Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 231.40 including GST
NZ$ 201.22 excluding GST
or four payments of $57.85
with
Learn More
each
S5413S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 186 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 17 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | LJ 80 0.8 | [F8A] | 01.1977-12.1982 |
| SUZUKI | SJ 410 1.0 | [F10A] | 01.1981-12.1991 |
| SUZUKI | SJ 410 1.0 | [F10A] | 09.1981-07.1991 |
Reference Information
028000-2151 111475 3110073010 M002T42382 DS1828 25-2077 M002T49189 28100-22020 28100-22021 3100080X51 M002T49181 M003T30481 6035107.0 3110073030XA LRS00490 UD16857S STR5145 M2T49181 M3T30481 9000334103 31100A7303 M002T42381 M2T49189 0986012881 J5218000 3110073036 3110073035 M2T47481 3110073034 3110073033 20394 J5218007 31000-80X51 3110080092 M003T29681 M2T30481 STR71018 S5413S CST35177AS STX200366 AES4190 3110082C11 M3T33182 M3T33181 1585263011 M3T33183 1585263012 1585263013 STM2394 LRS2065 M3T30586 31100-73010 180.001.082.608 31100T3035 SS838 M2T30585 M2T30586 M2T30581 180.001.092.415 3110070B20 M002T47481 M2T33183 31100-80X51 3110080X51000 M2T33182 180.001.092.138 180.001.082.415 3110073010XA MAV371770 JS394 180.001.092.130 MAV371770A 19837-63012 028000-2240 M2T27686 ANM12938X STX201321 20394M 31100-73030 15852-63011 31100-A7303 15852-63010 LRS02065 01100153002S 31100-73035 31100-73036 M002T30481 M2T41586 15852-63012 31100-73031 3110073071 31100-73033 028000-2241 31100-73034 M2T41581 20437771BN M003T33183 M003T33182 M003T33181 LRS490 31100-80091 CST35107AS 31100-80092 31100-80094 M002T27686 DRS0718 25-1201 20437701BN M003T30586 M2T42382 JS330 91-27-3068 M002T41586 M2T42381 M002T41581 3110073031XA 3100080X51000 9690 M3T29681 16791N 6035177.0 M002T30581 3110073092 31100-82C11 3110073091 M002T30585 88212502 3110073090 M002T30586Video/Publications
