Associated Numbers
AAM-C8001 AGV-C8001
0986UR6274 Bosch ruil show
1042106250 Denso show
1042106250OR +line
1042106250SEL +line
1042106251 Denso show
1042106254 Denso show
12090417 EuroTec
12317591268 BMW
12317591271 BMW
2151972102 DRI
215520210 PSH
286776 Elstock
40458 CEVAM
440990 Valeo
443430 Valeo
7591268 BMW
7591271 BMW
9090711F Friesen
930881 EDR
DAN1129 Denso
DRA0881 Remy
LRA03636 Lucas
TG23C039AMQ Valeo
TG23C042 Valeo
TNA109 TWA
UD12119A ASPL
AEK3636 AUTOELECTRO
12317591268 BMW
12317591271 BMW
0986UR6274 BOSCH
11141 DELCO
DRA0881 DELCO
1042106250 DENSOList
1042106251 DENSOList
1042106252 DENSOList
1042106254 DENSOList
A80609 DIXIE
286776 ELSTOCK
LRA03636 LUCAS
215.520.210 PSH
439234 VALEOList
90295834 WILSON
1042106250 Denso
1042106250OR
1042106251 Denso
12090417 EuroTec
12317591268 BMW
12317591271 BMW
215520210 PSH
286776 Elstock
7591268 BMW
9090711F Friesen
930881 EDR
DAN1129 Denso
DRA0881 Remy
LRA03636 Lucas
TNA109 TWA
658661
Arrowhead AND0602
J&N 40052415
BMW 12317591268, 12317591271, 7591268, 7591271
Bosch 0986UR6274, AL9453X
Denso 104210625, 1042106250, 1042106251, 1042106252, 1042106254
Lester 11791
Lucas LRA03636
PIC Picture ID 2205530, 2205532, 2906001
Remy Light Duty 11141
Youtech/PartRef 325654
Wilson 90295834
0986UR6274 104210-6250 104210-6251 104210-6252 104210-6254 11141 12317591268 12317591271 215.520.210 28-6776 301591RI 439234 555134RI 90-29-5834 A-80609 AEK3636 DRA0881 LRA03636 UD12119A
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 210 A |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Diameter (D.4) | 10.5 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 42 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 62.5 mm |
| Pad mount thickness (E.2) | 62.5 mm |
| Pad mount thickness (E.3) | 62.5 mm |
| Pad mount thickness (E.4) | 62.5 mm |
| Plug Code | PL_2303 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 49 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 523 3.0 i | [N53B30A] | 01.2010- |
| BMW | 528 3.0 i | [N53B30A] | 01.2010- |
| BMW | 530 3.0 i | [N53B30A] | 01.2011- |
| BMW | 730 3.0 i | [N52B30..] | 01.2008- |
| BMW | X3 3.0 xDrive 28 i | [N52B30A] | 01.2011- |
Reference Information
0986UR6274 104210-6250 104210-6251 104210-6252 104210-6254 11141 12317591268 12317591271 215.520.210 28-6776 301591RI 439234 555134RI 90-29-5834 A-80609 AEK3636 DRA0881 LRA03636 UD12119AView your shopping basket or Browse other items in Alternators.
