Associated Numbers
0121715078 0121715178 06E903018H 06E903018HX 205.549.180 554417RIR 90-15-6653 A-6622 BOS0121715178 DRA0898 UD12092A
0121715050 Bosch
0121715078 Bosch show
0121715078OR +line
0121715150 Bosch
0121715178 Bosch
06E903016T VW
06E903018H VW
06E903018HX VW
12090219 EuroTec
12090617 EuroTec
205549180 PSH
287577 Elstock
40002 CEVAM
40202 CEVAM
9090661 Friesen
9090661F Friesen
930898 EDR
DRA0898 Remy
LRA03967 Lucas
ARROWHEAD400-24257
BOSCH0121715078, 0121715178
LESTER11495
VOLKSWAGEN06E903-018H, 06E903-018HX
AUDI 06E903018H
BOSCH 0121715078
BOSCH 0121715178
LUCAS LRA03967
LUCAS LRA3967
VW (VOLKSWAGEN) 06E903018H
VW (VOLKSWAGEN) 06E903018HX
Specifications
| Amp | 180 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 189 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 65 mm |
| Pulley to Mount Distance (A) | 31 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.8 FSi | [CCDA] | 10.2008-08.2011 |
| AUDI | A6 2.8 FSi | [CCEA] | 10.2008-08.2011 |
| AUDI | A6 2.8 FSi Quattro | [CCDA] | 10.2008-08.2011 |
| AUDI | A6 2.8 FSi Quattro | [CCEA] | 10.2008-08.2011 |
| AUDI | A6 3.0 FSi Quattro | [CAJA] | 10.2008-08.2011 |
| AUDI | A6 3.2 FSi | [CALA] | 05.2009-03.2011 |
| AUDI | A6 Allroad 3.0 TFSi Quattro | [CAJA] | 10.2008-08.2011 |
Reference Information
STX102161 CAL10040GS 554417RIR DRA0898 20101040OE 0121715078 0121715178 PRAE889 UD12092A A12BH0750AS 06E903018HX 90-15-6653 06E903016T BOS0121715178 205.549.180 A-6622 ALT124490A ALTE889 06E903018H ALT124490 ALT1692 2010040.1 06E903016TXVideo/Publications
