Associated Numbers
0986017561 Bosch ruil
0986UR1211 Bosch ruil
113121 Cargo
1280008530 Denso show
1280008531 Denso show
1280008890 Denso
1280008891 Denso
17141 Remy
190549092 PSH
2810011010 Toyota
2810011020 Toyota
458503 Valeo
91295288 Wilson
DRS3383 Remy
LRS1481 Lucas
S8224 Dixie
S8365 Dixie
SR3254X Bosch (USA)
STR70256 Wood Auto
STR8265 Unipoint
STR8282 Unipoint
WOOSTR70256 Wood Auto
WOOSTR8282 Wood Auto
0986014541 Bosch ruil
0986UR1009 Bosch ruil
110323 Cargo
1280001441 Denso show
128000162 Denso
1280001620 Denso show
1280001621 Denso show
1280001622 Denso
1280001623 Denso
1280003090 Denso show
1280003091 Denso show
190013082 PSH
251044 Elstock
251206 Elstock
2810010020 Toyota
2810010021 Toyota
2810010030 Toyota
281001003084 Toyota
2810010030R Toyota
455590 Valeo
561114 Valeo
66925297 Prestolite
8LHB2003U Prestolite
91295088 Wilson
91295100 Wilson
91295180 Wilson
ATS190 ATK
DRS3024 Remy
DRS3175 Remy
HJS357 HC
JS357 HC
JS631 HC
LRS00769 Lucas
LRS02022 Lucas
LRS2022 Lucas
LRS684 Lucas
LRS768 Lucas
LRS769 Lucas
MSR1048 Magneti Marelli
OSM10625 Optimum
OSM11134 Optimum
S23077 Hitachi
SR113X Bosch (USA)
STR70010 Wood Auto
STR70163 Wood Auto
WOOSTR70010 Wood Auto
WOOSTR70163 Wood Auto
0986017561 Bosch ruil
0986UR1211 Bosch ruil
113121 Cargo
1280008530 Denso show
1280008531 Denso show
1280008890 Denso
1280008891 Denso
17141 Remy
190549092 PSH
2810011010 Toyota
2810011020 Toyota
458503 Valeo
91295288 Wilson
DRS3383 Remy
LRS1481 Lucas
S8224 Dixie
S8365 Dixie
SR3254X Bosch (USA)
STR70256 Wood Auto
STR8265 Unipoint
STR8282 Unipoint
WOOSTR70256 Wood Auto
WOOSTR8282 Wood Auto
Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 202 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 6 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Corolla 1.3 12V | [2E] | 01.1992-12.1995 |
| TOYOTA | Corolla 1.3 12V | [2E] | 01.1992-12.1997 |
| TOYOTA | Corolla 1.3 XLi | [4E-FE] | 01.1992-12.1995 |
| TOYOTA | Corolla 1.3 XLi | [4E-FE] | 01.1992-12.1997 |
| TOYOTA | Corolla 1.3 XLi | [4E-FE] | 01.1995-12.1997 |
Reference Information
28100-11020 458503 28100-11010 110323 S-8365 LRS1481 91-29-5258 28100-10030 0986017561 LRS01481 STR70256 UD20536S 6040357 STX200365 STX200772 25-2424 JS357 20432753BN CST40357AS 11496 128000-8891 128000-8890Video/Publications
