.jpg?w=800&h=600.jpg)
- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- < Critical Notes >
Associated Numbers
A0425 A3229 ASPL List UD02342A UD11345A AEK2970 AUTOELECTRO 12317550967 BMW 12317550968 12317551254 12317551256 12317555926 7550967 7550968 7551256 7555926 0121615010 BOSCH 0121615110 0121715012 0121715112 116120 CARGO 116121 CAL10377 CASCO 4775 CEVAM DRA0162 DELCO A6571 DIXIE EAA222989 EAA 57437 EAI 285584 ELSTOCK 209038 ERA AG1557 GHIBAUDI CA1953IR HC PARTS 8EL738212381 HELLA ALB1953UX KRAUF ALB9953 ALV1953 ALV1953DD ALV1953UX 11.1953M LAUBER LRA02970 LUCAS 063537151120 MAGNETI MARELLI 063731953010 89212348 POWERMAX 9212348 215.545.180 PSH 437557 VALEO 11301N WAI / TRANSPO 11301R 90156578 WILSON BOS0121715112 WOODAUTO 0986048820 11301 215545180 2205481 9090647F 930162 ALT1325sa KTR431090360 0156577 0986047970 11300 11300N 215544150 2205483 930161 CAL10391GS DRA0161 DRA1061 LRA03566 OAN12840 UD12081A 7551254 0986047977 116012 CAL10391 286676 89215531 215.544.150.014 215.544.150.215 11300R Arrowhead ABO0393 Bosch AL0839N AL0839X Lester Lucas PIC Picture ID Remy Light Duty 12890 Wilson 90156577 J N 40024287 ABO0391 VBO0391 Beck Arnley 1861341 1861468 0986048827 AL0841N AL0841X LRA2970 12891 Steyr Motors Youtech/PartRef 325402 651067 20101773BN 20101773OE 2010377 28-5584 301953RI 301953RIB 553210RIV 553647RI 553647RIB 8EL738212-381 90-15-6578 A-6571 CAL10377AS CAL10377ES CAL10377GS CAL10377OS CAL10377RS EAA-222989 show 0121615010RB RNL ruil Sidat Cargo 12090619 EuroTec 2010391 Sando 2151771502 DRI Elstock EDR (USA) Optimum RNL4797 439560 12-31-7-550-967 12-31-7-551-254 0-121-615-010 0-121-615-110 Newman Reman Service Europe 0-986-047-977 IAT 170-11300R (Reman) A11300 220-5483 220-5483A Saab 12785604 BBB Industries Dixie Electric Ltd A-6556 Industry J&N 400-24215 PPR BOA325 Romaine 12 78 5604 Voltux V2-11300 90-15-6577Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 42 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 62 mm |
| Pad mount thickness (E.2) | 62 mm |
| Plug Code | PL_2303 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 49 mm |
| Pulley to Mount Distance (A) | 30.5 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 125 3.0 i | (E82)[N52B30A] | 10.2007- |
| BMW | 125 3.0 i | (E88)[N52B30A] | 03.2008- |
| BMW | 130 3.0 i | (E81)[N52B30A] | 09.2006-09.2012 |
| BMW | 130 3.0 i | (E81)[N52B30B] | 09.2006-09.2012 |
| BMW | 130 3.0 i | (E81)[N52B30BF] | 09.2006-09.2012 |
| BMW | 130 3.0 i | (E87)[N52B30A] | 09.2006-09.2012 |
| BMW | 130 3.0 i | (E87)[N52B30AF] | 03.2005-09.2012 |
| BMW | 130 3.0 i | (E87)[N52B30B] | 09.2006-09.2012 |
| BMW | 130 3.0 i | (E87)[N52B30BF] | 09.2006-09.2012 |
| BMW | 323 2.5 i | (E90)[N52B25] | 04.2006-06.2007 |
| BMW | 323 2.5 i | (E91)[N52B25A] | 09.2006-07.2008 |
| BMW | 323 2.5 i | (E92)[N52B25AE] | 04.2006-02.2012 |
| BMW | 323 2.5 i | (E93)[N52B25A] | 03.2007-09.2011 |
| BMW | 325 2.5 i | (E90)[N52B25] | 01.2005- |
| BMW | 325 2.5 i | (E90)[N52B25A] | 01.2006- |
| BMW | 325 2.5 i | (E90)[N52B25C] | 01.2005- |
| BMW | 325 2.5 i | (E92)[N52B25A] | 09.2006- |
| BMW | 325 2.5 i | (E92)[N52B25C] | 09.2006- |
| BMW | 325 2.5 i | (E93)[N52B25] | 03.2007- |
| BMW | 325 2.5 i | (E93)[N52B25A] | 03.2007- |
| BMW | 325 2.5 i xDrive | (E92)[N52B25A] | 09.2006-12.2013 |
| BMW | 325 2.5 Xi | (E90)[N52B25A] | 01.2005-12.2011 |
| BMW | 325 2.5 Xi | (E90)[N52B25C] | 01.2005-12.2011 |
| BMW | 325 2.5 Xi | (E91)[N52B25A] | 01.2005- |
| BMW | 325 2.5 Xi | (E91)[N52B25C] | 01.2005- |
| BMW | 325 2.5 Xi | (E92)[N52B25A] | 09.2006- |
| BMW | 325 2.5 Xi | (E92)[N52B25C] | 09.2006- |
| BMW | 325 3.0 i | (E90)[N53B30] | 09.2007-12.2011 |
| BMW | 325 3.0 i | (E90)[N53B30A] | 09.2007-12.2011 |
| BMW | 325 3.0 i | (E91)[N53B30] | 09.2007- |
| BMW | 325 3.0 i | (E91)[N53B30A] | 09.2007- |
| BMW | 325 3.0 i | (E92)[N51B30A] | 09.2007- |
| BMW | 325 3.0 i | (E92)[N53B30] | 09.2007- |
| BMW | 325 3.0 i | (E92)[N53B30A] | 09.2007- |
| BMW | 325 3.0 i | (E93)[N51B30A] | 03.2007- |
| BMW | 325 3.0 i | (E93)[N53B30] | 03.2007- |
| BMW | 325 3.0 i | (E93)[N53B30A] | 03.2007- |
| BMW | 325 3.0 i xDrive | (E90)[N53B30A] | 09.2008-12.2011 |
| BMW | 325 3.0 i xDrive | (E91)[N51B30A] | 09.2007- |
| BMW | 325 3.0 i xDrive | (E91)[N53B30A] | 09.2007- |
| BMW | 325 3.0 i xDrive | (E92)[N51B30A] | 09.2008- |
| BMW | 325 3.0 i xDrive | (E92)[N53B30A] | 09.2008- |
| BMW | 325 3.0 Xi | (E90)[N53B30A] | 09.2007-12.2011 |
| BMW | 325 3.0 Xi | (E91)[N53B30A] | 09.2007- |
| BMW | 325 3.0 Xi | (E92)[N53B30A] | 09.2007- |
| BMW | 3 3.0 | (E93)[N52B30A] | 03.2007- |
| BMW | 3 3.0 | (E93)[N52NB30B] | 03.2007- |
| BMW | 330 3.0 i | (E90)[N52B30] | 01.2005-12.2011 |
| BMW | 330 3.0 i | (E90)[N52B30A] | 09.2007-12.2011 |
| BMW | 330 3.0 i | (E90)[N52B30B] | 09.2007-12.2011 |
| BMW | 330 3.0 i | (E90)[N52B30BF] | 09.2007-12.2011 |
| BMW | 330 3.0 i | (E90)[N53B30A] | 09.2007-12.2011 |
| BMW | 330 3.0 i | (E91)[N53B30A] | 09.2007- |
| BMW | 330 3.0 i | (E92)[N52B30A] | 09.2006- |
| BMW | 330 3.0 i | (E92)[N53B30A] | 09.2007- |
| BMW | 330 3.0 i | (E93)[N52B30A] | 03.2007- |
| BMW | 330 3.0 i | (E93)[N53B30A] | 03.2007- |
| BMW | 330 3.0 i xDrive | (E90)[N53B30A] | 09.2008-12.2011 |
| BMW | 330 3.0 i xDrive | (E91)[N53B30A] | 09.2007- |
| BMW | 330 3.0 i xDrive | (E92)[N53B30A] | 09.2008- |
| BMW | 330 3.0 Xi | (E90)[N52B30A] | 01.2005-12.2011 |
| BMW | 330 3.0 Xi | (E90)[N53B30A] | 09.2007-12.2011 |
| BMW | 330 3.0 Xi | (E91)[N52B30A] | 01.2005- |
| BMW | 330 3.0 Xi | (E91)[N53B30A] | 09.2007- |
| BMW | 330 3.0 Xi | (E92)[N52B30A] | 09.2006- |
| BMW | 330 3.0 Xi | (E92)[N53B30A] | 09.2006- |
| BMW | 523 2.5 i | (E60)[N52B25] | 07.2005- |
| BMW | 523 2.5 i | (E60)[N52B25A] | 01.2007- |
| BMW | 523 2.5 i | (E60)[N53B25A] | 01.2007- |
| BMW | 523 2.5 i | (E61)[N52B25] | 07.2005- |
| BMW | 523 2.5 i | (E61)[N52B25A] | 01.2007- |
| BMW | 523 2.5 i | (E61)[N53B25A] | 01.2007-12.2010 |
| BMW | 525 2.5 i | (E60)[N52B25] | 07.2005- |
| BMW | 525 2.5 i | (E60)[N52B25A] | 07.2005- |
| BMW | 525 2.5 i | (E61)[N52B25] | 07.2005- |
| BMW | 525 2.5 i | (E61)[N52B25A] | 07.2005-12.2010 |
| BMW | 525 2.5 i xDrive | (E60)[N53B30A] | 09.2008- |
| BMW | 525 2.5 Xi | (E60)[N52B25A] | 07.2005- |
| BMW | 525 2.5 Xi | (E61)[N52B25A] | 07.2005- |
| BMW | 525 3.0 i | (E60)[N53B30] | 01.2007- |
| BMW | 525 3.0 i | (E60)[N53B30A] | 01.2007- |
| BMW | 525 3.0 i | (E61)[N53B30] | 01.2007- |
| BMW | 525 3.0 i | (E61)[N53B30A] | 01.2007- |
| BMW | 525 3.0 i xDrive | (E61)[N53B30A] | 09.2008- |
| BMW | 525 3.0 Xi | (E60)[N53B30A] | 01.2007- |
| BMW | 525 3.0 Xi | (E61)[N52B30A] | 01.2007- |
| BMW | 525 3.0 Xi | (E61)[N53B30A] | 01.2007- |
| BMW | 530 3.0 i | (E60)[N52B30A] | 01.2007-03.2010 |
| BMW | 530 3.0 i | (E60)[N52B30B] | 01.2007-03.2010 |
| BMW | 530 3.0 i | (E60)[N52B30BF] | 01.2007-03.2010 |
| BMW | 530 3.0 i | (E60)[N53B30A] | 01.2007- |
| BMW | 530 3.0 i | (E61)[N52B30] | 07.2005- |
| BMW | 530 3.0 i | (E61)[N52B30A] | 01.2007- |
| BMW | 530 3.0 i | (E61)[N53B30A] | 01.2007- |
| BMW | 530 3.0 i xDrive | (E60)[N52B30A] | 09.2008- |
| BMW | 530 3.0 i xDrive | (E60)[N53B30A] | 09.2008- |
| BMW | 530 3.0 i xDrive | (E61)[N52B30A] | 09.2008- |
| BMW | 530 3.0 i xDrive | (E61)[N53B30A] | 09.2008- |
| BMW | 530 3.0 Xi | (E60)[N52B30A] | 01.2007- |
| BMW | 530 3.0 Xi | (E60)[N53B30A] | 01.2007- |
| BMW | 530 3.0 Xi | (E61)[N52B30A] | 01.2007- |
| BMW | 530 3.0 Xi | (E61)[N53B30A] | 01.2007- |
| BMW | 630 3.0 i | (E63)[N52B30] | 09.2004- |
| BMW | 630 3.0 i | (E63)[N52B30A] | 07.2007- |
| BMW | 630 3.0 i | (E63)[N52B30B] | 07.2007-07.2010 |
| BMW | 630 3.0 i | (E63)[N52B30BF] | 07.2007-07.2010 |
| BMW | 630 3.0 i | (E64)[N52B30] | 09.2004- |
| BMW | 630 3.0 i | (E64)[N52B30A] | 07.2007-07.2010 |
| BMW | 630 3.0 i | (E64)[N52B30B] | 07.2007- |
| BMW | 630 3.0 i | (E64)[N52B30BF] | 07.2007-07.2010 |
| BMW | 730 3.0 Li | (E65)[N52B30] | 03.2005- |
| BMW | 730 3.0 Li | (E65)[N52B30A] | 03.2005- |
| BMW | 730 3.0 Li | (E66)[N52B30] | 03.2005- |
| BMW | 730 3.0 Li | (E66)[N52B30A] | 03.2005- |
| BMW | 730 3.0 Li | (E67)[N52B30] | 03.2005- |
| BMW | 730 3.0 Li | (E67)[N52B30A] | 03.2005- |
| BMW | X1 3.0 xDrive | (E84)[N52B30A] | 10.2009- |
| BMW | X1 3.0 xDrive 25i | (E84)[N52B30A] | 01.2010- |
| BMW | X3 2.5 i xDrive | (E83)[N52B25A] | 09.2008- |
| BMW | X3 2.5 Si xDrive | (E83)[N52B25A] | 07.2006-12.2008 |
| BMW | X3 3.0 i xDrive | (E83)[N52B30A] | 09.2008- |
| BMW | X5 3.0 i xDrive | (E70)[N52B30A] | 09.2008- |
| BMW | X5 3.0 Si | (E70)[N52B30] | 02.2007-09.2008 |
| BMW | X5 3.0 Si | (E70)[N52B30A] | 02.2007-09.2008 |
Alternatives >>>
A3229 - Valeo Option
A0499 - Battery Insulator Difference
Reference Information
0121615010 0121615110 0121715012 0121715112 063537151120 063731953010 11.1953M 11301N 11301R 116120 116121 12317550967 12317550968 12317551254 12317551256 12317555926 20101773BN 20101773OE 2010377 209038 215.545.180 28-5584 301953RI 301953RIB 437557 4775 553210RIV 553647RI 553647RIB 57437 7550967 7550968 7551256 7555926 89212348 8EL738212-381 90-15-6578 9212348 A-6571 A0425 AEK2970 AG1557 AI-90225 ALB1953UX ALB9953 ALT173270 ALTE310 ALTS400 ALTS400B ALTS400V ALV1953 ALV1953DD ALV1953UX BOS0121715112 CA1953IR CAL10377 CAL10377AS CAL10377ES CAL10377GS CAL10377OS CAL10377RS CGB-85584 DRA0162 EAA-222989 LRA02970 LRA2970 PRAS400 PRAS400B PRAS400V UD02342A UD11345A< Critical Notes >
Can be used to replace A0459 but will require AFP0068(INA).
If we are out of stock of the A0459 but have the pulley AFP0068(INA) in stock we can happily swap them for you.
