Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 482.46 including GST
NZ$ 419.53 excluding GST
or four payments of $120.62
with
Learn More
each
S9430S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
IS1456Specifications
| Kilowatt | 3.2 kW |
| Length (L.1) | 278 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 21 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.5 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HATZ | Engine | [2M41] | |
| HATZ | Engine | [4L41] | |
| HATZ | Engine 1.7 | [2L41C] | |
| HATZ | Engine 1.7 | [2M41] | |
| HATZ | Engine 2.6 | [3L41C] | |
| HATZ | Engine 2.6 | [3M41] | |
| HATZ | Engine 2.6 | [3M43-DPF] | |
| HATZ | Engine 2.6 | [3M43-EGR] | |
| HATZ | Engine 3.4 | [4L42C] | |
| HATZ | Engine 3.4 | [4M41] | |
| HATZ | Engine 3.4 | [4M42] | |
| HATZ | Engine 3.4 | [4M42-EGR] | |
| HATZ | Engine 3.4 | [4M43] | |
| HATZ | Engine 3.4 | [4M43-DFP] | |
| HATZ | Engine 3.4 | [4M43-EGR] | |
| HUEDIG | SDVA 200 3.4 | [4L41C] | |
| LOMBARDINI | 1503 M 1.6 | 01.1996- | |
| LOMBARDINI | 2004 M 2.1 | 01.1996- | |
| LOMBARDINI | 2004 TBI 2.1 | 01.1996- | |
| SELWOOD | H80 3.4 | [4L41C] | |
| SELWOOD | HSP20 1.7 | [2L41C] | |
| SELWOOD | HSP35 2.6 | [3L41C] | |
| TURBOSOL | TB 30 2.6 | [3M41] |
Reference Information
11.132.389 S12ML0391A2 02502000 730.511.112.310 AZE4285 18236N 72412085 730.511.112.770 AZE4182 MAHMS725 6021185.1 331020 UD19377S IS1456 20419581BN STI4285 255839 STR79417 504761011053 6021185.0 20419581OE 000050648800 000050476101 000050476102 255839M 182-30492 CST21185AS 730.511.112.090 S9430S MS725 11.131.820 505407001023 CST21185GS 50476102 50648800Video/Publications
