Associated Numbers
CATERPILLAR 249-3681 428000-363 428000-3630 428080-363 428080-3630 013681 Andre Niermann 115326 Cargo 4280003630 Denso 4280003630SEL +line 4280803630 640527123 PSH 7983020 Claas DSN2070 0003090520 0007983020 03090520 07983020 10438112 Alanko 106781 Farcom 20130172 AES 2493681 WAI old 255887 DAS 255887P 3090520 438112 6040486 Sando 60404860 88215011 PowerMax CST40486 Casco CST40486AS S134961 Short code S144772 S164302 SDE1241 Everkraft SND1180 Quasar STR70462 Wood Auto WOOSTR70462
| Caterpillar | 249-3681 |
| DENSO | 428000-363, 428000-3630, 428080-363, 428080-3630 |
| Dixie Electric Ltd | S-80579 |
| IAT | S31093 |
| Industry | 31093 |
| J&N | 410-52675 |
| Lester | 31093 |
| PIC | 190-9242 |
| Voltux | V1-433921 |
Specifications
| Diameter (D.1) | 16.5 mm |
| Diameter (D.2) | 16.5 mm |
| Kilowatt | 5.0 kW |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.3) | 16.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 46 mm |
| Pinion/Drive OD | 56 mm |
| Product Line | Standard Line |
| Product Type | Brand New |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR |
Reference Information
|
0003090520 |
Claas |
|---|---|
|
0007983020 |
Claas |
|
013681 |
Andre Niermann |
|
03090520 |
Claas |
|
07983020 |
Claas |
|
10438112 |
Alanko |
|
106781 |
Farcom |
|
115326 |
Cargo |
|
20130172 |
AES |
|
2493681 |
WAI old |
|
255887 |
DAS |
|
255887P |
DAS |
|
3090520 |
Claas |
|
4280003630 |
Denso |
|
4280003630SEL |
+line |
|
4280803630 |
Denso |
|
438112 |
Alanko |
|
6040486 |
Sando |
|
60404860 |
Sando |
|
640527123 |
PSH |
|
7983020 |
Claas |
|
88215011 |
PowerMax |
|
CST40486 |
Casco |
|
CST40486AS |
Casco |
|
DSN2070 |
Denso |
|
S134961 |
Short code |
|
S144772 |
Short code |
|
S164302 |
Short code |
|
SDE1241 |
Everkraft |
|
SND1180 |
Quasar |
|
STR70462 |
Wood Auto |
|
WOOSTR70462 |
Wood Auto |
