Associated Numbers
115684 116316 12281 1778016 1893556 2033247 20479272 25-4377 254845 254845V 31324544 3219 438299 458706 590.576.113 6015272 88214620 8EA011611-591 AV6N-11000-GA AV6N-11000-GB AV6N-11000-GC AV6N-11000-GD AV6N-11000-GE CST15272 CST15272AS CST15272ES CST15272GS CST15272OS CST15272RS DRS0751 DS1861 EAA-123083 ESW20E11 LRS02705 STM1326 UD16959S VAL438299
11090318 EuroTec
115684 Cargo
116316 Cargo
12281 EAI
1715211 Ford
1778016 Ford
1893556 Ford
197695 Lester
2033247 Ford
214745 Valeo
220715 Messmer
31324544 Ford
3219 CEVAM
438299 Valeo
458706 Valeo
590576113 PSH
910751 EDR
AV6N11000GA Ford
AV6N11000GB Ford
AV6N11000GC Ford
AV6N11000GE Ford
AV9N11000GC Ford
DRS0751 Remy
ESW2022 Valeo
ESW20E11 VW
ESW20E11SEL +line
LRS02705 Lucas
LRS2705 Lucas
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 234 mm |
| Mount Hole Center - Center (O.1) | 116 mm |
| Mount Hole Center - Center (O.2) | 74.5 mm |
| Mount Hole Center - Center (O.3) | 84 mm |
| Mount Hole Diameter (C.1) | 9.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 13 mm |
| Rotation | CW |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | C-Max 1.5 TDCi | [XWDA] | 03.2015- |
| FORD | C-Max 1.5 TDCi | [XWDB] | 03.2015- |
| FORD | C-Max 1.5 TDCi | [XXDA] | 03.2015- |
| FORD | C-Max 1.5 TDCi ECOnetic | [AEDA] | 03.2015- |
| FORD | C-Max 1.6 TDCi | [T1DA] | 12.2010- |
| FORD | C-Max 1.6 TDCi | [T1DB] | 12.2010- |
| FORD | C-Max 1.6 TDCi | [T3DA] | 12.2010- |
| FORD | C-Max 1.6 TDCi | [T3DB] | 12.2010- |
| FORD | Focus 1.5 TDCi | [XWDA] | 11.2014- |
| FORD | Focus 1.5 TDCi | [XWDB] | 11.2014- |
| FORD | Focus 1.5 TDCi | [XWDC] | 11.2014- |
| FORD | Focus 1.5 TDCi | [XWDD] | 11.2014- |
| FORD | Focus 1.5 TDCi | [XXDA] | 11.2014- |
| FORD | Focus 1.5 TDCi | [XXDC] | 11.2014- |
| FORD | Focus 1.5 TDCi ECOnetic | [XXDB] | 11.2014- |
| FORD | Focus 1.6 TDCi | [T1DA] | 02.2012- |
| FORD | Focus 1.6 TDCi | [T1DB] | 02.2012- |
| FORD | Focus 1.6 TDCi | [T3DA] | 05.2011- |
| FORD | Focus 1.6 TDCi | [T3DB] | 05.2011- |
| FORD | Focus 1.6 TDCi ECOnetic | [NGDA] | 05.2012- |
| FORD | Galaxy 1.6 TDCi | [T1WA] | 02.2011- |
| FORD | Galaxy 1.6 TDCi | [T1WB] | 02.2011- |
| FORD | Grand C-Max 1.5 TDCi | [XWDA] | 03.2015- |
| FORD | Grand C-Max 1.5 TDCi | [XWDB] | 03.2015- |
| FORD | Grand C-Max 1.6 TDCi | [T1DA] | 12.2010- |
| FORD | Grand C-Max 1.6 TDCi | [T1DB] | 12.2010- |
| FORD | Grand C-Max 1.6 TDCi | [T3DA] | 12.2010- |
| FORD | Grand C-Max 1.6 TDCi | [T3DB] | 12.2010- |
| FORD | Kuga 1.5 TDCi | 07.2016- | |
| FORD | Mondeo 1.5 TDCi | [UGCC] | 03.2015- |
| FORD | Mondeo 1.5 TDCi | [XUCA] | 03.2015- |
| FORD | Mondeo 1.6 TDCi | [T1BA] | 02.2011- |
| FORD | Mondeo 1.6 TDCi | [T1BB] | 02.2011- |
| FORD | Mondeo 1.6 TDCi | [T1BC] | 02.2011- |
| FORD | S-Max 1.6 TDCi | [T1WA] | 02.2011- |
| FORD | S-Max 1.6 TDCi | [T1WB] | 02.2011- |
| FORD | Tourneo Connect 1.5 TDCi | [XUGA] | 05.2015- |
| FORD | Tourneo Connect 1.5 TDCi | [XVGA] | 05.2015- |
| FORD | Tourneo Connect 1.5 TDCi | [XVGB] | 05.2015- |
| FORD | Tourneo Connect 1.5 TDCi | [XVGC] | 05.2015- |
| FORD | Tourneo Connect 1.5 TDCi | [XWGA] | 05.2015- |
| FORD | Tourneo Connect 1.5 TDCi | [XWGB] | 05.2015- |
| FORD | Tourneo Connect 1.6 TDCi | [T1GA] | 09.2013- |
| FORD | Tourneo Connect 1.6 TDCi | [TZGA] | 09.2013- |
| FORD | Tourneo Connect 1.6 TDCi | [TZGB] | 09.2013- |
| FORD | Tourneo Connect 1.6 TDCi | [UBGA] | 09.2013- |
| FORD | Transit Connect 1.5 TDCi | [XUGA] | 08.2015- |
| FORD | Transit Connect 1.5 TDCi | [XVGA] | 05.2015- |
| FORD | Transit Connect 1.5 TDCi | [XVGB] | 05.2015- |
| FORD | Transit Connect 1.5 TDCi | [XVGC] | 05.2015- |
| FORD | Transit Connect 1.5 TDCi | [XWGA] | 05.2015- |
| FORD | Transit Connect 1.5 TDCi | [XWGB] | 05.2015- |
| FORD | Transit Connect 1.6 TDCi | [TZGA] | 09.2013- |
| FORD | Transit Connect 1.6 TDCi | [TZGB] | 09.2013- |
| FORD | Transit Connect 1.6 TDCi | [UBGA] | 09.2013- |
Reference Information
