Associated Numbers
2438697
Specifications
| Amp | 225 A |
| Bottom Mounting Foot Width (B) | 21 mm |
| Diameter (D.1) | 11.5 mm |
| Diameter (D.2) | 11.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 47 mm |
| OEM Product | No |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 49 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Galaxy 2.0 TDCi | [T7CI] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T7CJ] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T7CK] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T7CL] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T8CG] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T8CH] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T8CI] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [T8CJ] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [UFCA] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi | [UFCB] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi Bi-Turbo | [T9CB] | 01.2015-06.2018 |
| FORD | Galaxy 2.0 TDCi Bi-Turbo | [T9CC] | 01.2015-06.2018 |
| FORD | Mondeo 2.0 TDCi | [T7CA] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CC] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CD] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CE] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CF] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CN] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CP] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T7CQ] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T8CA] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T8CB] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T8CC] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T8CD] | 09.2014- |
| FORD | Mondeo 2.0 TDCi | [T8CL] | 09.2014- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CA] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CC] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CD] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CE] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CF] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CN] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CP] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T7CQ] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T8CA] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T8CB] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T8CC] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T8CD] | 02.2015- |
| FORD | Mondeo 2.0 TDCi 4x4 | [T8CL] | 02.2015- |
| FORD | Mondeo 2.0 TDCi Bi-Turbo | [T9CA] | 03.2015- |
| FORD | S-Max 2.0 TDCi | [T7CI] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T7CJ] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T7CK] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T7CL] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T8CG] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T8CH] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T8CI] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [T8CJ] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [UFCA] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi | [UFCB] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T7CI] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T7CJ] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T7CK] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T7CL] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T8CG] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T8CH] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T8CI] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi 4x4 | [T8CJ] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi BI-Turbo | [T9CB] | 01.2015-06.2018 |
| FORD | S-Max 2.0 TDCi BI-Turbo | [T9CC] | 01.2015-06.2018 |
Reference Information
STX110336 20179870OE 12090864 STX110336R AEK3796 ALT14636 55151086 ALT00966 554380RIV 440710 57583 ALV3307 LRA3796 2438697 FGN23S072 VAL439953 439953 CAL15078GS ALTE935 89215850 A3512S 24141N-OE DS7T10300FB 726561 CGB-86906 DS7T10300FD 2015078.1 DS7T-10300-FA NFG23S072 DS7T-10300-FB DS7T-10300-FC DS7T-10300-FD LRA03796 28-6906 1870356 A12VA0307AS 209315 FG23S072 DRA1592 DA2702 595.907.225 UD17249A 4337 2380384Video/Publications
