Associated Numbers
063280084010 09A911023 09A911023X 114308 17772 17865R 20445791RC 220344 25-3173 254542H 300.539.102 3383 6020197 91-25-1189 944280800860 AEY1641 CS1477 CST20197 CST20197AS CST20197ES CST20197GS CST20197OS CST20197RS DENDSN957 DRS0495 DSN957 EAA-153541 HITS114-875 LRS01641 S-80061 S114-875 UD12912S703233
UD12912S ASPL
AEY1641 AUTOELECTRO
114308 CARGO
CST20197 CASCO
CST20197RS CASCO
3383 CEVAM
17772 DELCO
DRS0495 DELCO
DSN957 DENSO
S80061 DIXIE
EAA153541 EAA
253173 ELSTOCK
220344 ERA
CS1477 HC PARTS
S114875 HITACHIList
LRS01641 LUCAS
063280084010 MAGNETI MARELLI
944280800860 MAGNETI MARELLI
300.539.102 PSH
20445791RC REAL
6020197 SANDO
09A911023 VW
09A911023X VW
17865R WAI / TRANSPO
91251189 WILSON
DENDSN957 WOODAUTO
HITS114875 WOODAUTO
Arrowhead BSR9497X
Audi 09A911023, 09A911023X
Hitachi S114875
Lester 17865
Volkswagen 09A911023, 09A911023X
Beck Arnley 1870811
Bosch SR9497X
Delco 3361781
Denso 2803135
Hitachi S114875
Lester 17865
PIC Picture ID 104320
Remy Light Duty 17772
Volkswagen 09A911023
09A911023 VW
11090045 EuroTec
17865 Lester
17865N WAI
17865R WAI
253173 Elstock
300539102 PSH
8080086F Friesen
910495 EDR
91251189 Wilson
CS1477 HC
DRS0495 Remy
DSN957 Denso
LRS01641 Lucas
S114875 Hitachi
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 234 mm |
| Mount Hole Center - Center (O.1) | 143 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | ACW |
| Voltage | 12 V |
Vehicle Applications
250032, AUDI, A3 1.8 Turbo, [AUQ], 05.2000-06.2003, ,250032, AUDI, A3 1.8 Turbo 20V, [AQA], 12.1996-05.2003, ,250032, VW, Bora 1.8 T, [AUM], 01.2000-12.2005, AT,250032, VW, Bora 2.3 V5 4-Motion, [AQN], 01.2000-12.2005, AT,250032, VW, Bora 2.8 V6 4-Motion, [AUE], 05.2000-05.2005, ,250032, VW, Bora 2.8 VR6, [AUE], 03.2000-05.2000, ,250032, VW, Golf IV 1.8 GTi Turbo, [AUQ], 08.2001-06.2005, ,250032, VW, Golf IV 1.8 Turbo, [AGU], -5.2, ,250032, VW, Golf IV 2.8 V6 4-Motion, [AUE], 03.1999-06.2005, ,250032, VW, Golf IV 2.8 V6 4-Motion, [BDE], 03.1999-06.2005, ,250032, VW, Golf IV 2.8 V6 4-Motion, [BDE], -5.2, ,250032, VW, Jetta 1.8, , 01.2000-12.2003, ,250032, VW, Jetta 2.8, , 01.2002-12.2004, ,250032, VW, Sharan 1.8 T, [AWC], -1.2, AT,250032, VW, Sharan 1.8 T 20V, [AJH], 09.1997-03.2010,View your shopping basket or Browse other items in Starter Motors.
