6Z10346FVideo/Publications
