Associated Numbers
0124525060 0124525061 0124525521 0124525522 0986047380 0986047383 11.1988 11091N 114312 20101814BN 20101814OE 2010418 209074 28-5539 301988RI 301988RIB 30658085 30667787 30667894 36012358 36050263 57567 815.521.140 8603262 8603263 89212203 8EL012428-431 8EL738212-171 90-15-6614 9047380 9212203 9364 A-6601 AEC1673 AEK2924 ALB1988 ALB1988AN ALB1988UX ALT10703 CA1988IR CAL10418 CAL10418AS CAL10418ES CAL10418GS CAL10418OS CAL10418RS DRB7380 EAA-221530 LRA02924 A0275
0124525060 Bosch
0124525061 Bosch show
0124525521 Bosch show
0124525521OR +line
0124525522 Bosch
0986047380 Bosch ruil
0986047387 Bosch ruil
11091 Lester
114312 Cargo
11447 Lester
12047380 EuroTec
2205049A PIC
2205051A PIC
2381441402 DRI
285539 Elstock
30658084 Volvo
30658085 Volvo
30667787 Volvo
30667892 Volvo
30667894 Volvo
36012358 Volvo
36050263 Volvo
57567 EAI
6439SP Spidan
815521140 PSH
8603262 Volvo
8603263 Volvo
8EL738212171 Hella
9047380 Friesen
9047380F Friesen
947380 EDR
ALT1436sa Electrolog
CA1988IR HC
DRB7380 Remy
HCA1988IR HC
LRA02924 Lucas
LRA2924 Lucas
OAN12353 Optimum
651755 ANB251
Arrowhead ABO0419
Bosch 0124525060, 0124525521, AL0854X
Lester 11091
Lucas LRA02924
PIC Picture ID 220-5049A
Remy Light Duty 11021
Volvo 30658085, 30667787, 30667894, 8603262
Arrowhead ABO0419
Bosch 0124525060, 0124525521, AL0854X
Lester 11091
Lucas LRA02924
PIC Picture ID 220-5049A
Remy Light Duty 11021
Volvo 30658085, 30667787, 30667894, 8603262
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 140 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 8.5 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 82 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 109 mm |
| Plug Code | PL_1201 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 45 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | S60 2.0 T | [B5204T5] | 01.2004-12.2009 |
| VOLVO | S60 2.4 | [B5244S] | 01.2004-12.2009 |
| VOLVO | S60 2.4 | [B5244S2] | 01.2004-12.2009 |
| VOLVO | S60 2.4 | [B5244T4] | 01.2005-10.2006 |
| VOLVO | S60 2.4 Bifuel | [B5244SG..] | 01.2004-12.2008 |
| VOLVO | S60 2.4 CDi | [D5244..] | 01.2003-12.2005 |
| VOLVO | S60 2.4 CDi | [D5244T3] | 10.2003-12.2005 |
| VOLVO | S60 2.4 D | [D5244T..] | 01.2004- |
| VOLVO | S60 2.4 D | [D5244T2] | 12.2001- |
| VOLVO | S60 2.4 D5 | [D5244T..] | 01.2004- |
| VOLVO | S60 2.4 LPG | [B5244SG2] | 06.2002-04.2010 |
| VOLVO | S60 2.4 T5 | [B5244T5] | 01.2004-12.2009 |
| VOLVO | S60 2.4 T AWD | [B5244T3] | 01.2004- |
| VOLVO | S60 2.4 Turbo | [B5244T] | 01.2001-04.2010 |
| VOLVO | S60 2.5 AWD | [B5254T4] | 09.2003-04.2010 |
| VOLVO | S60 2.5 R AWD | [B5254T4] | 01.2004- |
| VOLVO | S60 2.5 T | [B5254T2] | 01.2004-12.2009 |
| VOLVO | S60 2.5 T AWD | [B5254T2] | 01.2004-12.2009 |
| VOLVO | S60 2.5 Turbo AWD | [B5254T2] | 04.2004- |
| VOLVO | S60 R 2.5 Turbo AWD | [B5254T4] | 03.2003- |
| VOLVO | S80 2.0 T | [B5204T..] | 01.1998-12.2006 |
| VOLVO | S80 2.4 Bifuel | [B5244SG..] | 01.2004-12.2006 |
| VOLVO | S80 2.4 LPG | [B5244SG] | 09.2001-07.2006 |
| VOLVO | S80 2.5 T | [B5254T2] | 01.2004-12.2006 |
| VOLVO | S80 2.5 T AWD | [B5254T2] | 01.2004-12.2006 |
| VOLVO | S80 3.0 T6 | [D6294T] | 01.2004-12.2006 |
| VOLVO | V70 2.0 T | [B5204T..] | 01.2004-12.2007 |
| VOLVO | V70 2.0 T | [B5204T5] | 01.2004-12.2007 |
| VOLVO | V70 2.4 | [B5244S..] | 01.2004-12.2007 |
| VOLVO | V70 2.4 Bifuel | [B5244SG..] | 01.2004-12.2007 |
| VOLVO | V70 2.4 CDi | [B5244T6] | 01.2005-12.2008 |
| VOLVO | V70 2.4 D | [D5244T..] | 01.2004-12.2007 |
| VOLVO | V70 2.4 D5 | [D5244T..] | 01.2004-12.2007 |
| VOLVO | V70 2.4 D5 AWD | [D5244T..] | 01.2005-12.2007 |
| VOLVO | V70 2.4 D D5 | [D5244T] | 08.2001- |
| VOLVO | V70 2.4 D D5 | [D5244T5] | 08.2005-07.2007 |
| VOLVO | V70 2.4 LPG | [B5244SG] | 09.2001-08.2007 |
| VOLVO | V70 2.4 T5 | [B5244T5] | 01.2004-12.2007 |
| VOLVO | V70 2.5 R | [B5254T4] | 01.2004-12.2007 |
| VOLVO | V70 2.5 T | [B5254T2] | 01.2004-12.2007 |
| VOLVO | V70 2.5 T AWD | [B5254T2] | 01.2004-12.2007 |
| VOLVO | XC70 2.4 D5 | [D5244T] | 01.2004-12.2007 |
| VOLVO | XC70 2.4 D5 | [D5244T4] | 01.2004-12.2007 |
| VOLVO | XC70 2.5 T | [B5254T2] | 01.2004-12.2007 |
| VOLVO | XC90 2.4 D | [D5244T5] | 10.2002- |
| VOLVO | XC90 2.4 D5 | [D5244..] | 01.2004- |
| VOLVO | XC90 2.4 D D5 | [D5244T18] | 01.2011- |
| VOLVO | XC90 2.4 D D5 AWD | [D5244T5] | 10.2007- |
| VOLVO | XC90 2.5 T | [B5254T2] | 01.2004- |
| VOLVO | XC90 2.5 T AWD | [B5254T9] | 01.2012-12.2014 |
Alternatives >>>
A0430 - 160 Amp Version, Solid Pulley
