Associated Numbers
a0299 0121715041 Bosch 0121715051 0121715076 0121715076OR 0121715176 059903018E VW 059903018EX 059903018T 059903018TX 0986081930 ruil 12090422 EuroTec 12090500 205578180 PSH 285898 Elstock 9090608F Friesen 930833 EDR DRA0833 Remy EF33380 L81800 ATL LRA03286 Lucas OAN12716 Optimum UD12089A ASPL  AEK3216 AUTOELECTRO BOSCH  BOSCHList 0121715151 115906 CARGO CAL15485 CASCO CAL15485GS 4165 CEVAM DRA0372 DELCO 285828 ELSTOCK ALB5151 KRAUF ALB8151 LRA03216 LUCAS 89215645 POWERMAX 20179584OE REAL 2015485 SANDO 059903016P VW 059903016PX 20331N WAI / TRANSPO UD02346A ASPL 0121715080 0121715180 115910 CAL15396GS 20179693OE 2015396 059903018K BOS0121715176 WOODAUTO 651073 6510731 ASPL BOSCH BOSCHList CARGO CASCO CEVAM DELCO ELSTOCK KRAUF LUCAS POWERMAX REAL SANDO 6510731 28-5828 553790RI 553790RIV CAL15485AS CAL15485ES CAL15485OS CAL15485RS PSH anb5051gq anb5051
205.578.180.014
AAM-C6010 - Check Plug Location
A0409
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 174 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.7 TDi | [BSG] | 03.2005-08.2011 |
| AUDI | A6 2.7 TDi | [CANA] | 10.2008-08.2011 |
| AUDI | A6 2.7 TDi | [CANB] | 03.2005-08.2011 |
| AUDI | A6 2.7 TDi Quattro | [BSG] | 06.2005-08.2011 |
| AUDI | A6 2.7 TDi Quattro | [CANA] | 01.2008- |
| AUDI | A6 2.7 TDi Quattro | [CANC] | 10.2008-08.2011 |
| AUDI | A6 2.7 TDi Quattro | [CAND] | 06.2005-08.2011 |
| AUDI | A6 3.0 TDi | [BNG] | 01.2008- |
| AUDI | A6 3.0 TDi | [CDYA] | 01.2008- |
| AUDI | A6 3.0 TDi | [CDYB] | 01.2008- |
| AUDI | A6 3.0 TDi | [CDYC] | 01.2008- |
| AUDI | A6 3.0 TDi Quattro | [BNG] | 03.2005-08.2011 |
| AUDI | A6 3.0 TDi Quattro | [CDYA] | 10.2008-08.2011 |
| AUDI | A6 3.0 TDi Quattro | [CDYB] | 03.2005-08.2011 |
| AUDI | A6 3.0 TDi Quattro | [CDYC] | 10.2008-08.2011 |
| AUDI | A6 Allroad 2.7 TDi Quattro | [BSG] | 05.2006-08.2011 |
| AUDI | A6 Allroad 2.7 TDi Quattro | [CANC] | 10.2008-08.2011 |
| AUDI | A6 Allroad 2.7 TDi Quattro | [CAND] | 05.2006-08.2011 |
| AUDI | A6 Allroad 3.0 TDi Quattro | [BNG] | 05.2006-08.2011 |
| AUDI | A6 Allroad 3.0 TDi Quattro | [CDYA] | 10.2008-08.2011 |
| AUDI | A6 Allroad 3.0 TDi Quattro | [CDYB] | 05.2006-08.2011 |
| AUDI | A6 Allroad 3.0 TDi Quattro | [CDYC] | 10.2008-08.2011 |
| AUDI | Q7 3.0 TDi | [CASA] | 01.2009-12.2010 |
| AUDI | Q7 3.0 TDi | [CASB] | 01.2009-12.2010 |
| AUDI | Q7 3.0 TDi Quattro | [BUG] | 03.2006-05.2008 |
| AUDI | Q7 3.0 TDi Quattro | [BUN] | 03.2006-05.2010 |
| AUDI | Q7 3.0 TDi Quattro | [CASA] | 11.2007-05.2012 |
| AUDI | Q7 3.0 TDi Quattro | [CASB] | 03.2006-05.2010 |
| AUDI | Q7 3.0 TDi Quattro | [CCMA] | 11.2007-05.2012 |
| AUDI | Q7 3.0 TDi Quattro | [CJGA] | 11.2007-05.2012 |
| AUDI | Q7 3.0 TDi Quattro | [CNRB] | 11.2007-08.2015 |
| VW | Jetta 1.6 | [CFNA] | 12.2011- |
| VW | Jetta 1.6 | [CLRA] | 12.2011- |
Reference Information
0121715041 0121715051 0121715151 059903016P 059903016PX 115906 2015485 20179584OE 20331N 28-5828 4165 553790RI 553790RIV 89215645 AEK3216 AI-90223 ALB5151 ALB8151 ALT174850 ALTL359 ALTL359V CAL15485 CAL15485AS CAL15485ES CAL15485GS CAL15485OS CAL15485RS CGB-85828 DRA0372 LRA03216 LRA3216 PRAL359 PRAL359V RNL715051 UD12089A
